6000 AND 7000
APPLIANCES
REPLACING AC POWER
SUPPLY UNITS
Check Point Copyright Notice
© 2020-2021 Check Point Software Technologies Ltd.
All rights reserved. This product and related documentation are protected by copyright and distributed under
licensing restricting their use, copying, distribution, and decompilation. No part of this product or related
documentation may be reproduced in any form or by any means without prior written authorization of Check
Point. While every precaution has been taken in the preparation of this book, Check Point assumes no
responsibility for errors or omissions. This publication and features described herein are subject to change
without notice.
RESTRICTED RIGHTS LEGEND:
Use, duplication, or disclosure by the government is subject to restrictions as set forth in subparagraph (c)
(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 and FAR
52.227-19.
TRADEMARKS:
Refer to the Copyright page for a list of our trademarks.
Refer to the Third Party copyright notices for a list of relevant copyrights and third-party licenses.
Important Information
Latest Software
We recommend that you install the most recent software release to stay up-to-date with the
latest functional improvements, stability fixes, security enhancements and protection against
new and evolving attacks.
Certifications
For third party independent certification of Check Point products, see the Check Point
Certifications page.
Check Point 6000 and 7000 Appliances Replacing AC Power Supply Units
For more about this release, see the home page.
Latest Version of this Document in English
Download the latest version of this document in PDF format.
Feedback
Check Point is engaged in a continuous effort to improve its documentation.
Please help us by sending your comments.
Revision History
Date Description
24 October 2021 Updated a note that PSUs on an appliance must be of the same type
30 April 2020 Updated with 6700 and 7000 appliances
03 February 2020 First release of this document
Table of Contents
6000 and 7000 Appliances Replacing AC Power Supply Units|4
Table of Contents
6000 and 7000 Appliances Replacing AC Power Supply Units
5
6000 and 7000 Appliances Rear Panel
5
6500
5
6600/6700/6900
5
6800
6
7000
6
Removing an AC Power Supply Unit
7
Installing an AC Power Supply Unit
7
Using the Restraint Clip
8
6000 and 7000 Appliances Replacing AC Power Supply Units
6000 and 7000 Appliances Replacing AC Power Supply Units|5
6000 and 7000 Appliances
Replacing AC Power Supply Units
These Check Point appliances have a redundant Power Supply Unit (PSU).
n6500 appliances
n6600 appliances
n6700 appliances
n6800 appliances
n6900 appliances
n7000 appliances
If necessary, you can replace a PSU on these appliances. Note that both PSUs on an appliance must be of
the same type (both AC). Mixing AC and DC PSUs is not supported and can cause damage to the
appliance.
Important - Make sure you are electromagnetically grounded before you install,
uninstall, or replace a PSU. ESD (electrostatic discharge) can damage the appliance.
6000 and 7000 Appliances Rear Panel
6500
6600/6700/6900
6000 and 7000 Appliances Replacing AC Power Supply Units
6000 and 7000 Appliances Replacing AC Power Supply Units|6
6800
7000
Item Component Description
1 Release lever Used to remove the power supply unit
2 Extraction
handle
Used to remove the power supply unit
3 LED indicator for
each power
supply unit
Off - Power supply is not connected to an electric outlet
nOn (Amber) - Power off
nOn (Green) - Power on
nOn (Red) - Failure
4 Power supply
unit/s
Connect to an electric outlet.
In 6500, 6700 Base, 6800, and 7000 Base appliances, one module
is included. An optional dual redundant hot-swappable power
supply is available.
In 6600, 6700 Plus, 6900, and 7000 Plus appliances two modules
are supplied.
You can use the cable restraints/clips to avoid accidental removal
of the power supply cable.
5 Alarm off button
for power supply
units
If a power supply cable is not connected to the outlet, an alarm
sounds continuously. Press this button to turn off the alarm.
6000 and 7000 Appliances Replacing AC Power Supply Units
6000 and 7000 Appliances Replacing AC Power Supply Units|7
Removing an AC Power Supply Unit
Before you remove a Power Supply Unit, we recommend that you make sure that either:
nThe other power supply is installed and connected to a working power source
Or
nShutdown the appliance
To remove a Power Supply Unit:
1. Remove the power cord from the Power Supply Unit.
2. If the alarm sounds, press the alarm off button to the right of the Power Supply Units.
The alarm stops.
3. While holding the release lever, pull the extraction handle to remove the Power Supply Unit.
Note - Remove the Power Supply Unit only with the extraction handle to prevent any possible damage.
Installing an AC Power Supply Unit
To install a replacement Power Supply Unit:
1. Insert the Power Supply Unit into the power supply slot.
2. Push the Power Supply Unit in until the release lever clicks.
6000 and 7000 Appliances Replacing AC Power Supply Units
6000 and 7000 Appliances Replacing AC Power Supply Units|8
3. Insert the power cord into the power supply socket.
4. Make sure that the power LED is illuminated.
Using the Restraint Clip
The 6500, 6600, 6800, 6900, and 7000 appliances have a power cable restraint clip attached to the Power
Supply Unit (PSU). Use the restraint clip to prevent accidental removal of the power cable.
To secure the restraint clip on the power supply cable:
1. Make sure the restraint clip is in the open position (upward).
2. Connect the power supply cable to the power supply inlet on the PSU.
6000 and 7000 Appliances Replacing AC Power Supply Units
6000 and 7000 Appliances Replacing AC Power Supply Units|9
3. Push down on the restraint clip to close it and secure the power supply cable.
Item Description
1 Restraint clip in the open position (upward)
2 Restraint clip in the closed position
