CDS COOLED Z6 USER GUIDE

CDS Cooled Z6

User Guide

Version1.05

August2019

PAGE / CENTRALDS1 11

CDS COOLED Z6 USER GUIDE

Contents

*ThankyouforpurchasingaCentralDSproduct.

CDS Cooled Z6 1

User Guide 1

Version 1.05 1

August 2019 1

Introduction 3

Informations of product 3

Camera usages 3

Package contents 4

Camera operation and responsibility 4

Handling precaution 4

Nomenclature 6

Taking Pictures 6

You can operate the camera with the following instruction. 6

Using with Telescope 6

Characteristics of the modification 8

Safety of the User and the Camera 9

Product Warranty 10

CDS Cooled Z6 system Chart 11

PAGE / CENTRALDS2 11

CDS COOLED Z6 USER GUIDE

Introduction

CDS Cooled Z6 is a cooled camera that modiﬁed Z6 of Nikon.We took out the image sensor from

the inside of camera body and attached a TEC cooling module on to it and made it to a high

performance Astronomical cooled camera.The image sensor can be cooled maximum -18℃( ±

2℃) below ambient by the installed TEC cooling module.

Informationsofproduct

＊Cool down the temperature of CMOS sensor 18 Celsius degree(±2℃) from that of ambient air.

＊Absolutely high-Quality image in B-shutter use compared with usual unmodiﬁed DSLR

＊Realtime Monitoring of the cooling temperature by digital thermometer

＊Drop-in ﬁlter system

＊Use of high efﬁciency

Thermo electric cooler

module

＊Power: 12V, 1.0A DC

＊Low Pass Filter

Removed.

＊Optimal design by 3D

CAD modelling

＊Precision manufacturing

by CNC machine

＊Perfect tuning of optical

axis of CMOS sensor by 3

point alignment

＊Permanent Anti-dew

system applied.

＊Hoya MC Clear Filter"

Installed

* Internal Silent cooling fan

installed

* Live-view Focus function

alive.

＊Disabled function:Low

Pass Filter, Mechanical shutter, Sensor Cleaning, Body to Lens communication(AF, Aperture

Control), Image Stabilization

＊Net weight: 1,050g

Camerausages

Youwillgetusedtothiscameraandunderstandthecamerabetterwhilereadingthismanualandtaking

testimages.Pleaseread‘Handlingcaution’and‘Safetyoftheuserandthecamera‘thoroughlytoprevent

anyaccidentsordamagestothecamera.

PAGE / CENTRALDS3 11

CDS COOLED Z6 USER GUIDE

Packagecontents

Pleasecheckfollowingdevicesandaccessoriesareallincludedinthepackage.

Ifanythingismissing,pleasecontactCentralDSorthedealerthatyoupurchasedfrom.

1. CDS Cooled Z6body

2. FRM72/BaseAdapter(M72x0.75mmpitchMaleThread)

3. CM2C/Drop-InFiltersystem+CanonEFMount,or(CM2N/Drop-InFiltersystem+NikonFMount)

4. DFH48/48mm(2”)FilterHolder(*52mmFilterthreadincluded)

5. FR1/FieldRotator(M72x0.75mmpitchMaleThread)

6. ECR48/AdapterforWideTthread(M42x0.75mmPitchFemaleThread)

7. ECR54/AdapterforTakahashiTelescope(M54x0.75mmPitchMaleThread)

8. DTH-1/DigitalThermometer

9. CT18/ThermometerCable

10. PSC2/USBpowercable(for5VInput,3.5mm/1.4mmBarrel)

Cameraoperationandresponsibility

You can record the images to the storage(XQD Memory Card) of this camera. CentralDS will not be

responsible for any inconvenience or loss due to failure of storing images to XQD Memory Card or

defectiveimagesstoredinthecard.

Youcanusethiscameraforpersonaluseanywhereintheworld.

Handlingprecaution

PAGE / CENTRALDS4 11

CDS COOLED Z6 USER GUIDE

•This camera is a high precision device. Please do not drop and avoid any physical impact against

camera.

•Ifyoudropthecamerainwater,wipeoffanywaterdropletsfromthecamerawithadryclothand

contactCentralDS([email protected])

•Donotleavethecameraunderthedirectsunlight.Hightemperaturecandamagethecamera.

•Donotdisassemblethecamera.

•Do not touch Parallelism Alignment Screws (3 pieces of M4 headless screws) on the beneath of

FRM72.

•If the Parallelism Alignment Screws were adjusted by

personnelnotauthorizedbyCentralDS,thewarrantywillbe

voided.

•Pleaseuseadustblowertoremovedustsonthefilter.

•Do not disassemble the filter. If the airtight sealing is

damaged,dewcanforminsidethecamera.

•If the camera is disassembled by personnel not

authorized by CentralDS, the warranty will be

voided.

•Thiscameraisnotwaterproof.Donotleavethe

camera attached to a telescope with [ cooling

systemoff]forlongtime.Dewcanformonthe

surfaceofthecameraandthiscandamagethe

camera.**

•Ifcondensationformsonthecamera,donotusethecamera.

•Ifthecameraissuddenlybroughtinfromthecoldintoawarmroom,condensationmayformonthe

cameraandinternalparts.Topreventcondensation,firstputthecamerainasealedplasticbagand

letitadjusttothewarmertemperaturebeforetakingitoutofthebag.

•Store the camera in a sealed container with desiccants (i.e. Silica gel) or cool, dry, well ventilated

location.

•Imagesensordust–CentralDStestseachcamerawithtestexposurestochecktheimagesensoris

dust free before shipping. However about 2 – 4 % of the customer reported dusts on the image

sensor. If you see marks on your image due to the dusts on the image sensor, please contact

CentralDSforservicing.Donotdisassemblethecameratocleanthedusts.

•Cautionwiththecoolingsystemactivated–theTECcoolingsystemfortheimagesensorisdesigned

to emit substantial amounts of heat to outside. This does not cause any problem on the camera

operationbutaminorburncanbecausedifskiniscontactedwiththecoolingsystemforextended

periodtime.

PAGE / CENTRALDS5 11

CDS COOLED Z6 USER GUIDE

Nomenclature

Taking Pictures

Youcanoperatethecamerawiththefollowinginstruction.

UsingwithTelescope

1. AttachfirmlythecameratoTelescopeusingFR1+ECR48orECR54.

2. InsertaFilterinDrop-InFilterHolder.(**veryimportanttomaintainBackFocusDistance)

3. ConnectUSBpowercables(PSC2->TECPowerIn)andtemperaturesensorcable(CT18).

4. ConectDC5VtoPSC2(USBChargerforsmartPhone/5VPowerBank).

5. InsertLi-ionBattery(EN-EL15b)toZ6batteryslot.PowerOnNikonZ6Body.

6. ChecktheworkingofZ6camerabodyandcoolingmodule.

7. Check the cooling temperature. Within 7~10minutes the temperature of CMOS will drop to

maximumcooledtemperature.

PAGE / CENTRALDS6 11

CDS COOLED Z6 USER GUIDE

8. Using[Liveview]modeofcamerafindthesubjectandadjustthefocus.

9. Taketheshots.

*CoolingModuleofCDSCooledZ6hasnoON/OFFswitch.WhenyouconnecttheDCpowertocooling

module,TECcoolingbecomeONatthesametime.

*CDSCooledZ6hasnoTemperaturecontroller.WhencoolinggetreachtostableconditiontheCMOS

temperaturewillbeit’smaximumcoolingstate.

*Back Focus Distance of CDS Cooled Z6 is 44mm(CM2C: for Canon Mount) /46.5mm(CM2N: for

NikonMount),ThesearesametoCanonEF-mountorNikonF-mount,andadjustedattheconditionof

2mmthicknessglassfilterinstalledatthedrop-infilterholder.Ifyoutaketheshotswiththecameralens,

incaseofnofilterindrop-infilterholder,infinityfocusingerrorwillbeoccurred.Werecommendtoinstall

afilter(2~3mmthickness)intodrop-infilterholderalways.

(Recommendedfilters:HoyaMCClear,BaaderUV/IRcut,IDASLPSP2etc)

*IncaseofBaader2”filters,youcanuseonlyLowProfileFilterCell(LPFC)products.

*TECcoolingmodule ismore efficientwhen theambienttemperature ishigh butthe efficiencyislower

when the temperature is low in the winter. This is due to the electricity consumption per temperature

characteristicsofthePeltierelementswhichisoneofthemostimportantpartsintheTECcoolingmodule.

Asaresult,thecooledimagesensortemperaturemaynotreachtomaxcoolingtemperatureof[product

information]inthewinterseason.

*ThecameratemperatureshowinginBackyardNikonorotherAstroimagingprogramsisnottheactual

sensor temperature but the temperature at the temperature sensor installed on the PCB circuit board

placedbehindtheimagesensor.

**ThetemperaturevaluedisplayedatDTH-1isfromthetemperatureoncoldfingerandit’sneartoreal

CMOStemperatureandthetemperaturethatAstroimagingprogramsisdisplaying(fromcamera’sexif

data)isabout3-7Chigherthanthisvalue.

*Ifthecameraisexposedtotheairoutsidewiththecoolingmoduleoffforextendedperiodoftime,the

cameracanbeinternallydamagedduetoproblemssuchasshortcircuitscausedbycondensation.

*Ifyouhavetoleavethecameraoutsideforextendedperiodoftime,coverthecamera

withthedewshieldcoverassoonasturningoffthecooler.

PAGE / CENTRALDS7 11

CDS COOLED Z6 USER GUIDE

Characteristics of the modiﬁcation

•CDSCooledZ6ismodifiedversionsofNikon’sgeneralpurposeMirror-lesscameras.

SomeoforiginalfeaturesofNikoncamerawereremovedandnewfeaturessuchas

TEC cooling and Drop-In filter holder System are added for high quality

astrophotography.Followingsarethedifferencesmadebythemodification.

1. LowPassFilteroforiginalCMOSsensorwasremoved.

2. InCDSCooledZ6HoyaClearfilterinstalled,andimage

blurringcanoccurduetochromaticaberrationonIRlights

recorded on the sensor so the image sharpness can

suffer.Thisismorepronouncedintheimagestakenwith

refraction optics than reflection optics. We recommend

youtoinstall inDrop-In filterholder UV/IRcutfilter, light

pollutionfilter and deep sky filter atthe same time while

imaging.MostAstronomicalfilterscutIRlightandwillhelp

toremoveIRhaloorblurring.

3. With CDS Cooled Z6, you can take IR images by

mounting a visible light blocking / infrared transmitting

filtersuchasaHoyaR72filter.

4. Various2”imagingfiltersor52mmfilterscanbemountedintheDrop-Infilterholder(DFH48).

PAGE / CENTRALDS8 11

CDS COOLED Z6 USER GUIDE

5. Drop-InFiltersystemofCM2C/CM2Ndoesnothavethelenscommunicationelectriccontactpoints

sotheautofocus,lensinformationrecordingandpulsesignaltransferformotoroperationwhichare

based on the communication between the camera body and the lens are disabled even when a

Cameralensisused.

6. IncaseofDrop-InFiltersystemofCM2C/CM2Nyoualwayshavetofocuslensesmanually.Some

lenses need power from the body for manual focusing and you cannot focus these lenses even

manuallywhentheyaremountedonAstroZ6.

7. ElectricViewFinderisaliveasbeforemodification.

8. In mechanical shutter mode, Shutter speed control of CDS Cooled Z6 is not valid in sub-second

exposure,onlyvalidinBulbShuttermode.Butin[Silentphotography]modeON,youcantakephoto

inallshutterspeed.

SafetyoftheUserandtheCamera

Follow these safeguards and use the equipment properly to prevent injury and

equipmentdamage.

1. Donotleavethepoweradapterandthepowercordnearanobjectemittingheat.Thiscancause

fireduetodeformationanddamageoftheinsulator.

2. Donotusethecameranearinflammablegas.

3. Iftheinternalpartsofthecameraareexposedafterthecameraisdroppedorthecamerahousingis

damaged,donotconnectthepowertothecameraduetodangerofanelectricshock.

4. Donotdisassemblethecamera.Itcancauseanelectricshock.

5. Keepthecamerafromthereachofsmallchildren.

6. Donotusetheequipmentindustyorhumidplaces.Thisistopreventfireandelectricalshock.

7. Do not use the camera with medical equipments. The electromagnetic interference can cause

malfunctionofthemedicalequipments.

8. Topreventfireandelectricalshock,followthesafeguardsbelow:

•Alwaysinsertthepowerplugallthewayin.

•Donothandleapowerplugwithwethands.

•Donotexcessivelybendthecord.

•Donotputaheavyobjectonthepoweradapterandcord.

•Donotconnecttoomanypowerplugstothesamepoweroutlet.

•Donotuseacordwhoseinsulationhasbeendamaged.

•Ifthesurroundingnearthepoweroutletisdustyorhumid,thepoweroutletcanbeshort

circuited.Cleananddrythesurroundingbeforeusingtheequipment.

•Donotusethecamerainsideacarunderthehotsun,underthedirectsunlightornearaheat

source.Thecameracanbedamagedorcausesskinburns.

•Donotusepaintthinner,benzene,acetoneorotherorganicsolventstocleantheequipment.

Doingsomaycausefireorahealthhazard.

PAGE / CENTRALDS9 11

CDS COOLED Z6 USER GUIDE

ProductWarranty

CentralDSProvides1yearproductwarrantyforcustomerswhopurchasesbrandnew

CDSCooledZ6.

Incaseof[Usersuppliedcameramodificationservice],CentralDSoffers60days

productwarranty.

PAGE / CENTRALDS10 11

Inhaltsverzeichnis

Andere CentralDS Kamerazubehör Handbücher

CentralDS

CentralDS Astro D850 Bedienungsanleitung

Beliebte Kamerazubehör Handbücher anderer Marken

Viltrox

Viltrox EF-NEX Montageanleitung

Calumet

Calumet 7100 Series CK7114 Bedienungsanleitung

Ropox

Ropox 4Single Series Bedienungsanleitung

Cambo

Cambo Wide DS Digital Series Betriebsanleitung

Samsung

Samsung SHG-120 Bedienungsanleitung

Ryobi

Ryobi BPL-1820 Bedienungsanleitung

Aegis

Aegis ABL-36020P Bedienungsanleitung

Pentax

Pentax Data Back Fc Bedienungsanleitung

Fantasea

Fantasea EyeGrabber F Series Bedienungsanleitung

Honeywell

Honeywell HDZ20HD Bedienungsanleitung

EGO

EGO BA1400T Bedienungsanleitung

Sima

Sima SRW-62 Bedienungsanleitung

Shape

Shape A7SSMKIT Bedienungsanleitung

Slide Kamera

Slide Kamera HST-2 Bedienungsanleitung

Power works

Power works 2902613 Bedienungsanleitung

SES

SES SE-2047-2 Bedienungsanleitung

Olympus

Olympus PT-EP05L Bedienungsanleitung

Starlite

Starlite OctoDome nxt Bedienungsanleitung
