Ultrasonic Humidifier

USER MANUAL

Model: PH-805-24

Warning Notice: Before using

this product, please read this

manual carefully and keep it for

future reference.

The design and specifications are

subject to change without prior

notice for product improvement.

Consult with your dealer or

the manufacturer for details.

Rated voltage: 120V

Rated power: 24W

Frequency: 60Hz

QUESTIONS? CONTACT US.

Email: humidifier@fscarro.com

Tel: 888-253-2374

Page 2 

Read This Manual

Inside you’ll find many helpful hints on how to use and maintain your appliance

properly. Just a little preventive care on your part can save you a great deal

of time and money over the life of your appliance. You’ll find many answers

to common problems in the troubleshooting tips - you should be able to fix

most of them quickly before calling customer service. These instructions may

not cover every possible condition, so attention to safety details is required

when operating and maintaining this product.

SAFETY PRECAUTIONS

To prevent injury to the user or other people and property damage, the

instructions shown here must be followed. Incorrect operation due to ignoring

of instructions may cause harm or damage. The different levels of risk is shown

by the following indications.

CAUTION

This symbol indicates a hazardous situation, which, if

not avoided, could result in minor or moderate injury.

This symbol addresses practices not related to physical

injury.

NOTICE

This symbol indicates a hazardous situation which, if

not avoided, could result in death or serious injury.

WARNING

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT INSTRUCTIONS

• In the case of power up, do not plug or unplug the power cord with wet hands

to avoid electric shock;

• Do not force the water tank to work in the case of no water;

• Do not add any additives not produced or supervised by the company to the

water tank;

• Do not put or place anything or pets into the water tank;

• Do not add water to the atomization outlet;

• When the humidifier is working, do not touch the water in the water tank or the

parts sank in the water;

• Do not cover the atomization outlet, and please keep it clear above the outlet;

Page 3 

IMPORTANT INSTRUCTIONS

• Do not replace the power cord without authorization, or connect the power

cord halfway or use other appliances in parallel;

• Do not place the appliance near water source;

• Do not disassemble, modify or repair internal parts without authorization;

• Do not climb or sit on the appliance;

• Do not directly flush the humidifier with water;

• Do not store flammable or explosive materials around the humidifier;

• Do not place it near heat source;

• Do not turn off the humidifier by unplugging the power cord directly;

• Do not use volatile oil, alcohol, thinner, etc. to clean the machine, otherwise, the

product may be damaged;

• Do not modify the use and function of the product without permission;

• When the power is turned off in low temperature weather, the water must be

drained.

• Do not place the water container on the live product, the water immersing in the

product will weaken the electrical insulation, resulting in Electric shock, fire, etc;

• Please keep a distance of more than 12 inch between the humidifier and other

products;

• Please use purified water for humidification;

• Please do not use a damaged or worn power cord; Do not replace the power

cord without authorization. If the power cord is damaged, it must be replaced

by the manufacturer, its service department or professional from similar

department to avoid danger.

• The power must be cut off in thunderstorm;

• When an abnormal phenomenon (like a burnt smell) occurs, the operation must

be stopped and the power supply is cut off.

• Please unplug the power cord and clean the water tank, when the appliance is

not used for a long time;

• To avoid bacterial growth, please always change the water in the water tank.

• When the appliance is moved, please unplug the power cord to keep the water

tank stable and to prevent the water from overflowing in the water tank;

• If the appliance is tilted when filled with water, be sure to unplug the power

cord immediately and send it for inspection.

• Suitable temperature for this product: 41°F -104°F; relative humidity: less than

80% RH (please fill purified water with water temperature below 104°F).

Matters that may cause minor injury or property damage.

Please unplug the power plug when filling and cleaning.

The power supply must be within the specified voltage range of the product.

CAUTION

Page 4 

This humidifier is pre-assembled in factory.

ASSEMBLY

RULES FOR SAFE OPERATION

SPECIFICATIONS

Model Rated

voltage

Rated

frequency

Rated

power Noise Volume

of tank

PH-805-24 120V ~60Hz 24W 38dB 2.11Gal

WARNING

• Please be sure to unplug the power cord before filling water.

• The level of the water added shall not be higher than the highest water level;

• Please be not to add the water in the atomization outlet when the water is

added;

• Please do not add additives like essential oil, perfume, drug, etc. to the water.

• Please use the purified water below 104°F(Do not use distilled water).

NOTICE

• The following are the design parametersof PH-805-24 themeasured

parameters are subject to the product;

• The humidification amount will vary, depending on the temperature and

humidity in the room.

• Actualhumidification amount isnot less than 90% the standard 390mL/h.

Page 5 

PARTS AND FEATURES

Manual × 1

NOTICE

Water Mist

Guiding Tube

Water Tank

Main Unit

Control Panel

Atomization Outlet

• The pictures of the Manualare for referenceonly, and theactual product in

thepacking box shall prevail.

• The product appearance and function vary with themodel; Please be subject

to the realproduct,with optional reading of the respective function

description.

Page 6 

INSTRUCTION FOR USE

Two methods forwater filing

Method A

Fill the water tank directly through the main unit cover. Please use

purified water. Please do not add the water in the atomization outlet.

Method B

Lift the main unit of the humidifier up and fill purified water directly from top

of the water tank.

Atomization Outlet Main Unit Cover

Purified

Water

Purified Water

Page 7 

OPERATION INSTRUCTIONS

Buttons Operation

On/Off

Atomization

adjustment

Timing button

1. Shortly press this button to enter the on/idle state.

2. In the on/idle state, press and hold 3 seconds till hear “be-

ep”, the WIFI signal on the screen will blink and enter the

CARRO HOME APP connection mode.

Under working conditions, the humidity and atomization

amount can be set to three levels (small, medium and large).

Press and hold till hear "beep" to enter sleep mode, the

display light will be turned off, and the atomization amount

level automatically switched to level 1 (small).

1.Shortly press in the working conditions, you can cycle to

set the timer function.The timer setting can be 0h→1h→

2h→4h→8h→0h.

2. In the process of setting, the setting timer time will be

displayed first, and then if you do not operate, the timer

will flash 3 times and then switch to display the humidity

of the current environment.

3.The timer time displays in a countdown way. After setting

the timer, if you press the timer button again, the operation

screen will display the remaining time before shutdown,

and then press the timer button again to re-set the timer.

4. After the timer is turned on, press and hold the timer button

for 3 seconds to exit the timer setting state.

NOTICE

Control Panel

• If the indoor temperature is too low or the humidity is too high, and the mist

cannot be fully diffused, it is recommended to reduce the volume of water

mist.

• When humidity setting lower than current humidity, the atomizing mist will

stop within two minutes. In the working state, if there is no operation for more

than 1 minute, the operation screen will automatically enter the light-off sleep mode

The level of atomization remains unchanged.

Operation Part

Display Part

WiFi indicator

light

Humidity On/Off

Humidity Setting. Press once will display "F", and you can

cycle to set the humidity "40%-45%-50%-55%-...-90%-F-

40%"(5%RH gradient). "F" stands for canceling the preset

humidity.

The indicator light is on when the humidifier is shortage of

water.

When connecting to the network, the indicator light is on.

01 small atomization amount

02 medium atomization amount

03 large atomization amount

0h/01h/2h/4h/8h timer

Display the humidity of the environment, such as 60%.

Page 8 

CLEANING AND MAINTENANCE

WARNING

Before cleaning or descaling, be sure to unplug the power cord.

Do not use abrasive, corrosive, or flammable cleaners (such as bleach or

alcohol) to clean any part of the humidifier.

The humidifier must regularly clean the scale and debris in the water tank

and sink. It is recommended to clean it once a week.

•

Water shortage

indicator light

• IMPORTANT TIP: DO NOT leavethe humidifier plugged in for prolonged

periods (i.e. several days or more) without use.

• This causes premature failure of the circuitry. When the humidifier is not in

use, press the control button until the light goesoff, then UNPLUG it.

Lift the main unit cover.

Fig 1 Fig 2 Fig 4 Fig 5

Atomizing Head

Assembly

Lift the main unit up in

the direction of the arrow.

Placed the main unit on the

platform and stabilize it.

Do not turn the main unit upside down.

Cleaning the outer casing

Wipe and clean the surface of the whole machine with a slightly damp soft

cloth. In case of stubborn stains, add a small drop of detergent to clean it,

and then wipe the detergent away.

Tank cleaning

First take out the main unit cover, then lift the main unit upwards, shake

the main unit slightly, so that the water in the mist guiding tube flows back

to the water tank, put the main unit aside, then pour clean water into the

water tank, and add an appropriate amount of detergent for cleaning.

Use a clean cloth to dry the inside and outside of the water tank.

Warning:Do not use a dripping soft cloth to clean the outer casing, or rinse

it with a shower.

Page 9 

Clean the outside part

of the machine.

Lift the main unit up in

the direction of the arrow.

Clean the outside part of the machine.

Do not turn the main unit upside down.

Fig 3

Fig 6

Fig 7 Fig 8

Cleaning the inside & outside of the mist guiding tube,and the

atomizing head

1. Rotate counterclockwise to unscrew connecting hose of the main unit

and the atomizing head as shown in Fig 1.

2. Hold the main unit with one hand, press the spring switch of the mist guidi-

ng tube with the other hand at the same time as shown in Fig 2, and remove

the main unit in Fig 3.

3. Rotate the lower cover of the tube clockwise to remove the cover, and

then take out the atomizing head assembly as shown in Fig 4.

4. Clean the dirt inside the tube with a long-handled soft brush(not included)

as shown in Fig 5, and then wash the tube in the sink.

5.Use a screwdriver(not included) to poke the small hole in the back of

atomizing head assembly, and take out the atomizing head for cleaning as

shown in Fig 6, and wipe the center of it with a damp soft cloth.

6.When cleaning the components of the float, first loosen the set screw,

rotate the upper shell of the float clockwise and take it out, and then take

out the foam of the float as shown in Fig 7.

7.Wipe the upper shell of the float with a clean damp cloth, use a soft brush

(not included) to clean the lower part of the float as shown in Fig 8, and then

put it in sink to clean it.

Page 10 

Foam

Inhaltsverzeichnis

Andere Carro Luftbefeuchter Handbücher

Carro

Carro ME-F800W Bedienungsanleitung

Beliebte Luftbefeuchter Handbücher anderer Marken

Boneco

Boneco H300 Bedienungsanleitung

Bionaire

Bionaire CM1 Handbuch

Air-O-Swiss

Air-O-Swiss AOS 7131 Handbuch

KING

KING K 5002 Rainbow Bedienungsanleitung

Crane

Crane EE-6902 Bedienungsanleitung

Glaziar

Glaziar Ness Bedienungsanleitung

Philips

Philips DreamStation Go Abmessungen

Honeywell

Honeywell MISTMATE HUL520BC Bedienungsanleitung

Stadler Form

Stadler Form Hera Bedienungsanleitung

Hunter

Hunter 31206 Bedienungsanleitung

TaoTronics

TaoTronics TT-AH004 Bedienungsanleitung

adorini

adorini Cigar Heaven Bedienungsanleitung

Lanaform

Lanaform Aroma Bedienungsanleitung

Aprilaire

Aprilaire 800 Series Bedienungsanleitung

Pyle

Pyle SereneLife PHUMDIF8 Bedienungsanleitung

Trotec

Trotec B 200 Bedienungsanleitung

Pure Humidifier

Pure Humidifier EC Series Bedienungsanleitung

Crane

Crane EE-864 Bedienungsanleitung
