INSTRUCTIONS FOR USING THE MACHINE
The cordless screwdriver / drill, equipped with a chuck for clamping a screw bit or drill bit. This machine is
suitable for drilling a maximum diameter of 13 mm and screwing bolts up to 10 mm. Note: Do not insert work
tools that are not dimensioned to work in the machine's chuck.
1. Put the drill bit or screw bit into the chuck. The chuck is designed for manual handling. 2. Use the rotary
selector for setting a desired maximum torque or set the mode without torque control (bit symbol). 3. Select
desired speed range at the top of the machine: mode 1 - speed 0 - 400 min - for screwdriving; mode 2 - speed
0 - 1500 min - for drilling. 4. Use the switch to select the direction of rotation. 5. Start the machine slowly by
pressing the main switch. 6. Regulation of speed can be done by applying smooth pressure on main switch.
Battery charging: If it is necessary to charge the battery, remove it by pulling it out of the machine, by
pushing on the fixing tab and pull the battery out. Connect charger to t he battery and connect the charger to
the 230V socket. The red light indicates charging. As soon as the battery is charged, the green LED lights
up. Disconnect the charger from the 230V mains and remove the battery. Be careful, always use only
original battery and original charger for this machine.
INSTRUCTIONS FOR USE
Service
źThis product is not intended for children and persons with reduced physical, sensory or mental
capabilities, or persons with limited experience and knowledge, unless supervised or instructed to
use this product with the person responsible for their safety.
źUse caution when using the product near children. Always place the product out of reach. Children
should be supervised to ensure that they do not play with the product.
źNever allow children or persons unfamiliar with this operating instructions to operate the device.
Local regulations may set a minimum age for the user. The user is responsible for damage caused to
third parties in the working area of the machine as a result of its use.
źDo not use the machine, if you are tired, under the influence of alcohol or narcotics.
źUse personal protective equipment (gloves, work shoes, eye protection, respirators, etc.) if necessa-
ry.
źSecure free clothing, long hair or jewelry so they can not be caught in moving parts of the machine.
Intended use
źThis tool should be used for DIY work and should not be considered as professional tools.
źDo not use the product for purposes other than those for which it is intended.
źFor safety reasons, the machine may not be used as a drive unit for any other tools, unless expressly
permitted by the manufacturer.
Instructions for use
źTurn the machine on and operate as instructed in the operating instructions carefully.
źBefore performing any inspection, maintenance, or repairs, unplug the charger cable from the
electrical outlet.
źOnly use tools in good working condition and for tasks they are intended for.
źOnly work with good visibility or provide sufficient artificial lighting.
źWork in a clean environment.
źMake sure to maintain a firm and stable attitude while working. Keep in mind that falls are one of the
main causes of accidents.
źEnsure that the machine is not used when working on objects under power to prevent electric shock.
Before using this tool, make sure you know the location of all electrical wires or cables inside walls
(use a metal detector for this purpose). Do not touch the chuck, bracket, or bit when working.
źUse and store the product away from flammable and volatile substances.
źDo not expose the product to extreme temperatures, direct sunlight, excessive humidity, nor place it
in an excessively dusty environment.
źDo not place the product near heaters, open fires and other appliances or heat sources.
źDo not spray the product with water or other liquid. Do not spill water or other liquids into the product.
Do not immerse the product in water or other liquids.
źNever leave the product unattended.
item 09 609
