CITROEN C5 2000 Bedienungsanleitung

2000

CAR 050007

AC/QCAV/MTD

Méthodes Techniques Documentation



’’The intellectual property rights relating to the technical information contained in this document belong

exclusively to the manufacturer. Reproduction, translation or distribution in whole or in part without

prior written authorisation from the manufacturer is forbidden.‘‘

PRIVATE CARS

«The technical information contained in this document is intended for the exclusive use of the trained personnel of the

motor vehicle repair trade. In some instances, this information could concern the security and safety of the vehicle. The

information is to be used by the professional vehicle repairers for whom it is intended and they alone would assume full

responsibility to the exclusion of that of the manufacturer».

’’The technical information appearing in this brochure is subject to updating as the characteristics of each

model in the range evolve. otor vehicle repairers are invited to contact the CITROËN network periodically

for further information and to obtain any possible updates».

PRESENTATION

THIS HANDBOOK summarises the specifications, adjustments, checks and special features of the CITROEN C5.

The handbook is divided into the following sections representing the main functions :

GENERA - ENGINE - INJECTION - IGNITION - C UTCH - GEARBOX - DRIVESHAFTS - AX ES - SUSPENSION - STEERING - BRAKES - HYDRAU ICS -

E ECTRICA - AIR CONDITIONING.

INJECTION

Idling - antipollution 111

Petrol injection 112

Emission standards 113 - 119

Prohibited operations : HDi 120 - 121

Safety requirements : HDi 122 - 123

Checking the fuel supply circuit 124 - 125

Checking the air supply circuit 126 - 130

Exhaust gas recycling 131 - 134

Checking turbo pressure 135 - 138

Features of injection systems 139 - 168

IGNITION

Sparking plugs 169

CLUTCH-GEARBOX

Speedometers 170

Clutch specifications 171 - 172

Gearbox and tyre specifications 173 - 174

BE4/5 gearbox controls 175 - 183

M /5 gearbox controls 184 - 192

A 4-4HP20 gearbox controls 193 - 203

Driveshafts 204

AXLES-SUSPENSION

Wheels and tyres 205 - 211

Axle geometry 212 - 214

Front and rear axle 215 - 216

Suspension 217 - 220

Steering specifications 221 - 222

BRAKES

Brake specifications 223 - 228

Handbrake adjustment 229

Bleeding and filling braking system 230 - 233

HYDRAULICS

Specifications 234 - 237

Suspension spheres 238 - 240

ELECTRICAL

Starter motors 241

Alternators 242

Charging circuit 243

AIR CONDITIONING

Quantities in R 134a aircon system 244

Special features 245

Pollen filter 246

Dryer cartridge 247 - 249

Checking oil level 250 - 251

Checking pressures 252

Air conditioning : 6FN-RFN-R Z 253

Air conditioning circuit : XFX 254

Air conditioning circuit : RHY-RHZ 255

Air conditioning circuit : 4HX 256

INDEX

GENERAL

Identification of vehicles 1 - 4

General : Dimensions 5 - 6

Weight specifications 7 - 8

Towing specifications 9 - 10

ifting / supporting the vehicle 11 - 14

Capacities 15 - 18

ubricants 19 - 32

ENGINES

Engine specifications 34 - 58

Cylinder head marking / tightening

6FZ-RFN-R Z 38

XFX 51 - 52

RHY-R Z 55 - 56

4HX 57 - 58

Auxiliaries drive belt 59 - 68

Checking and setting valve timing 69 - 90

Power unit suspension 91 - 95

Exhaust system 96 - 100

Cooling system 101 - 107

Checking oil pressures 108

Oil filter 109

Filling and bleeding engine coolant 110

GENERAL

IDENTIFICATION OF VEHICLES

E1APO8RD

(A) Chassis stamp

(cold stamp on bodywork).

(B) Manufacturer’s data plate.

(under the rear bench seat)

(label on front pillar close to driver’s door).

(D) Inflation pressures and tyre references.

(label on front pillar close to driver’s door)

(E) Serial no. on bodywork.

(F) Gearbox reference – Factory serial no.

(G) Engine legislation type – Factory serial no.

GENERAL

Emission standard L IF/L5 L IFL5 L -IF/L5 L IF/L5

Type code DC 6FZB DC 6FZC/IF DC 6FZE DCRFNC/IF DC RFNF/IF DC RLZB DC XFXC/IF DC XFXF/IF

Engine type 6FZ RFN RLZ XFX

Cubic capacity (cc) 1749 1997 2946

Fiscal rating (hp) 78 9 14

Gearbox type BE4 5 AL4 BE4 5 AL4 BE4 5 ML5 5 4 HP 20

Gearbox ident. plate 20 DL 29 20 TP 44 20 DL 30 20 TP 42 20 DL 31 20 LE 95 20 HZ 13

IDENTIFICATION OF VEHICLES

Petrol

ESEW

J J D

2.0 HPi

J S

2 0i 16V 3.0i V61.8i 16V

Exclusive

SX-ExclusiveX-SX

10 9

Auto.Auto.Auto.

Engine families

GENERAL

Emission standard L

Type code DC RHYB DC RHZB DC RHZE DC HXB DC HXE

Engine type RHY RHZ HX

Cubic capacity (cc) 1997 2178

Fiscal rating (hp) 56 7 8 9

Gearbox type BE4 5 ML 5 AL4 ML 5 4 HP 20

Gearbox ident. plate 20 DL 32 20 LE 94 20 TP 43 20 LE 96 20 HZ 20

IDENTIFICATION OF VEHICLES

Diesel

TD ATED

2.0 HDi

TED

2.2 HDi

Engine families

SX-Exclusive

X-SXXAuto. Auto.

GENERAL

Family

Ref. Family

DX4

Body shape

Ref. Body shape

C 5- door saloon

Engine

Ref. Capacity Type Ref. Capacity Type

6FZ 1749 EW7 RHY 1997 DW10TD

RFN 1998 EW10J4 RHZ DW10ATED

RLZ EW10D HX 2179 DW12TED4

XFX 2946 ES9J4

Version (Gearbox and emission standard)

Ref. Gearbox Emission standard

BManual L4

C5 gears L5

EAutomatic L4

F4 gears L5

IDENTIFICATION OF VEHICLES

Manufacturer’s plate Factory code.

Structure. The factory code is composed of 6 figures or letters.

Example : D.C.6.F.Z.B. - D = Vehicle family. - 6FZ = Engine.

- C = Body shape. - B = Version.

- (a) Type approval number (*).

- (b) Type serial number.

-(c) Gross vehicle weight (*).

-(d) Gross train weight (*).

- (e) Maximum weight on the front axle (*).

- (f) Maximum weight on rear axle (*).

(*)= according to marketing country.

E1AP08SC

GENERAL

GENERAL SPECIFICATION : DIMENSIONS

E1AP08TD

GENERAL

GENERAL SPECIFICATION : DIMENSIONS

Exterior dimensions (mm)

Dimensions and interior volumes (mm)

Vehicles All types

(except 3.0i V6 and 2.2 HDi) 2.2 HDi 3.0i V6

Wheel base A 2750

Length (overall) B 618

Rear track on the ground C 1509 1 95 1 93

Front track on the ground D 15 1530 1528

Width (overall) E 1770

Height (overall) (*) F 1 76

Front overhang G 971

Rear overhang H 897

(*) = Vehicle in running order (vehicle empty, levels topped up).

Elbow width, front 1538

Elbow width, rear 1520

Height of boot below parcel shelf 55

Minimum floor width 1170

Boot depth at floor level 985

Volume of boot below parcel shelf (dm3)56

GENERAL

Versions 1.8i16V 2.0i16V 2.0 HPi 3.0i V6 1.8i16V 2.0i16V 3.0i V6

6FZ RFN RLZ XFX 6FZ RFN XFX

Gearbox type BE4 5 ML 5 AL4 4 HP 20

Payload 520 527 520 530 520 520 500

Unladen weight in running order 1290 1318 1325 1480 1315 1325 1520

Gross vehicle weight 1810 1845 1845 2010 1835 1845 2020

Gross train weight 3310 3345 3345 3610 3335 3345 3420

Maximum trailer weight without brakes 660 695 700 750 695 700 750

Maximum trailer weight with brakes

Incline 12% 1500 1500 1500 1600 1500 1500 1400

Incline 10% 1550 1600 1600 1700 1550 1600 1700

Incline 8% 1800 1900 1900 2000 1800 1900 2000

Maximum nose weight 75

Maximum roof rack load 75

GENERAL SPECIFICATION : WEIGHTS

Exterior dimensions (mm)

Manual gearbox Automatic gearbox
