INSTALLATION AND USER MANUAL
ECOFLEX
EF02
EF04
INSTALLATION AND USER MANUAL
ECOFLEX
V1REV3EN0622
INSTALLATION AND USER MANUAL
ECOFLEX
V1REV3EN0622
1. INTRODUCTION................................................................................................ 1
2. GENERAL INDICATIONS................................................................................... 1
3. TECHNICAL INFORMATION ............................................................................. 3
4. INSTALLATION STEPS ..................................................................................... 5
5. PLACING ECOFLEX.......................................................................................... 6
6. AIR CONNECTION............................................................................................. 7
7. HIDRAULIC CONNECTION ............................................................................... 8
8. ELECTRICAL CONNECTION............................................................................11
9. COMISSIONING. CONTROLLER......................................................................12
10. WARRANTY CONDITIONS...............................................................................22
INSTALLATION AND USER MANUAL
ECOFLEX
V1REV3EN0622
INSTALLATION AND USER MANUAL
ECOFLEX
1 V1REV3EN0622
1. INTRODUCTION
Thank you for buying a product manufactured by CLIMER TECHNOLOGY. This product, has
been manufactured according to the European Quality Standards, incorporates prime grade
materials and its correct working has been tested before it leaves our facilities.
Through this Installation and User Manual, you will be guide towards the correct and safety
installation of the product. It is necessary to carefully read this manual before making any
handling to avoid problems arising from the misuse of the product.
The company CLIMER TECHNOLOGY reserves the right to modify the information included in
this document at any time without prior notice.
2. GENERAL INDICATIONS
2.1. Safety notes
The incorrect or inappropriate use of this product could lead to hazardous situations, causing
damage or injuries to the user, third parties or even to the product itself or material goods.
-The installer has the responsibility to install the minimum safety devices (hydraulic and
electrical) set out in this Manual. In case of failure, the lack of any device may cause
burns or other injuries.
-The installer has the responsibility to inform the user about the function and placement
of the safety devices installed into the device and the installation.
-The water outlet temperature could reach 62 degrees. Do not touch the pipes while
the system is working to avoid any risk of burns.
2.2. Qualification of the installer
It is needed the technical staff have the official certification that accredits them as authorized
to handle coolants.
The installer must explain the user the application of the product and the use and
management of the unit, and he should provide the user all the documentation supplied
with the equipment.
INSTALLATION AND USER MANUAL
ECOFLEX
2 V1REV3EN0622
2.3. Package contents
The ECOFLEX system comprises the following components:
-ECOFLEX
-Silent-blocks
-User Manual
2.4. Indications about transport and unpacking the unit
The unit is supplied packed into a wooden pallet properly secured to prevent damage
during transport.
The material that CLIMER TECHNOLOGY uses to the packing are recyclables, so dispose it
in an appropriate container.
Use a forklift or hand pallet truck to transport the unit to the installation site, always
introducing the forks into the bottom of the pallet being careful not to damage the unit.
In case you identify any damage at the time of the reception of the unit, it is mandatory to
register it in the reception note of the transport company, and then, submit the complaint.
For this reason, it is recommended to make a thorough visual inspection of the goods before
signing the reception note.
INSTALLATION AND USER MANUAL
ECOFLEX
3 V1REV3EN0622
3. TECHNICAL INFORMATION
3.1. Operating Principle
Figure 1. Operating principle
DHW
Condenser:
Transfers
energy to water
Compressor
Evaporator: Extracts
energy from air
Expanssion valve
INSTALLATION AND USER MANUAL
ECOFLEX
4 V1REV3EN0622
3.2. Dimension drawings
Figure 2. Dimensions EF02
Figure 3. Dimensions EF04
Figure 4. Front and back connections
A
Power supply, 230 V/1PH/50 Hz
B
Condensate drain
C
Air intake
D
Air outlet
E
Hot water outlet, (EF02: 3/4”/ EF04: 1”)
F
Cold water inlet, (EF02: 3/4”/ EF04: 1”)
G
Temperature probe / Pump connection
INSTALLATION AND USER MANUAL
ECOFLEX
5 V1REV3EN0622
3.3. Technical data
4. INSTALLATION STEPS
Before starting the installation, check the availability of all the necessary components and tools:
-Drill
-Screwdriver
-Hydraulic installation components
-Electric installation components
Once it has been checked that it is available all the necessary components and tools, the
installer should follow the next steps:
1. Placing the ECOFLEX
2. Air connection
3. Hydraulic installation
4. Electric installation
5. Commissioning
Model
EF02
EF04
Energy efficiency class
A
A
Load profile
L
XL
Heating capacity range, W
1841 –1127
3680 –2270
Input power range, W
496 –407
990 –806
SCOP (14 °C)
2,91
3,01
Minimum air temperature, ºC
-5
Maximum water temperature, ºC
55
Refrigerant
R134a
Charge, g
950
1200
Power supply, V/ph/Hz
230 / 1 / 50
Air flow, m3/h
350
700
Maximum pressure drop (air), Pa
70
Air connection, mm
160
Mimimum water flow, L/h
250
485
Pressure drop heat exchanger, kPa
5
8
Water connection, inch
3/4
1
INSTALLATION AND USER MANUAL
ECOFLEX
6 V1REV3EN0622
5. PLACING ECOFLEX
The place where the system will be installed should allow an easy access to make maintenance
work or inspection.
Beside these factors, it is important to consider the following indications regards the installation
site:
-The system has been designed and manufactured for it indoors utilization.
-In case the system has to be placed outdoors, it must be protected against the adverse
weather conditions (direct solar radiation, rain, snow…)
-Try to place ECOFLEX as near as possible of the buffer tank.
-Installer must install the supplied Silent blocks to avoid the transmission of vibration.
The equipment allows the installation on floor or on wall. To do this, it has 4 holes to insert the
legs (supplied) or the supports to the brackets.
Figure 5. EF02 supports
Figure 6. EF04 supports
