Celestion CDX1-1430 Bedienungsanleitung

Professional Loudspeakers

Your Global Driver Solutions Partner

Celestion International Ltd, Claydon Business Park, Great Blakenham, Ipswich IP6 ONL, UK

+44 (0)1473 835300 [email protected] www.celestionprofessional.com

Celestion adopts a progressive policy and reserve the right to alter drive unit specifications and/or appearance without prior notice 08/05

CDX1-1430

General Specifications

Power rating (AES, W rms) ........................................... 50

Nominal impedance (

Ω

) ................................................. 8

Frequency range (Hz)..................................... 2000-20000

Sensitivity (dB) ............................................................ 108

Minimum crossover (Hz) ............................................ 2500

Voice coil diameter (mm/in).................................. 35.6/1.4

Diaphragm material........................................... Aluminium

Magnet material .............................................. Neodymium

Mounting Information

Width (mm/in)......................................................... 90/3.5

Depth (mm/in) ........................................................ 58/2.3

Weight (kg/lb)...................................................... 0.47/1.0

Fitting ................ Flange (2 M6 holes on 76mm, 3.0in PCD)

Throat exit (mm/in) ................................................. 25.4/1

Packed Dimensions & Weight

Single pack size W x D x H (mm/in).................90 x 90 x 60

................................................................ /3.5 x 3.5 x 2.4

Single pack weight (kg/lb) ................................... 0.75/1.7

Multi pack (24) size W x D x H (mm/in) ........ 345 x 370 x 245

............................................................ /13.6 x 14.6 x 9.6

Multi pack (24) weight (kg/lb) ............................... 12.5/28

• 50Wrms continuous power handling (AES standard) and

108dB sensitivity

• Lightweight and compact compression driver featuring

neodymium magnet

• Finite Element Analysis (FEA) used to optimise both magnet and

acoustic design

• Screw mounting adaptor available

100

120

140

160

20

40

60

80

60

80

100

120

20

40

60

80

Frequency Response and Impedance Curves

Measured - Exponential Horn 90º x 40º radiation patternMeasured - Plane Wave Tube
