Please read this manual carefully before operating the device and keep it at hand for future reference.

R220+

WATERPROOF FOOD SERVICE SCALE

USER MANUAL

www.charder.com

R220+ Waterproof Food Service Scale

CONTENTS

INTRODUCTION ---------------------------------------------------------------------------- 2

SAFETY PRECAUTIONS --------------------------------------------------------------------2

DISPOSAL -------------------------------------------------------------------------------------2

LIMITED WARRANTY ----------------------------------------------------------------------3

MAINTENANCE ----------------------------------------------------------------------------- 3

PACKAGING ----------------------------------------------------------------------------------4

INSTALLATION ------------------------------------------------------------------------------ 5

OPERATION ----------------------------------------------------------------------------------6

ERROR MESSAGES ------------------------------------------------------------------------- 7

TROUBLESHOOTING ---------------------------------------------------------------------- 7

SETTINGS CONFIGURATION -------------------------------------------------------------8

SCALE CALIBRATION ---------------------------------------------------------------------- 9

SPECIFICATIONS -------------------------------------------------------------------------- 10

R220+ Waterproof Food Service Scale

INTRODUCTION

This user manual will guide you through the correct operating procedure for the

R220+ Waterproof Food Service Scale. Please read this manual thoroughly

before operation and keep it at hand for future reference.

R220+ Waterproof Food Service Scale Maximum Weight Capacity: 3000g

SAFETY PRECAUTIONS

Please follow these safety precautions:

XDO NOT insert liquids or foreign object.

XDO NOT operate the scale in hostile environments.

XDO NOT drop loads/leave permanent load on the platform.

XDO NOT place the scale upside down.

XDO NOT open the scale. Attempts to make repairs might cause injuries.

Product warranty considered void if this stipulation is ignored.

The scale must only be repaired by authorized personnel.

Verify power adapter input voltage matches the local power supply.

Risk of explosion can occur if battery is replaced with the wrong type or

connected improperly. Do not disassemble, repair or otherwise manipulate the

battery socket.

Obey local laws and regulations on battery disposal.

DISPOSAL

In conformance with the European Directive 2002/96 EC on Waste Electrical

and Electronic Equipment (WEEE), this device may not be disposed of with

domestic waste.

This also applies to countries outside the EU, according to their specific

requirements.

Please dispose of this product in accordance with local regulations at the

collecting point specified for electrical and electronic equipment.

For more detailed information about recycling this product, please contact the

local distributor from which you purchased this device.

R220+ Waterproof Food Service Scale

LIMITED WARRANTY

What does the Warranty Cover?

This scale is warranted from date of purchase against defects of materials or in

workmanship for a period of one (1) Year from the date of purchase.

Who is Covered?

The original purchaser of the product must have proof of purchase to receive

warranty service. Please keep your invoice or receipt. Charder authorized dealers

or retail stores selling Charder products do not have the right to alter or modify

or in any way change the terms and conditions of this warranty.

What is Excluded?

Your warranty does not cover normal wear of parts or damage resulting from

any of the following: negligent use or misuse of the product, use on improper

voltage or current, use contrary to the operating instructions, abuse including

tampering, damage in transit, or unauthorized repair or alternations. Further,

the warranty does not cover natural disasters, such as fire, flood, hurricanes and

tornadoes. This warranty gives you specific legal rights, and you may also have

other rights that vary from country to country, state to state, province to

province or jurisdiction to jurisdiction.

MAINTENANCE

The scale does not require any routine maintenance. However, we recommend

checking the scale’s accuracy at regular intervals. If any inaccuracies occur,

please contact your local dealer or service partner.

Contact authorized Charder service agent in your area.

Submit your inquires at Charder Customer Support:

www.charder.com/contactus.htm or email to info_cec@charder.com.tw for

further assistance.

R220+ Waterproof Food Service Scale

PACKAGING

What’s in The Box:

Before Getting Started:

Make sure the scale is placed on a flat,horizontal and steady surface.

Make sure the scale has been cleared of all weight before turning on.

R220+ Waterproof Food Service Scale x1

Power AC Adapter x1

User Manual x1

R220+ Waterproof Food Service Scale

INSTALLATION

Power Supply

The scale is powered by a rechargeable battery that is charged using the

included power adapter.

Connect Adapter to mains power before plugging into AC jack on the back of

the scale (as shown in the illustration below).

If the adapter is not plugged in, the scale will automatically use battery power.

Note: When low battery is displayed, the scale needs to be charged,

and will automatically shut off after 30 seconds to avoid damaging the battery.

Parts Description

Stainless Steel

Pan

LCD Screen

Keypad

R220+ Waterproof Food Service Scale

OPERATION

Display:

A. g / lb / oz / lb:oz

This indicator will be turned on to indicate what unit is active.

B. Stability Indicator

This indicator will be turned on when the weight display is stable.

C. Negative Sign

This indicator will be turned on when a negative (minus) weight is displayed.

Keys:

ON/OFF: Press to turn the scale on & off.

TARE/ZERO: Press to deduct the weight of an object on the platform (ex:

measuring bowl). Press again to reset to zero.

UNIT: Press to switch between weighing units.

R220+ Waterproof Food Service Scale

ERROR MESSAGES

TROUBLESHOOTING

Low battery

Charge battery using adapter

Overload

Weight on platform exceeds

maximum capacity - remove

extra weight and try again.

Zero value too low

Turn scale off and try again. If

problem persists, please contact

your local Charder distributor.

Zero value too high

Remove weight before turning

on scale. If problem persists,

please contact your local

Charder distributor.

Programming Error

If problem persists, please

contact your local Charder

distributor.

Symptom

Possible Cause

Solution

Scale will not

turn on

Dead battery

Check if scale can be powered

when adapter is plugged in. Even if

device can still be operated, we still

recommend replacing battery

ON/OFF button

malfunction

Contact your local Charder

distributor for repair

Questionable

weight result /

scale will not

zero

External object

interfering with

scale

Remove object interfering with

scale

Display does not

show "0.0" before

weighing

Remove weight from platform,

press "TARE/ZERO" key and try

again.

R220+ Waterproof Food Service Scale

SETTINGS CONFIGURATION

Turn on the scale. Press and hold TARE/ZERO key. AOFF will appear on the

indicator.

Programming the Auto Off Time. (Default: 180S)

With AOFF selected:

1. Press TARE/ZERO key to enter Auto-off settings.

2. Press UNIT key to toggle through options: 120S, 180S, 240S, 300S, OFF.

3. Press TARE/ZERO key to select.

4. Press UNIT key until "End" appears on indicator. Press TARE/ZERO key to save

settings and restart scale.

NOTE: Auto-off option is only activated when the scale is using battery power. If

adapter is plugged in, Auto-off will be automatically disabled.

= =

[Save Setting & Restart the Scale]

[Auto Turn Off Time]

R220+ Waterproof Food Service Scale

SCALE CALIBRATION

This scale has been factory calibrated and does not require calibration

prior to use. If required, the scale can be calibrated.

1. When the scale is off, hold the ON/OFF button while pressing the UNIT

button 3 times.

2. You should have a raw count zero number value on the display for

reference only.

3.Press the UNIT key to select the unit of weight for this calibration.

(recommended: kg)

4. Making sure there is no weight on the platform, press the TARE/ZERO

key. The display will show "0".

5. Place the 3000g calibration weight on the platform, and press the

TARE/ZERO key. The display will show Cal, and then your test weight

value.

6. The scale will return you to normal weighing mode.
