CEL-FI GO M Bedienungsanleitung
Cel-Fi GO M is optimized for mobile applications
such as trucks, boats, and RVs. It features
the IntelliBoost™technology which allows it to
automatically adjust to the fast changing cellular
network conditions as you move. ONLY when
the signal is poor, will the Intelliboost maximizes
gain while boosting thus preventing any potential
degradation of existing cellular service.
IN THE BOX
Power Supply
Main Unit
IN THE MOBILE KIT
External Magnetic Mount
(Mag Mount) Antenna
(used as the donor)
Interior Patch
Server Antenna
Included in the Mobile Kit (MK) version:
For more information, visit: www.cel-.com
Cel-Fi GO M
Quick Start Guide
Smart Signal Booster™
Cel-Fi GO M: Smart Signal Booster
2
Basic Functionality
The Cel-Fi GO M connects to an external Donor Antenna to draw in
a cellular signal from the macro network. The Cel-Fi GO M Smart
Signal Booster nds the appropriate cellular signal, per the product’s
conguration, improves the signal, and amplies it. Improved service
is provided to the user via the Server Antenna.
NOTE: A Stationary version (“GO X”) of the product is available. Go to
cel-.com for details.
Cel-Fi WAVE Mobile App
The Cel-Fi WAVE app provides a User Interface to Cel-Fi systems.
The app’s dashboard shows the system “Boost” value. A numeric
representation mapped to the amount of Signal Gain the system
is providing. Higher is better, with nine (9) being the highest value.
Cel-Fi WAVE and Cel-Fi GO M
Your Cel-Fi GO M will automatically select the strongest cellular
signal to boost. However, you may manually congure the system
preferences using Cel-Fi WAVE. Connect to Cel-Fi GO M with a
bluetooth enabled mobile device, and manage the boost settings.
NEMA 4 Rating
The Cel-Fi GO M is NEMA 4 rated, and can be used both indoors
and outdoors.
The NEMA 4 rating provides the following advantages:
• A degree of protection against ingress of solid foreign objects
(falling dirt and windblown dust)
• A degree of protection from the ingress of water (rain, sleet, snow,
splashing water, and hose directed water)
• Equipment will be undamaged by the external formation of ice
on the enclosure
Cel-Fi GO M: Smart Signal Booster
3
Specifications:
Frequency Support Multiple variations of the product are available with
different frequency support.
Model:
G32-2/4/5/12/13M
BAND NAME DOWNLINK UPLINK
21900 PCS 1930 1990 1850 1910
4AWS-1 2110 2155 1710 1755
5850 869 894 824 849
12 700 a 729 746 699 716
13 700 c 746 756 777 787
Gain Up to 65dB system gain
Model:
G32-1/3/5/7/8/20M
BAND NAME DOWNLINK UPLINK
12100 2110 2170 1920 1980
31800+ 1805 1880 1710 1785
5850 869 894 824 849
72600 2620 2690 2500 2570
8900 925 960 880 915
20 800 DD 791 821 832 862
Gain Up to 70dB system gain
Dimensions
LENGTH WIDTH HEIGHT WEIGHT
272.5 mm 96.5 mm 43.5 mm 850 g
Power (max)
DOWNLINK TX UPLINK TX
10dBm/5 MHz (16dBm per band) 24dBm per band
Bluetooth (LE Ver 4.2)
FREQUENCY POWER
2042 – 2480 MHz 0dBm
Bluetooth: LE Ver 4.2
Bluetooth frequency: 2042 - 2480 Mhz
Environmental Operating Temp: 0 - 65C
Relative Humidity: 95%
Antenna Connectors SMA-Female
Certications 3GPP TS 25.143 Rel.10
(All variants) 3GPP TS 36.143 Rel.10
RoHS 2
BQB (Bluetooth)
NEMA-4
(G32-2/4/5/12/13 FCC
variants only) ISED
UL 62368-1:2014
CSA C22.2#62368-1
UL 50E, UL 60950-22
CSA C22.2#60950-22
(G32-1/3/5/7/8/20 IEC 62368-1:2014
variants only)EN 301 489-1 v2.1.1
EN 301 489-17 v3.1.1
EN 301 489-50 v2.2.0
EN 301 908-1 v11.1.1
EN 301 908 v11.1.2
EN 301 908 v11.1.2
EN 300 328 v2.1.1
EN 62311 (2008)
Regulation (EC) 1275/2008 (Standby and Off mode)
Regulation (EC) 278/2009 (External Power Supply)
Cel-Fi GO M: Smart Signal Booster
4
Before You Begin
Cel-Fi GO has a Donor Antenna Port and a Server Antenna Port.
They are marked on the device with icons (see illustration). It is
critical that the Donor and Server antennas are connected to the
correct port.
Cel-Fi GO M Installation
Place the Donor Antenna on the vehicle. Make sure you consider the
entire system and required cable lengths.
Donor Antenna
Install Donor Antenna
I
TIPS AND TECHNIQUES
• Install antenna at least 12 inches from any other antennas for best
performance
• Antenna should be free of obstructions
• Antenna should be away from windows (including sunroof or other
openings)
• Install 8 inches away from any people
• For best performance make sure there is 50cm of metal around the
base of the antenna.
SERVER DONOR
Install Server Antenna in the cab where coverage is needed.
Install Server Antenna
2
TIPS AND TECHNIQUES
• For best results, install Donor and Server Antennas such that there is
substantial material between the antennas. This will create isolation and
allow the system to perform at higher gain without oscillation or feedback.
• Keep Donor and Server Antennas separated/isolated from each other
for best performance.
• The power supply may not be NEMA 4 rated.
Donor Antenna
Server Antenna
Cel-Fi GO M: Smart Signal Booster
5
5Plug in Cel-Fi GO M
4Connect Donor & Server Antennas
to the Cel-Fi GO M Unit
3Mount Cel-Fi GO M
Find a good mounting location in your vehicle. Location should
have airow (for cooling) and be secure from contact with external
objects.
Make sure the unit is within cable range of the 12V power
supply on your vehicle.
Best to make sure all cable lengths support the intended
mounting location BEFORE permanent mounting.
DO NOT
plug in at
this time.
Donor Antenna
Cel-Fi GO
Server Antenna
Donor Antenna
Cel-Fi GO
Server Antenna
Donor Antenna
Server Antenna
Cel-Fi GO
12V Power Supply
6
MODEL DESCRIPTION FREQUENCY
A41-V21-100
Mobile Mag Mount 698-960 // 1710-2700 MHz
CERTIFICATION BAND SUPPORT
FCC 2/4/5/12/13/28
DONOR SERVER
3
MODEL DESCRIPTION FREQUENCY
A41-V30-100
Patch Antenna 698-960 // 1710-2700 MHz
CERTIFICATION BAND SUPPORT
FCC, CE 1/3/5/7/8/20/2/4/5/12/13/28
DONOR SERVER
3
Additional Cel-Fi Antenna options are available at www.cel-.com/antennas
MODEL DESCRIPTION FREQUENCY
A41-V21-101
Mobile Mag Mount 698-960 // 1710-2700 MHz
CERTIFICATION BAND SUPPORT
CE 1/3/5/7/8/20
DONOR SERVER
3
The following antennas are authorized to be used with Cel-Fi GO M
Smart Signal Booster:
Antenna Kitting
qsg_GO-M-Eng_17-1115
LED MEANING
Solid GREEN The unit is working properly and boosting properly.
Blinking GREEN Unit is scanning for networks to boost.
Blinking RED The unit is in an error condition. Use the Cel-Fi WAVE app to
check the error code meaning and remedy.
Solid RED The unit has a hardware error and is not booting up normally.
Cel-Fi GO M features an LED on the top face to indicate the unit’s state:
NOTE: In mobile usage, it is normal for the Cel-Fi GO M to uctuate between
scanning and boosting. The Cel-Fi GO M automatically adjusts its boost
behavior based on available signal.
User Interface
ISSUE MEANING ACTION
Continual
Blinking
GREEN
Unit is
operational, but
not attaching to a
network to boost.
• Make sure both antennas are connected
properly and are appropriate for the desired
frequencies to boost.
• Make sure the selected operator to relay is
available at your location. This can be checked
with the Cel-Fi WAVE application. If the
service is not available, it cannot be boosted.
Solid RED LED Unit is not
operational.
• Unplug and reinsert power.
• If restart has no effect, contact vendor for
remedy.
Troubleshooting
