GC-318BMotherboard

Note to Users

ThisUser’sGuide&TechnicalReferenceareforassistingsystem

manufacturers and end users in setting up and installing the

motherboard.Everyefforthasbeenmadetoensurethattheinfor-

mation in thismanual is accurate. Champion-First Electronics

Limitedisnotresponsibleforprintingorclericalerrors.Informa-

tioninthisdocumentissubjecttochangewithoutnoticeanddoes

notrepresenta commitmentonthepartof Champion-First.For

previousorupdatedmanuals,BIOS,drivers,orproductrelease

information,pleasecontact Champion-First ElectronicsLimited

at http://www.champion-first.com or through any of the means

indicatedonthefollowingpages.

Companiesandproductsmentioned in this manual areforiden-

tificationpurposes only.Productnamesappearing inthismanual

may or may not be registered trademarks or copyrights of their

respectiveowners.

WebSite: http://www.champion-first.com

Email: [email protected]

ProductName: GC-318B

Version: 1.00

Edition: April,2001

GC-318BMotherboard

Page 2

Taa

abb

ble ofle of

le ofle of

le of ContentsContents

ContentsContents

Contents

Chapter 1 Introduction .......................................................3

1.1 Product Features ................................................................ 3

1.2 Features Summary ............................................................. 3

Chapter 2 Installation ......................................................... 4

2.1 InstallationInstructions ....................................................... 4

2.2 MotherboardLayout ............................................................ 5

2.3 Jumper Setting.................................................................... 6

2.4 Function & Installation Instructions...................................... 9

2.4.1ATPowerSupplyConnector........................................... 9

2.4.2ATXPowerSupply Connector ......................................... 9

2.4.3ATKeyboard Connector ................................................. 10

2.4.4Serial(COM1/COM2) PortConnector .............................. 10

2.4.5USB Connector .............................................................. 10

2.4.6PS/2Mouse Connector .................................................. 10

2.4.7Infra-RedConnector........................................................ 10

2.4.8 Reset Switch.................................................................. 10

2.4.9HDD Led ........................................................................ 10

2.4.10Speaker Connector....................................................... 10

2.4.11 Keyboard Lock Switch.................................................. 10

2.4.12Parallel Port Connector ................................................ 11

2.4.13 SDRAM Sockets.......................................................... 11

2.4.14 PCI Slot ....................................................................... 12

2.4.15 ISA Slot ....................................................................... 12

2.4.16FloppyDriveConnector ................................................ 12

2.4.18BIOS ............................................................................ 12

2.4.19ZIFCPU Socket ........................................................... 13

2.4.20CPU Fan Connector ..................................................... 13

Chapter 3 Software Installation.......................................... 14

Chapter 4 AMI BIOS Setup .................................................15

4.1 Standard CMOS Setup ....................................................... 17

4.2 AdvancedCMOSSetup ...................................................... 19

4.3 AdvancedChipsetSetup ..................................................... 19

4.4 PowerManagementSetup .................................................. 19

4.5 PCI/PnP Setup.................................................................... 19

4.6 CPUConfiguration Setup..................................................... 19

4.7 Save Settings and Exit........................................................ 19

4.8 Exit Without Saving............................................................. 19

Page 3

GC-318BMotherboard

Chapter 1

Introduction

1.1 Product Features

The Intel 430VX highest performance motherboard is based on the

all new Intel 430VX chipset with Baby AT form factor to support the

latest Socket 7 including Intel Pentium, AMD K5 / K6 as well as Cyrix

6x86 / 6x86MX processors.

1.2 Features Summary

ThisMotherboardcomes with followingfeatures:

SupportIntelPentium/PentiumwithMMXtechnology,Cyrix6x86/6x86MX,

AMD K5/K6 using Socket 7

Intel430VXChipset

Two DIMM slots Supportingupto64MB Memory Capacity

Support3.3V EDO and SDRAM DIMM

3 x PCI slots, 2 x ISA slots

2x USB ports, 1 xPS/2mouse port, 1 xPS/2Keyboard port, 1 xIrDAport

1 x FDD port, 1 x LPT port, 2 x COM ports

DualIDE ChannelsSupporting FourUltra-DMA33IDE Devices

AdvancedConfigurationPowerInterface(ACPI) Ready.

1MBBIOS, PC99/ACPI/DMI Compliant

AT/ATXPowerSupplyInterface

Baby AT format, 220mm x 173mm PCB

GC-318BMotherboard

Page 4

Chapter 2

Installation

2.1 Installation Instructions

Thissection covers ExternalConnectorsand MemoryConfiguration.Please

refer to the motherboard layout chart for external connectors, slots and I/O

ports. Furthermore, this section lists all necessary connector pin assign-

mentsfor your reference.Thelocations of theconnectors and portsareillus-

tratedin the following figures.Beforeinserting these connectors, pleasepay

attention to the orientations.

NOTICE!!!

1. Makesure to unplug yourpower supply while addingorremoving

system components

2. Alwayswork onanantistatic surfaceto avoidpossibledamage tothe

motherboardor other components fromstaticdischarge.

Page 5

GC-318BMotherboard

PRIMARYIDE(IDE1)

PCI3

PCI2

DIMM1

DIMM2

AT KB Connector

Socket 7

ISA2

PRINTER

USB

COM2

COM1

ISA1

PCI1

430VX

1 1 1 1 1

1 1

JP10

JP9

J17

J16

J15

J14

J13

P45

P41

P42

JP43

2.2 Motherboard Layout

JP10

JP9

JP44-Fan

J3-KB Lock

J11-Speaker

JP18-Fan

JP15-Suspend

JP14-HDD LED

JP19-Reset

JP1-PWR_SW

J10-IR Connector

JP4

JP2

JP3

JP45

JP41

JP42

J17

J16

J15

J14

J13

GC-318BMotherboard

Page 6

PRIMARYIDE(IDE1)

PCI3

PCI2

DIMM1

DIMM2

AT KB Connecto r

Socke t 7

ISA2

PRINTER

USB

COM2

COM1

ISA1

PCI1

43 0V X

430VX

1 1 1 1 1

JP10

JP 9

J17

J16

J15

J14

J13

P45

P41

P42

JP 4 3

CPUTypeselection:

CPUType&Speed Ratio Bus Freq. RatioJumper

JP42 JP41 JP45 JP3 JP2 JP4

IntelPentium-233 3.5x 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [1-2]

IntelPentium-200 3.0x 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

IntelPentium-166 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

Cyrix6x86MX-PR200GP 166MHz 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

Cyrix6x86MX-PR166GP 150MHz 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

AMD-K6-PR2-233 3.5X 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [1-2]

AMD-K6-PR2-200 3.0X 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

AMD-K6-PR2-166 2.5X 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

AMD-K5-PR200 3.0X 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

AMD-K5-PR166 2.5X 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

JP45

JP41

JP42

2.3 Jumper Setting

Remark: Open Close

CPU External Clock(BUS) Frequency Selection

JP45

JP41

JP42

JP45

JP41

JP42

HCLK: 66.8MHz 75MHz 75MHz

PCICLK: 33.4MHz 37.5MHz 32MHz

2.5x3.0x3.5x4.0x4.5x5.0x5.5x

(2/5)(1/3)(2/7)(1/4)(2/9)(1/5)(2/11)

JP4

JP2

JP3

CPU : BUS Frequency Ratio

JP4

JP2

JP3

JP4

JP2

JP3

JP4

JP2

JP3

JP4

JP2

JP3

JP4

JP2

JP3

JP4

JP2

JP3

Page 7

GC-318BMotherboard

CPUTypeselection:

CPUType&Speed Ratio Bus Freq. RatioJumper

JP42 JP41 JP45 JP3 JP2 JP4

IntelPentium-233MMX 3.5x 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [1-2]

IntelPentium-200MMX 3.0x 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

IntelPentium-166MMX 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

IntelPentium-200 3.0x 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

IntelPentium-166 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

AMD-K6-III/550 5.5X 100MHz [1-2] [1-2] [1-2] [1-2] [1-2] [2-3]

AMD-K6-III/500 5.0X 100MHz [1-2] [1-2] [1-2] [1-2] [2-3] [2-3]

AMD-K6-III/450 4.5X 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [2-3]

AMD-K6-III/400 4.0X 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [2-3]

AMD-K6-2/550 5.5X 100MHz [1-2] [1-2] [1-2] [1-2] [1-2] [2-3]

AMD-K6-2/500 5.0X 100MHz [1-2] [1-2] [1-2] [1-2] [2-3] [2-3]

AMD-K6-2/450 4.5X 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [2-3]

AMD-K6-PR2-233 3.5X 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [1-2]

AMD-K6-PR2-200 3.0X 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

AMD-K6-PR2-166 2.5X 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

AMD-K5-PR200 3.0X 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

AMD-K5-PR166 2.5X 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

IBM/CyrixMII-PR366 2.5x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [1-2]

IBM/CyrixMII-PR333 3.0x 83MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

IBM/CyrixMII-PR300 3.0x 75MHz [1-2] [1-2] [2-3] [1-2] [2-3] [1-2]

IBM/CyrixMII-PR300 3.5x 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [1-2]

IBM/Cyrix6x86MX-PR233 3.0x 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [1-2]

IBM/Cyrix6x86MX-PR200 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

Cyrix6x86MX-PR166GP 2.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [1-2]

150MHz

Remarks:

- 83MHz & 100MHz Bus Frequency is NOTsuported

GC-318BMotherboard

Page 8

CPUTypeselection:

CPUType&Speed Ratio Bus Freq. RatioJumper

JP42 JP41 JP45 JP3 JP2 JP4

AMD-K6-III/550 5.5x 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [2-3]

AMD-K6-III/500 5.0x 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [2-3]

AMD-K6-III/450 4.5x 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [2-3]

AMD-K6-III/400 4.0x 66MHz [1-2] [2-3] [2-3] [2-3] [1-2] [2-3]

AMD-K6-III/550 5.5X 75MHz [1-2] [1-2] [2-3] [1-2] [1-2] [2-3]

AMD-K6-III/500 5.0X 75MHz [1-2] [1-2] [2-3] [1-2] [2-3] [2-3]

AMD-K6-III/450 4.5X 75MHz [1-2] [1-2] [2-3] [2-3] [2-3] [2-3]

AMD-K6-III/400 4.0X 75MHz [1-2] [1-2] [2-3] [2-3] [1-2] [2-3]

AMD-K6-2/550 5.5X 66MHz [1-2] [2-3] [2-3] [1-2] [1-2] [2-3]

AMD-K6-2/500 5.0X 66MHz [1-2] [2-3] [2-3] [1-2] [2-3] [2-3]

AMD-K6-2/450 4.5X 66MHz [1-2] [2-3] [2-3] [2-3] [2-3] [2-3]

AMD-K6-2/400 4.0X 66MHz [1-2] [2-3] [2-3] [2-3] [1-2] [2-3]

AMD-K6-2/550 5.5X 75MHz [1-2] [1-2] [2-3] [1-2] [2-3] [1-2]

AMD-K6-2/500 5.0X 75MHz [1-2] [1-2] [2-3] [1-2] [2-3] [2-3]

AMD-K6-2/450 4.5X 75MHz [1-2] [1-2] [2-3] [2-3] [2-3] [2-3]

AMD-K6-2/400 4.0X 75MHz [1-2] [1-2] [2-3] [2-3] [1-2] [2-3]

Remarks:

- 83MHz & 100MHz Bus Frequency is NOTsuported

Page 9

GC-318BMotherboard

Thisjumperis used for adjusting CPUworkingvoltage, for this motherboard

design it can auto detect the single voltage CPU or dual voltage CPU.

Thetable of CPUvoltage selection

CoreVoltage J17 J16 J15 J14 J13

2.1V [1-2] [1-2] [1-2] [1-2] [2-3]

2.2V [1-2] [1-2] [1-2] [2-3] [1-2]

2.4V [1-2] [1-2] [2-3] [1-2] [1-2]

2.8V [1-2] [2-3] [1-2] [1-2] [1-2]

2.9V [1-2] [2-3] [1-2] [1-2] [2-3]

3.0V [1-2] [2-3] [1-2] [2-3] [1-2]

3.1V [1-2] [2-3] [1-2] [2-3] [2-3]

3.2V [1-2] [2-3] [2-3] [1-2] [1-2]

3.5V [1-2] [2-3] [2-3] [2-3] [2-3]

J17

J16

J15

J14

J13

PRIMARYIDE(IDE1)

PCI3

PCI2

DIMM1

DIMM2

AT KB Connecto r

Socke t 7

ISA2

PRINTER

USB

COM2

COM1

ISA1

PCI1

43 0V X

430VX

1 1 1 1 1

JP10

JP 9

J17

J16

J15

J14

J13

P45

P41

P42

JP 4 3

2.1V 2.2V 2.4V 2.8V 2.9V

3.0V 3.1V 3.2V 3.5V

J17

J16

J15

J14

J13

CMOS Clear - JP43

JP43 CMOS

(1-2) CMOSClear (momentarily)

(2-3) Normal(Default)

CPU Core Voltage Selection - J13,J14,J15,J16,J17

Remark: Open Close

GC-318BMotherboard

Page 10

2.4 Function & Installation Instructions

2.4.1 AT Power Supply Connector (12-Pin)

This connector connects to a standard AT power supply. To connect the

leads from the power supply, ensure first that the power supply is not power

on.Most powersuppliesprovide twoplugs, andeachplug containssixwires.

Two of six wires are black and please orient the plugs to the connector so

that 4 black wires are together.

AT Power Connector

At a slight angle, align the plastic guide pins on the lead to their recep-

tacles on the connector. Once aligned, press the lead onto the connector

until the lead locks into place.

2.4.2 ATX Power Supply Connector (20-Pin)

Thisconnectorconnects to an ATX power supply.Theplug from ATXpower

supply will only insert in one orientation because of the different hole sizes.

Find the proper orientation and push down firmly making sure that the pins

are aligned. The system power can be turned off through software control,

like the shut down in Windows 2000 / ME / 98 / 95 start menu. Power man-

agement must be enabled in the system BIOS in order to activate this soft-

off feature. Once the system BIOS receives the power management com-

mand from the OS, it will switch the system power off.

ATX Power Connector

+3.3V

-12V

Ground

PW_ON

Ground

-5V

+5V

Power Connector on

Motherboard

+3.3V

Ground

+5V

Ground

+5V

Ground

PWRGOOD

+5VSB

+12V

+5V

+12V

-12V

Ground

-5V

+5V

Red

White

Black

Blue

Yellow

Red

Orange

Power Plug Power Plug

Power Plugs

fromPower

Supply

Power

Connector on

Motherboard

Inhaltsverzeichnis

Andere Champion-First Electronics Hauptplatine Handbücher

Champion-First Electronics

Champion-First Electronics GC-8601 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
