Introduction 1

Introduction

Congratulations on the purchase of your Roadtrek and welcome to the Roadtreking family. The information included in this

manual is meant to help and guide you through the use of your vehicle so that you know how to properly use the many

functions your Roadtrek has to offer.

Please keep this manual in your vehicle as a reference for when you are travelling. If you have any questions or comments on

information found in this document please contact us at [email protected] [1] or 1-888-ROADTREK.

References

[1] mailto:manuals@roadtrek.com

This manual is released under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0

International License [1].

In summary, you may:

•• Copy any portion of this manual in any form for personal use;

•• Distribute this manual complete with all of its original unmodified content;

•• Modify this manual for your own personal, non-commercial use.

You may not:

•• Use this manual for any commercial use whatsoever;

•• Modify this manual except as provided for in the full license and then distribute the resulting work;

•• Charge for this manual other than reasonable media and shipping costs.

All images used in this manual remain the property of Roadtrek, Inc. They are for illustrative purposes only and may or may

not be representative of the upfits in your Roadtrek.

Contact Roadtrek, Inc. for alternate licensing arrangements if you want to use or distribute this manual commercially.

References

[1] http://creativecommons.org/licenses/by-nc-nd/4.0/

Do's and Don'ts 3

Do's and Don'ts

Symbol Legend

For your information. May be useful information to know.

Warning. Not following this can lead to bad results.

Caution. You really should follow this to avoid bad results.

Don't do it. Doing this can result in injury, severe damage, or death.

Information, cautions, and warnings

Level Item Comment

SEAT BELTS Use only forward facing seats equipped with factory installed seat belts while the vehicle is in

motion. All passengers must be seated in these seats only, with the seat belts fastened while

the vehicle is in motion.

TV Turn the TV off and stow it while the vehicle is in motion.

TV The flat screen TV should not be stored inside the Roadtrek in cold temperatures. Remove it to

reduce the chance of damage from the cold. Check the Owner's Manual for the TV for storage

and operating temperatures.

Do's and Don'ts 4

TV To remove the TV, remove the four mounting bolts on the back of the TV mounting bracket

and remove the RCA cables, power supply cable and antenna cable.

PROPANE Do not store propane tanks inside your vehicle. Propane tanks are equipped with safety

devices which relieve excessive pressure by discharging gas to the atmosphere.

PROPANE Do not refuel the propane tank to more than 80% of its capacity.

PROPANE The propane tank valve must be closed and ALL PILOT LIGHTS, APPLIANCES, AND THEIR

IGNITERS, MUST BE TURNED OFF during refueling of the motor fuel tank and/or the propane

fuel tank. Only qualified personnel should refuel your propane tank.

PROPANE Purchase propane from a reputable propane facility. Contaminated propane is a common

cause of system failure and is not covered under any warranty.

PROPANE The BBQ quick disconnect is regulated to 10 P.S.I. Please ensure that all devices connected to

this are either rated for “high pressure” or have their own regulator. Many grills sold in the

United States are "low pressure" (1/2 P.S.I.) and will require an additional regulator to step the

pressure down to a useable level. If hooked directly to the BBQ quick disconnect they will be a

severe fire hazard.

PROPANE LEAK

DETECTOR

Do not block the air circulation in the area where the Propane Leak Detector is located.

PROPANE LEAK

DETECTOR

Battery disconnect switch must be in the “ON” position for the propane detector to function.

Do's and Don'ts 5

FLAMMABLE

LIQUIDS AND

GASSES

Do not store gasoline or other flammable liquids inside your vehicle.

HEATING Never use cooking appliances or unvented propane heaters for space heating purposes. They

need fresh air for safe operation.

HEATING The heating furnace provides its own outside combustion air and exhausts to the outside.

HEATING Portable fuel burning equipment, including wood, charcoal, and liquid fuel grills and stoves,

should not be used inside your vehicle. Use of this type of equipment inside your vehicle may

cause a fire or asphyxiation.

CARBON MONOXIDE

LEAK DETECTOR

Do not block the air circulation in the area where the Carbon Monoxide Leak Detector is

located

CARBON MONOXIDE

LEAK DETECTOR

Battery disconnect switch must be in the “ON” position for the Carbon Monoxide Leak Detector

to function.

110 VOLT

ELECTRICAL

SERVICING

Prior to servicing the 110 volt Galley GFCI & Audio/Video cabinet interior receptacles, unplug

the output lead from the power inverter.

EXTERIOR ACCESS

DOORS

Ensure the shore power cord and city water supply lines are disconnected and in their stored

positions before the vehicle is put in motion.

Do's and Don'ts 6

AWNINGS Close the sliding side door prior to opening or closing the awning.

CLOVERLEAF

DINING TABLE

The cloverleaf dining table is heavy. Use proper lifting techniques.

EXTRA COUNTER

SPACE

Make sure the stove is off and has cooled prior to lowering the stove cover.

BATTERY Battery acid can burn your skin and damage clothing. Protective eye wear and gloves should

be worn while handling batteries. Effective June 2010 all Roadtrek installed batteries

are sealed AGM batteries that do no require the addition of water.

BATTERY Disconnect the inverter/charger prior to disconnecting the auxiliary battery.

GENERATOR Never submerge the generator. Use a spotter when launching a boat or crossing streams.

GENERATOR When using the generator as the main power source to run the appliances, refer to the

generator owner’s manual for proper use and maintenance.

GENERATOR The generator cannot run all the appliances at the same time.

Do's and Don'ts 7

WASTE WATER

STORAGE AND

DUMPING SYSTEM

Close both the black and gray water gate valves before using the waste water system.

FREEZING Under moderate subfreezing conditions, antifreeze is required in the exterior fresh water tank,

black and gray waste water tanks. Use RV antifreeze in accordance with the manufacturer's

instructions.

ELECTRICAL

SERVICING

This unit has 12 volt, 110 volt and potentially 36 volt solar system. These systems need to be

disconnected before working on them.

GENERATOR The generator is not compatible with E-85 fuel. If the vehicle is equipped with a generator,

avoid the use of E-85 fuel.

ENGINE BATTERY The Chevrolet engine battery will be drawn down by the GM electronics to a no-start condition

if left unattended for extended periods. Plug the vehicle in, drive the vehicle for at least three

hours every two weeks to keep the engine and auxiliary batteries charged, or disconnect the

engine battery to keep it in good condition. Battery maintenance is the vehicle owner’s

responsibility.
