T18

Handheld GCS

User manual V 1.1

2020.11

www.chinowing.com

Catalog

1. Disclaimer............................................................................................. 3

2. Product Precautions............................................................................. 3

2.1. Installation Note.......................................................................4

2.2. Precautions for Use..................................................................4

3. Product Introduction.......................................................................... 4

3.1. Item List.................................................................................... 5

4. Product Instruction.............................................................................5

4.1 Airborne unit.............................................................................. 5

4.2 GCS..............................................................................................8

5. GCS Software..................................................................................... 11

5.1 The main interface of GCS........................................................ 11

5.2 Check flight information...........................................................12

5.3 Planning flight routes............................................................... 12

5.4 Video window...........................................................................13

5.5 Initialization Settings............................................................... 14

5.6 Joystick management............................................................... 15

5.7 Flight setting............................................................................. 16

6. Battery maintenance........................................................................ 19

7. Parameters........................................................................................ 19

1. Disclaimer

Thank you for purchasing the T18 hand-held remote-control station. Please use it

in accordance with local radio control regulations and read this statement

carefully before using it. Once used, it shall be deemed to endorse and accept all

contents of this statement. Please strictly follow this instruction to install and use

the product. The supplier will not bear any legal liability for any result or loss

caused by improper use, installation, final assembly or modification of the

product.

2. Product Precautions

1. Be sure to power on the GCS before starting the drone.

2. When switching between left and right handed mode, disconnect the remote

control from the aircraft first.

3. Turn the antenna sideways to the drone to ensure a stable signal when

performing tasks.

4. In the operation, be sure to handle it gently to avoid damage.

5. Do not disassemble the product, otherwise the product cannot be under

warranty.

6. Please use soft fabric for dust cleaning after the operation.

7. When not in use, please store the product in an EVA foam packing box in a cool

and dry environment.

8. Please keep it away from flammable and explosive materials as there is a built-

in lithium battery.

9. In order to serve our customers better, our R & D team has been upgrading and

optimizing the product, the corresponding software and firmware will be updated

from time to time, there may be incompatibility between the different firmware

versions of the ground unit and the airborne unit, so please check the software

firmware version when using. Please refer to our website for the latest firmware

and technical support.

10. If you encounter any insurmountable problems during the installation or the

operation of the product, please contact us or visit our website:

www.chinowing.com for the support.

2.1. Installation Note

1) Be sure to use the spare parts provided by our company.

2) Be sure to install the antennas before power on to avoid damage to the circuit.

3) Try to make the receiver antenna without obstruction, and the end part of the

antenna is vertically downward without bending, so as to avoid shortening the

communication distance or even failing to communicate due to obstruction.

4) Do not disassemble or refit without permission. If you encounter any problem

that cannot be solved during installation, please contact us directly.

5) During installation, keep proper distance between electronic devices to

minimize electromagnetic interference.

2.2. Precautions for Use

1) Before use, please make sure that all connection wires are fastened reliably

and all parts work normally.

2) Please open the configuration software of the remote control and check

whether the channels are normal after power-on.

3) Please check the surrounding environment to ensure that there is no

interference of 2.4GHz from other devices, otherwise T18 data transmission

performance will be seriously affected.

4) Ensure that the antennas are free from obstacles and bends during use, and

stay away from large metal structural parts as far as possible to avoid

communication obstruction.

5) Check the power of the remote control before use. If the parameter

adjustment software shows that power is low, please charge the remote control

timely. If the remote control is turned off, the receiver has entered the state of

out-of-control protection. Stop using it when the battery is too low. Don't rely on

the device's low-power alarm, which is only a precaution and tells you when to

charge. It takes about 5-6hs to be fully charged.

3. Product Introduction

T18 hand-held GCS system integrates video, data transmission, SBus link. With 15

channels, 5km transmission range, 150ms latency, it supports up to 1080P60 HD

video transmission. With built-in QGC open-source ground station software, it is

compatible with APM, PX4 open-source flight control system, realizing real-time

monitoring and control of drones, unmanned boats, as well as inspection robots

and other intelligent terminal equipment.

Note: High-end 4G version -- With built-in 4G module, it can access the video

command system that complies with GB/T 28181-2016 national standard

protocol, compatible with Hikvision, Dahua and other platforms, suitable for

public security, firefighting, traffic management and other related industry

applications.

3.1. Item List

Power cable x1

Charger ×1

Receiver upgrade

configuration cable ×1

Lan-to-4 pins line

×1

Power for receiver

(DC:7.4-12V, Li

battery 2s-3s)

Charge for remote

control

Used for firmware

upgrading

and parameters

Setting for receiver

For module

Parameter

configuration

4. Product Instruction

4.1 Airborne unit

T18 remote controller x 1

Airborne unit x 1

1-2. SMA connector

Antenna connector, used for connecting the airborne antenna.

3. S-Bus1

（1）S-Bus1 output(used for connecting flight controller or gimbal)

（2）Nc: VCC

（3）GND

4. LINK indicator

RC link indicator, used for indicating the connection status of airborne unit and

GCS.

Indicator

Status

Flashing red

light

PAIRING button has been pressed, and the airborne unit is

in the PAIRING state.

Flashing green

light

The signal was detected but not connected. Need to do the

pairing operation.

Green light ON

The successful pairing.

Red light ON

No signal was detected. Pls turn on the power switch at

the GCS or check whether the airborne unit is connected

correctly.

5. VIEDO indicator

Video link indicator, used for indicating the video source input status

Indicator

Status

Green light ON

HDMI signal is detected and work normally.

Flashing green

light

HDMI signal has been detected, but unable to transmit.It is

necessary to re-power-on the airborne unit or check the

connection of the airborne unit.

Red light ON

No video source has been detected or video source does

not supported. Pls confirm that the camera is connected

correctly or that the output format of the camera is correct.

6. PAIRING button

Frequency pairing button, through which the airborne unit can be pairing with

the GCS.

7. HDMI input

Use the HDMI cable to connect this port to the camera's HDMI output port. It

supports up to 1080P60 video input.

8. CAN bus

（1）NC: VCC

（2）CANH: CAN high level

（3）CANL: CAN low level

（4）GND

9. Integration interface

（1）Rx: serial port input(TTL Level, 115200bps)

（2）Tx: serial port output(TTL Level, 115200bps)

（3）SBUS 2: output(connecting the SBUS port of flight controller or gimal)

（4）GND

（5）GND

（6）GND

（7）12V: power input(4.5v-16v)

（8）12V: power input(4.5v-16v)

4.2 GCS

Fig 5 front diagram

[1]Data Transmission Antenna: transmitting RC, telemetry data

[2]7 inch LCD screen: for the operation and interface display

[3] Video Transmission Antenna: transmitting video data

[4] [6]Flight joystick: controlling the attitude and lifting of the UAV

[5]ON/OFF button: start or turn off the device

Short press the power button once and then long press it until all four power

indicators are on and then the GCS is started. Short press the power button once

and then long press it until all four power indicators are off and then the GCS is

turned off.

[7]One key return button: long press to trigger the return mode; the red light of

the button is on, short press to cancel the return mode;

[8]Strap hook: use with strap.

[9]Status indicator: indicating whether the system can work normally.

With the flashing green indicator, it means that the system is running normally

and has not been charged;

When the blue light and the white light of the status indicator flicker alternately,

it means that the system is running normally and is charging;

When the status indicator light is blue, it means that the system is charging under

shutdown.

[10]Power indicator: indicating the current power

The four power indicators respectively represent 100%, 75%, 50% and 25% of the

remaining power. At the same time, the accurate percentage of power will be

displayed in the software interface of GCS. When the percentage of power is less

than 10%, the software interface of the GCS will give an alarm of low voltage. At

this point, please turn off the device and charge it as soon as possible.

[11]Fan outlet: for cooling, pls do not block;

[12] DC charger port: Charge the device through a standard adapter;

图 6 底部示意图

[11]

[12]

[13]Handle

[14]Photograph button: short press to trigger photography

[15]Custom button

[16]Cooling fan air inlet: pls do not block

[17]Record button: Press once to start recording; Short press again to end the

video.

[18]Custom button

[21]

[22]

[23]

[24]

[25]

[26]

[27]

Fig 8 top diagram

FIg 7 Back diagram

[20]

[19]

[28]

[29]

[14]

[15]

[16]

[17]

[18]
