Cisco Catalyst 9200 Series Switches Hardware Installation Guide

First Published: 2018-11-19

Last Modified: 2020-11-17

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Cisco Catalyst

C9200-L C9200L-24T-4X-A o cerca il tuo prodotto tra le migliori offerte di Switch

CONTENTS

Product Overview 1

CHAPTER 1

Switch Models 1

Front Panel Components 3

10/100/1000 Ports 4

PoE and PoE+ Ports 4

Multigigabit Ethernet Ports 5

Management Ports 5

USB Type A Port 6

Uplink Ports 6

Rear Panel 8

RFID Tag 9

StackWise Ports 9

Power Supply Modules 9

Fan Modules 11

Ethernet Management Port 12

RJ-45 Console Port 12

Network Configurations 13

Installing the Switch 15

CHAPTER 2

Preparing for Installation 15

Safety Warnings 15

Installation Guidelines 17

Shipping Box Contents 17

Tools and Equipment 18

Verifying Switch Operation 18

Planning a Switch Data Stack 19

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

iii

Switch Stacking Guidelines 19

Data Stack Cabling Configurations 20

Data Stack Bandwidth and Partitioning Examples 21

Power-On Sequence for Switch Stacks 23

Mounting the Switch 24

Rack-Mounting 24

Attaching the Rack-Mount Brackets 25

Mounting the Switch in a Rack 27

Installing the Switch on a Table or Shelf 27

After Switch Installation 28

Connecting to the StackWise Ports 28

Connecting Devices to the Ethernet Ports 31

10/100/1000/Multigigabit Ethernet Port Connections 31

Auto-MDIX Connections 31

PoE and POE+ Port Connections 31

Installing a Network Module 33

CHAPTER 3

Installing a Network Module in the Switch 33

Safety Warnings 33

Equipment That You Need 33

Installing a Network Module 34

Removing a Network Module 36

Finding the Network Module Serial Number 36

Installing and Removing Pluggable Transceiver Modules 37

Installing a Cisco Pluggable Transceiver Module 37

Removing a Cisco Pluggable Transceiver Module 39

Installing a Power Supply Unit 41

CHAPTER 4

Power Supply Modules Overview 41

Finding the Power Supply Module Serial Number 44

Installation Guidelines 45

Installing or Replacing an AC Power Supply Module 46

Installing a Fan Module 49

CHAPTER 5

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Contents

Fan Modules Overview 49

Installation Guidelines 50

Installing a Fan Module 50

Finding the Fan Module Serial Number 51

Configuring the Switch 53

CHAPTER 6

Configuring the Switch Using the Web User Interface 53

Setting up the Switch 53

Connecting to the Switch 53

Creating User Accounts 57

Choosing Setup Options 57

Configuring Basic Device Settings 57

Configuring Your Device Based on a Site Profile 59

Configuring Switch Wide Settings 64

Configuring VLAN Settings 64

Configure STP Settings 65

Configuring DHCP, NTP, DNS and SNMP Settings 65

Configuring Port Settings 66

Configuring VTY Lines 67

Configuring the Switch Using the CLI 68

Accessing the CLI Through the Console Port 68

Connecting the RJ-45 Console Port 68

Connecting the USB Console Port 69

Installing the Cisco Microsoft Windows USB Device Driver 70

Installing the Cisco Microsoft Windows 7 USB Driver 70

Uninstalling the Cisco Microsoft Windows USB Driver 70

Uninstalling the Cisco Microsoft Windows 7 USB Driver 70

Technical Specifications 73

APPENDIX A

Environmental and Physical Specifications 73

Specifications for the Power Supplies and Fans 77

Switch LEDs 79

APPENDIX B

LEDs 79

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Contents

Console LED 79

System LED 80

MASTER LED 80

STACK LED 81

PoE LED 82

Port LEDs and Modes 82

Beacon LED 84

RJ-45 Console Port LED 85

Fan LED 85

Uplink Port LEDs 85

Introduction ?

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Contents

CHAPTER 1

Product Overview

•Switch Models, on page 1

•Front Panel Components, on page 3

•Rear Panel, on page 8

•Network Configurations, on page 13

Switch Models

The Cisco Catalyst 9200 Series switches have four modular (C9200) and eight fixed (C9200L) switch models.

The following tables describe all the available Cisco Catalyst 9200 Series switches and the features supported.

Table 1: C9200L Switch Models and Descriptions

DescriptionSwitch Model

Stackable 24x1G PoE+ ports; 4x1G SFP fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-24P-4G

Stackable 24x1G PoE+ ports; 4x10G SFP+ fixed uplink ports; 2

power supply slots; 2 fixed fans; supports StackWise-80.

C9200L-24P-4X

Stackable 24x1G ports; 4x1G SFP fixed uplink ports; 2 power supply

slots; 2 fixed fans; supports StackWise-80.

C9200L-24T-4G

Stackable 24x1G ports; 4x10G SFP+ fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-24T-4X

Stackable 48x1G PoE+ ports; 4x1G SFP fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-48P-4G

Stackable 48x1G PoE+ ports; 4x10G SFP+ fixed uplink ports; 2

power supply slots; 2 fixed fans; supports StackWise-80.

C9200L-48P-4X

Stackable 48x1G ports; 4x1G SFP fixed uplink ports; 2 power supply

slots; 2 fixed fans; supports StackWise-80.

C9200L-48T-4G

Stackable 48x1G ports; 4x10G SFP+ fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-48T-4X

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

DescriptionSwitch Model

Stackable 8xMultigigabit Ethernet PoE+ ports and 16x1G PoE+

ports; 4x10G SFP+ fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-24PXG-4X

Stackable 8xMultigigabit Ethernet PoE+ ports and 16x1G PoE+

ports; 2x25G SFP28 fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-24PXG-2Y

Stackable 12xMultigigabit Ethernet PoE+ ports and 36x1G PoE+

ports; 4x10G SFP+ fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-48PXG-4X

Stackable 8xMultigigabit Ethernet PoE+ ports and 40x1G PoE+

ports; 2x25G SFP28 fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-48PXG-2Y

Stackable 48x1G PoE+ ports with partial PoE support; 4x1G SFP

fixed uplink ports; 2 power supply slots; 2 fixed fans; supports

StackWise-80.

C9200L-48PL-4G

Stackable 48x1G PoE+ ports with partial PoE support; 4x10G SFP

fixed uplink ports; 2 power supply slots; 2 fixed fans; supports

StackWise-80.

C9200L-48PL-4X

Table 2: C9200 Switch Models and Descriptions

DescriptionSwitch Model

Stackable 24x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-24P

Stackable 24x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-24PB

Stackable 24x1G ports; 4x1G and 4x10G network modules for uplink

ports; 2 power supply slots; 2 field-replaceable fans; supports

StackWise-160.

C9200-24T

Stackable 48x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-48P

Stackable 48x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-48PB

Stackable 48x1G ports; 4x1G and 4x10G network modules for uplink

ports; 2 power supply slots; 2 field-replaceable fans; supports

StackWise-160.

C9200-48T

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Product Overview

Switch Models

DescriptionSwitch Model

Stackable 8 Multigigabit Ethernet and 16x1G PoE+ ports; supports

4x10G, 2x25G and 2x40G network modules for uplink ports; 2 power

supply slots; 2 field-replaceable fans; supports StackWise-160.

C9200-24PXG

Stackable 8 Multigigabit Ethernet and 40x1G PoE+ ports; supports

4x10G, 2x25G and 2x40G network modules for uplink ports; 2 power

supply slots; 2 field-replaceable fans; supports StackWise-160.

C9200-48PXG

Stackable 48x1G PoE+ ports with partial PoE support; 4x1G and

4x10G network modules for uplink ports; 2 power supply slots; 2

field-replaceable fans; supports StackWise-160.

C9200-48PL

Front Panel Components

This section describes the front panel components of Cisco Catalyst 9200 Series switches :

• 24 or 48 downlink ports of one of the following types:

• 10/100/1000

• 10/100/1000 PoE+

• 1G/10G Uplink ports

• USB Type A storage ports

• USB mini-Type B console port

• LEDs

• Blue Beacon

All the switch models have similar components. See the following illustration for example.

The Cisco Catalyst 9200 Series switches might have slight cosmetic differences on the bezels.

Note

Figure 1: Front Panel of a C9200L Switch

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Product Overview

Front Panel Components

USB Type A storage ports5Blue Beacon (UID button)1

10/100/1000 PoE+ ports6Mode button2

Fixed uplink ports7Status LEDs3

USB mini-Type B (console) port4

Figure 2: Front Panel of a C9200 Switch

USB Type A storage ports4Blue Beacon (UID button)1

10/100/1000 PoE+ ports5Mode button2

Network Module with uplink

ports

6USB mini-Type B (console)

port

10/100/1000 Ports

The 10/100/1000 ports use RJ-45 connectors with Ethernet pinouts. The maximum cable length is 328 feet

(100 meters). The 100BASE-TX and 1000BASE-T traffic requires twisted pair (UTP) cable of Category 5

or higher. The 10BASE-T traffic can use Category 3 cable or higher.

PoE and PoE+ Ports

The PoE and PoE+ ports provide the following functionality:

• PoE/PoE+ ports: Support for IEEE 802.3af-compliant powered devices (up to 15.4W PoE per port) and

support for IEEE 802.3at-compliant powered devices (up to 30W PoE+ per port).

• Support for pre-standard Cisco powered devices.

• Configurable support for Cisco intelligent power management, including enhanced power negotiation,

power reservation, and per-port power policing.

See the Power Supply Modules, on page 9 for the power supply matrix that defines the available PoE and

PoE+ power per port. The output of the PoE+ circuit has been evaluated as a Limited Power Source (LPS)

per IEC 60950-1.

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Product Overview

10/100/1000 Ports

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Cisco Schalten Handbücher

Cisco

Cisco MDS 9120 - Fabric Switch Bedienungs- und Wartungshandbuch

Cisco

Cisco 4900M - Catalyst Switch Bedienungsanleitung

Cisco

Cisco Catalyst Express 520 Referenzhandbuch

Cisco

Cisco Small Business 200 Series Bedienungsanleitung

Cisco

Cisco 4948 Series Bedienungsanleitung

Cisco

Cisco Catalyst 9300 Series Bedienungsanleitung

Cisco

Cisco 300 Series Bedienungsanleitung

Cisco

Cisco Catalyst 3750G-12S-SD Anleitung zur Verwendung

Cisco

Cisco 3020 - Cisco Catalyst Blade Switch Bedienungsanleitung

Cisco

Cisco Cisco mds 9124 - fabric switch Bedienungsanleitung

Cisco

Cisco Catalyst 3750-X Series Bedienungsanleitung

Cisco

Cisco N5K-M1600 - Expansion Module - 6 Ports Bedienungsanleitung

Cisco

Cisco Catalyst Express 500-24LC Bedienungsanleitung

Cisco

Cisco SF500-24 Bedienungsanleitung

Cisco

Cisco Catalyst Blade Switch 3130 Handbuch

Cisco

Cisco IE-3000-8TC Installationshandbuch

Cisco

Cisco Catalyst Express 520-24LC Bedienungsanleitung

Cisco

Cisco Catalyst 2960-XR Bedienungsanleitung

Cisco

Cisco Nexus 9336PQ Handbuch

Cisco

Cisco SR216 Bedienungsanleitung

Cisco

Cisco WS-C2950-12 Handbuch

Cisco

Cisco AJ732A - MDS 9134 Fabric Switch Bedienungsanleitung

Cisco

Cisco Nexus 7000 Series Bedienungsanleitung

Cisco

Cisco Catalyst 2960 Series Installationshandbuch

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
