Celestion CDX1-1730 Bedienungsanleitung

Professional Loudspeakers

Your Global Driver Solutions Partner

Celestion International Ltd, Claydon Business Park, Great Blakenham, Ipswich IP6 ONL, UK

+44 (0)1473 835300 [email protected] www.celestionprofessional.com

Celestion adopts a progressive policy and reserve the right to alter drive unit specifications and/or appearance without prior notice 08/05

CDX1-1730

General Specifications

Power rating (AES, W rms) ........................................... 75

Nominal impedance (

Ω

) ............................................ 8/16

Frequency range (Hz) ..................................... 1200-20000

Sensitivity (dB) ............................................................ 110

Minimum crossover (Hz) ............................................ 2200

Voice coil diameter (mm/in)................................ 44.5/1.75

Diaphragm material ............................................ PETP film

Magnet material .............................................. Neodymium

Mounting Information

Width (mm/in)......................................................... 90/3.5

Depth (mm/in) ........................................................ 58/2.3

Weight (kg/lb)...................................................... 0.75/1.7

Fitting .. Flange (2/3 M6 holes on 76/57mm, 3.0/2.24in PCD)

Throat exit (mm/in) ................................................. 25.4/1

Packed Dimensions & Weight

Single pack size W x D x H (mm/in).................90 x 90 x 60

................................................................ /3.5 x 3.5 x 2.4

Single pack weight (kg/lb) ........................................ 1/2.2

100

120

140

160

20

40

60

80

60

80

100

120

20

40

60

80

Frequency Response and Impedance Curves

Measured - Exponential Horn 90º x 40º radiation patternMeasured - Plane Wave Tube

• 75Wrms continuous power handling and 110dB sensitivity

• Neodymium magnet compression driver with 1.75" voice coil

• Designed with Sound Castle

T

M

clamping to ensure uniform pressure

on diaphragm assembly for reduced acoustic distortion

• Advanced Finite Element Analysis (FEA) tools used to create a very

light weight, high powered 1" exit compression driver

• Field repairable
