Cello Freeview C24FVP Bedienungsanleitung
24” FVP LED TV
USER Manual
Contents
Unpacking the TV / Accessories ………………………………………………………………………………………… 1
Installing / Removing the stand feet …………………………………………………………………………………. 2
Front / Right / Side view and controls ………………………………………………………………………………. 3
Rear View and Sockets ………………………………………………………………………………………………………. 3
Remote Control ……………………………………………………………………………………………………………… 4-5
Video and Audio connec�ons …………………………………………………………………………………………….. 6
Connec�ng the HDMI cable ……………………………………………………………………………………………….. 6
Connec�ng the composite cable ………………………………………………………………………………………… 7
Connec�ng a digital Audio receiver ……………………………………………………………………………………. 8
Connec�ng Headphones ……………………………………………………………………………………………………. 8
First �me installa�on ……………………………………………………………………………………………………. 9-11
Reset to Factory default …………………………………………………………………………………………………… 12
Quick remote control view …………………………………………………………………………………………………13
OSD Menus ………………………………………………………………………………………………………………… 14 -15
EPG ………………………………………………………………………………………………………………………………….. 16
Netgem TV / App ……………………………………………………………………………………………………………….17
Alexa voice setup and commands …………………………………………………………………………………18-20
Maintenance ……………………………………………………………………………………………………………………. 21
Specifica�ons / Safety warnings ………….…………………………………………………………………………… 22
Dear Cello customer
Thank you for purchasing your new 24” Freeview Play HD Television. This TV has many
features and incorporates the latest technology to enhance your viewing experience. We
recommend that you spend some �me reading this instruc�on manual in order to fully
understand these features. Hints and �ps to resolve diverse issues are also available in the
manual. Read all the safety instruc�oons carefully before use and keep this instruc� on
manual for future reference.
Unpacking / TV accessories
Television Power cable Remote
Baeries
1
ST4 x 12 3PCS
ST4 x 12 2PCS
Neck / Screws
Installing / Removing the stand feet
Parts
Television
Stand assembly instruc�ons
The Television is VESA-Compliant and designed to be wall mounted with a VESA-Compliant
200 x 100mm moun�ng kit. Mount the Television according to the instruc�ons of the wall
bracket (Not supplied)
2
ST4 x 12 3PCS
ST4 x 12 2PCS
Neck / Screws
2.Put the stand to the neck of the TV set
as shown below.
1.Place the neck in position as shown,
fix it with the supplied screws(ST4x12).
(ST4 x12 3 PCS)
3.Attach the stand with the supplied screws.
Screw size M4 x 8
200mm
100mm
Front / Side view TV bu�on controls
ITEM DESCRIPTION
1 POWER LED Illuminates Green when the TV is turned on.
Illuminates Red when the TV is in Standby.
2 IR (Infrared Receiver) Receives IR Signals from the remote control.
Do not block the sensor.
3 VOL+/- Adjusts the Volume
4 CH+/- Selects channels
5 MENU Displays the on screen display
6 SOURCE Select from NETGEM/HDMI1/HDMI2/AV/USB
7 STANDBY Turns the Television ON and OFF
Rear view sockets
SOCKET DESCRIPTION
1 HDMI INPUTS Connect to external devices via HDMI cable
2 AV Connect to external devices via AV cables
3 HEADPHONE Connect to Headphones
4 USB Connect to a USB storage device and play media files
5 OPTICAL AUDIO OUTPUT Digital audio output to sound system
6 USB For service and maintenance use only
7 COAX AUDIO OUTPUT Digital audio output to sound system
8 RJ45 (ETHERNET) Connect to the internet
9 TV Aerial Connect to the domes�c aerial socket
3
Installing Batteries in the Remote control
1. Insert 2 x 1.5V AAA batteries making sure to match the (+) and (-) ends of the batteries with
the (+) and (-) ends shown in the batterie compartment.
2. Close the batterie compartment cover.
The Remote-Control Operation Range
5 Meters is the normal distance recommended between the Remote control and the TV IR
sensor and within 60° in front of the TV (See diagram). The operating distance may vary
depending on the brightness of the room.
4
@tv access to
netgem.tv avenue
POWER
ON/OFF
NOT IN USE
TV GUIDE
OPEN THE EPG
Search
Access to Search Avenue
PLAYBACK CONTROLS
REWIND, PLAY/PAUSE
STOP & FORWARD
CHANNEL UP/DOWN
PAGE UP/DOWN IN EPG
EXIT
RETURN TO LIVE TV
HOME
RETURN TO MAIN MENU
FPLAY
FREEVIEW EXPLORE APP
SMART TV MENU
CHANGE AUDIO SOURCE
(Depending on Devices）
VOICE CONTROL
Pair a device
MUTE
MUTE AUDIO FROM ANY SOURCE
VOLUME
UP/DOWN
4-WAY NAVIGATION
OK TO SELECT
STEP BACK
GO BACK TO LIVE TV FROM HOME
MORE INFO
OPEN PROGRAMME CARD
DELETE
TURN ON SUBTITLES
IN FULL-SCREEN PLAYBACK NUM-PAD
CHANNEL NUMBER &
TEXT INPUT
Remote control
5
Video and Audio connec�ons
This TV supports High-Defini�on Mul�media Interface (HDMI) and High-Bandwidth Digital
Content Protec�on (HDCP) Protocol.
Always connect a device to the TV with the highest quality connec�on available. Also, use
good quality cables to ensure a good transfer of picture and sound.
An HDMI connection has the best picture and sound quality. One HDMI cable combines
video and audio signals.
Connec�ng an AV device with HDMI cable
Audio/Video
devices:
HDMI1 & HDMI2
After connecting to an external device (Blu-ray disc player, Game console, Set-top box, or personal
computer) with the HDMI cable. Select the HDMI in the source menu and the TV will automa�cally
detect the resolu�on coming from the device. For the best picture quality adjust the device output
resolution up to 1920 x 1080.
6
Connec�ng an AV device with a composite cable
Connect the Television to an AV device with the RED = Audio Right / YELLOW = Video /
WHITE = Audio LeCinch connector composite cable. Select the AV source on the Television
to view content from the aached device.
7
L RVIDEO / Media
Connecng a digital audio receiver
For a beer sound quality, you may want to listen to the TV audio output through your
Home Sound System or Sound bar. The TV is fitted with an Opcal Digital Audio Output.
When purchasing a cable, it must be an Opcal cable. When the Opcal cable is
connected to both devices select the source mode opcal on the Sound system or Sound
bar.
Connecng Headphones
Connect the headphones to the TVs headphone socket. Before using the headphones
make the volume is low and then increase to a comfortable listening level.
Long term exposure to loud music may cause hearing damage. It is best to avoid
extreme volume when using earphones, especially for long lengths of me.
8
L RVI D E O / Media
L RVI D E O / Media
