CHP - 5350DL / CHP-5351DL

• Read the user's manual thoroughly before using the unit.

• Design and color may differ from the picture.

• Unit appearance, specification, etc. are subject to change without prior notice if

necessary for improving unit performance.

• The rated voltage of this unit is 220-240 V~ / 50 Hz only

Use 's manual

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 2

Unit features

Coffee capsule extract function for Italian flavor of coffee

Extract function for coffee and tea is applied to allow users to enjoy Italian flavor of coffee and tea.

Reverse osmosis purifying system without pump

This unit serves purified water from reverse osmosis system without booster pump. This decreases the function noise

and power consumption accordingly.

All-in-one water purifier with caffe

Water with 3 different temperature (hot, cold and ambient), ice and extract function offer various beverages on

user's preference.

Detachable capsule holder and hygienic operation

Extract method is easy to follow by inserting a capsule to the holder and push the desired beverage button. Detachable

capsule holder helps to stay clean by rinsing it with water simply.

ACS smart cleaning function

This makes users not to worry about contamination by bacteria as it empties the ambient water and cold tank automati-

cally every 4 days in fixed time and fill the clean water which is sterilized by UV sterilizer.

Selection key for optimized taste of various coffee capsules

Buttons for Espresso, Americano and Tea are designed for the best taste of its coffee and tea.

Easy and quick extract for Americano

In case “AMERICANO” button is applied, hot water is added while extracting coffee.

Compact size (width: 29 cm)

Compact-sized water purifier can be installed by effectively utilizing the space.

Extended water dispensing space

It is convenient to take water with any shape of bottle as height of water dispensing space is up to 25 cm.

Dual heating system

Hot water is made by standby heating mode or hot tank heating mode. User can easily select the mode by their prefer-

ence. It enhances energy efficiency.

24 hour natural water circulation system(N.W.P.W)

ChungHo Nais purification system is designed to allow water to continuously flow for 24 hours within the water purifier by

adopting a natural circulation method. This mode, entitled N.W.P.W. applies the natural weight of water pressure in order

to supply always clean and fresh water. (patent : No.105585)

ilter structure is designed for user friendly

It is convenient to replace filters as they could be detached by lifting them.

Easy maintenance system

It is more convenient that empty water tank within 11 minutes by pressing the button once for cleaning inside.

123456

8910111213

This appliance is intended to be used in household and simila applications such as

-staff kitchen areas in shops, offices and other working environments

-farm houses

-by clients in hotels, motels and other residential type environments

-bed and breakfast type environments

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 3

We greatly appreciate your purchase of "WHI CA E

-Ⅳ

". This unit is manufactured according to standard specifica-

tion, and produced with a reliability test on all integrated components. The system is tested thoroughly on strict quality

guidelines including temperature, moisture, shock, dust, vibration, drop, etc. We are sure that these various production

processes will provide the utmost customer satisfaction in both quality and excellence.

Befo e installing o using the unit, ead this use 's manual tho oughly and keep it fo you futu e efe ence.

1.제품의특징02

G eetings

Safety precautions

03~06

Names of each part

Installation cautions

Installation method

How to extract coffee and tea

Display and coffee extract button

Extracting coffee and tea

Using coffee and tea extract method

11~13

LCD display for coffee extract

Extracting coffee and tea

11~13

Descaling coffee outlet

Coffee recipe

Operation

Display and function settings (A)

Water dispensing selection (B)

Usage

16~19

unction setting and releasing

16~17

Ice and water dispensing method

18~19

Smart cleaning function

Cautions during use

Cleaning

21~23

Ice dispensing spout

Water dispensing spout

Water tank

21~23

Capsule holder

Coffee outlet packing

Drip tray

Maintenance

ilters

ilter function

ilter service life

Replacement

Specification

low diagram

Recommended replacement part

Troubleshooting

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 4

● When the power cord has

been damaged, change the

power cord in order to

prevent danger such as an

electric shock, etc.

(Do not use damaged or

loose wall outlets. An electric

shock or fire may occur.)

● Keep the cord out of heavy

traffic areas.

(This can lead to overheating

the outlet.)

● Insert the plug to the outlet

firmly to avoid loosening.

(Unstable connection may

cause a fire.)

● Do not bend the power cord

excessively or put heavy

objects over the power cord.

(An electric shock or fire may

occur.)

● If the unit is damaged or

malfunctioning, do not disa-

ssemble, repair, or remodel it

on your own.

● Do not put candles, lit

cigarettes, etc. on the unit.

(There is danger of a fire.)

● Do not put a bowl containing

water, chemicals, small

metals, etc. on the unit.

(If these materials drop into

the inside of the unit, this

may cause an electric shock

or fire.)

Associated with the possibility for serious injury or death.

Danger

Cautions are divided into 2 categories : ‘Danger’ and ‘Caution’

Safety p ecautions

● Leave the unit unplugged,

before cleaning the inside

of the unit.

(An electric shock or fire

may occur.)

● Do not touch the power plug

with wet hands.

(An electric shock may occur.)

● While coffee is extracting, do not

stay close to coffee outlet.

(Coffee splashes and it can cause

burns.)

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 5

● Do not reuse the capsule.

(Capsule can have deformation

and it cause leakage.)

● Use designated capsule size

only.

(Do not use other sized

capsules. Different size can

cause malfunction and burns.)

● Remove used capsule from

the capsule holder.

(Leaving the capsule for long

time can cause germ

and mold in the holder.)

● Be careful of burns when you

throw away capsules after

extract.

(Small amount of hot

water remaining capsule

holder can cause burns.)

● Do not insert finger to the coffee

outlet with capsule holder sepa-

rated.

( inger can be injured by being

caught.)

● While coffee is extracting,

never try to separate

capsule holder.

(Coffee machine can have

damage and hot beverage

can cause burns.)

● Close supervision is required

when any appliance is used

by or near children.

● Make sure that drip tray is

properly installed when you

extract coffee.

(Hot coffee can spill over.)

● Do not try to extract coffee or

tea without cup.

(Beverage can overflow from

drip tray and it can cause

burns.)

Associated with the possibility of injury, property damage and reduced performance of unit.

Caution

25mm36mm

Safety p ecautions

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 6

● To avoid burns from beverage,

use containers such as a cup

during coffee extract.

● To avoid burns from hot water,

use containers such as a cup

during hot water dispensing.

● Do not install the unit in a place

where the temperature may

drop below 32 ° (0 °C).

● Do not operate the unit standing

unbalanced.

(It can cause malfunction.)

● Do not tilt the unit over 45° dur-

ing transportation.

(Severe inclination can cause

performance degradation.)

● Do not install the unit in a

sloped or unstable position.

(This can cause a reduced

performance, system damage

or overall trouble.)

Associated with the possibility of injury, property damage and reduced performance of unit.

Caution

Safety p ecautions

●

When taking ice, place a contain-

er close to the ice dispensing hole

not to drop ice on the floor.

(Be careful in order not to allow

containers such as cups, etc. to

be inserted into the inside of ice

dispensing hole.)

●

When taking ice, avoid using a

glass cup and avoid taking ice

with cup filled with beverage, cof-

fee etc.

(A glass cup can be broken by

abrupt temperature change or the

ice strike. Beverage and coffee

can splash into ice dispensing

hole and it can cause mold.)

●

Do not put foreign materials

into the ice dispensing hole

or block the dispensing hole.

(This can cause system mal-

function.)

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 7

● If there is dust, water or etc.

on the power plug pin, wipe it

off well.

(Wipe it off dust, water or etc. on

the power plug pin before con-

nection.)

30 Minutes

● After transporting the unit, do

not supply the power for at

least 30 minutes to stabilize the

unit.

● To disconnect the unit, be sure

to pull by the plug and not the

cord.

(Be sure to pull by the plug, not

the cord to disconnect the unit.)

● After installation, arrange the

power cord so that it will not

be stepped on or stepped

over.

● Do not put any covering on the

rear and side of the unit.

Blocking ventilation holes may

raise inside temperature and

cause system malfunction

or even system stoppage.

● Do not install the unit in or

around largely damp areas,

at a place near flammable

materials, or at a place

exposed to rain or snow.

(There is danger of an

electric shock or fire.)

Symptoms under normal operations

1. During use of the unit, a murmuring water-flow sound, a clattering ice dropping sound, etc. may occur

during cold water making process or ice making process.

2. Opaque ice may occasionally be served, but there is no abnormality in unit performance or ice quality.

3. TDSs (Total Dissolved Solids) found in ambient water, cold water, and ice may vary from one another.

(This is a result of the freezing point method.)

4. After the system power source is interrupted and then again restarted, irregular ice may temporarily be

served.

● Keep tube fixed properly so as not to

splash around area with water from brine tube.

Associated with the possibility of injury, property damage and reduced performance of unit.

Caution

Safety p ecautions

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 8

Names of each pa t

Drain switch

Drip tray

Hot tank heating/Off/Standby

heating selection switch

Ice dispensing touch button

Ice dispensing display

Water dispensing button

Water dispensing spout

Grill

Hot/Ambi./Cold water display

Hot water : Red, Ambient water : Green, Cold water : Blue

ICE/LOCK setting touch button

Ice dispensing spout

Capsule holder

Water tray

Lock display

Ice making display

Ice full display

Water full display

Hot water display

Hot water selection touch button

Coffee extract display and control panel

Cold water selection touch button

Ambient water selection touch button

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 9

Installation cautions

When transporting the unit, do not tilt it over 45°

*Severe tilting can cause performance degradation.

Keep the unit approximately 8" (20 cm) away from the wall for proper ventilation.

Use the following water quality range.

• Water pressure : 1.4~7 kgf/㎠(137~686 kPa) • Water temperature : 39~100 ° (4~38 °C)

•

pH : 5.8~8.5

• Water hardness : 300 ppm or less

•

Evaporated residue : 500 ppm or less

• Water quality : Biologically safe water quality

*When using the water out of range, discuss it with the distributor. If not, the unit can be

excluded from the stated warranty.

Do not connect hot water over 100 °(38 °C) to this unit.

*This can cause trouble and malfunction.

When connecting tube, ensure that the tube is not bent or pressed down by any heavy objects.

*If tube is bent or pressed, water does not flow well and can cause problems.

The highest point of installed brine tube must be less than 12"(30 cm) away from the flat floor.

Total length of brine tube must be less than 118"(3 m). Otherwise, water is not drained well.

When installing more than one unit(water purifier, shower softener, etc.), tubes of source water, brine

water need to be independent for one another.

Adjust the tube so that brine water may not splash around area.

*Brine water can easily be used for other purposes, such as bathroom cleaning, house cleaning, laundering,

washing, etc. Never use the brine water for drinking or cooking.

Do not install the unit at the following places.

• Near fire or heater • Near flammable material • Wet place • Near the toilet

• A place exposed to rain or snow • A place exposed to direct sunlight

• Near chemicals(volatile material, organic solvent, etc.)

• A place below 32 ° (0 °C) or a place with the possibility of dropping below 32 ° (0 °C).

• A place above 104 ° (40 °C) or a place with the possibility of rising above 104 ° (40 °C).

Install the unit at a place where the surface is flat, and after installation, always adjust the level of the unit

by using a level gauge.

* More 3˚ tilting can cause performance degradation.

Do not place any electric heater near the rear of the unit.

1234567891011

휘카페 4_영문매뉴얼_*이과수공기청정기-수정 16. 2. 22. 오후 2:47 페이지 10

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Chungho Kaffeemaschine Handbücher

Chungho

Chungho WHI CAFFE CHP-5230S Bedienungsanleitung

Beliebte Kaffeemaschine Handbücher anderer Marken

Taurus

Taurus Livorno 6 Bedienungsanleitung

Delta-q

Delta-q QUICK Bedienungsanleitung

Bunn

Bunn LCA-1 Fehlerbehebungshandbuch

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Montageanleitung

Saeco

Saeco Vienna Plus Sup 018M Bedienungsanleitung

DeLonghi

DeLonghi DC300 Bedienungsanleitung

INCAPTO

INCAPTO BXCO1470E Bedienungsanleitung

Bosch

Bosch TASSIMO finesse TAS16B Series Bedienungsanleitung

Exido

Exido 245-072 Bedienungsanleitung

Animo

Animo OptiVend Choco Bedienungsanleitung

Siemens

Siemens TQ505DF Series Bedienungsanleitung

DeLonghi

DeLonghi ECI341 Bedienungsanleitung

Krups

Krups KT406511 Bedienungsanleitung

Cimbali

Cimbali M32 Classic Bedienungsanleitung

Philips

Philips HL3844N Bedienungsanleitung

Bosch

Bosch TES 515 SERIES Bedienungsanleitung

Tekmatix

Tekmatix TMFM - 65 Bedienungsanleitung

Scarlett

Scarlett SC-CM33005 Bedienungsanleitung
