Quick guide for Cochlear™Baha®5 Sound Processor users
Cochlear™Wireless Phone Clip
Benefits of your Cochlear™Wireless Phone Clip
• Enjoy hands-free calling direct to your Baha
Sound Processor.
• Hear your Bluetooth®-enabled navigation system
directly through your Baha sound processor.
• Discreetly adjust your Baha Sound Processor
by using the Phone Clip as a remote control.
• Stream music from a Bluetooth-enabled device.
The Phone Clip can be easily attached to clothing.
The built-in microphone will pick up and transmit your
voice, even if your phone is several feets away.
Getting started
Check with your hearing healthcare professional
whether your sound processor has been paired with
your Phone Clip. Previously paired sound processors do
not need to be paired again. If your sound processor is
not pre-paired, see below for instructions on how to
easily pair it with your Phone Clip.
Tip! Make sure that your sound processor volume is comfortably
adjusted before you change the settings with the volume control
on the Phone Clip.
4-10 inches between
mouth and Phone Clip
Product overview
Call pick-up/
hang-up button
Micro-USB connector
for charging
Sound processor
program button
Sound processor
microphone mute button
Microphone inlet
Volume control
ON/OFF switch OFF
ON
Connecting with your mobile phone
To receive or place phone calls with the Phone Clip,
the Bluetooth®functionality must be activated in your
mobile phone. Your phone might ask you to confirm
whether you would like to connect with the Phone Clip
after it is successfully paired.
If you have to connect manually, locate a list of “Paired
Devices” in your phone’s Bluetooth menu. From this list,
highlight “Hearing Aid Phone” and select “Connect.”
You are now ready to use your Phone Clip.
On some phones you can also enable “Automatic
Reconnection.” Refer to your mobile phone’s user guide
for instructions on how to do this.
Tip! In most instances, a headset symbol on the main
screen of your mobile phone will confirm that you have
successfully connected.
Using the Phone Clip
Managing calls with the call pick-up / hang-up button
Incoming calls:
To answer a call, press once.
To decline a call, double-click.
During a call:
To transfer a call started on your
phone to the phone clip, press once.
To put a call on hold, press and hold
for 2 seconds.
To make a call:
To redial the last number, double-click.
To activate voice dialing, press and
hold for 2 seconds.
Light indicators (LED)
The LED indicator at the top of your Phone Clip
functions as a multi-purpose user interface, providing
information on the status of the device.
Blinks Meaning
Normal operation (green)
Battery low (yellow)
Charging (red)
Fully charged – still connected to charger (red/green)
Ready for pairing with sound processor (yellow)
Ready for pairing with Bluetooth device (blue)
Bluetooth call active (blue)
Using the Phone Clip as a remote control
Adjust the sound processor’s volume.
Press once to mute and unmute the
sound processor’s microphones.
Press one or more times to toggle
through the sound processor’s programs.
When you’re not on the phone,
the Phone Clip can also be used
as a simple remote control for
your sound processor(s).
Charging the battery
Plug one end of the included micro-USB charging cable
into the Phone Clip and the other into a computer, or
into a power outlet via the supplied adapter.
When the red LED indicator on top of the Phone Clip
turns green with a red blink every 2 seconds charging
is complete.
The first time you charge your Phone Clip allow it to
charge for at least 3 hours, even if the indicator light
shows a full charge. The battery cannot be overcharged.
Note: The Phone Clip provides 6 hours of talk time or 80 hours of
standby time from a full charge.
Pairing with your Baha Sound Processor
Switch off your Baha Sound Processor
by opening the battery door.
1Press the white pairing button on the Phone Clip
once using the tip of a pen or similar object.
3
Switch on
Remove cap
Switch on your Phone Clip and remove
the silver cap.
2
While pairing mode is active, switch on your
sound processor by closing the battery door.
5
The LED will flash yellow every two seconds and the
Phone Clip will now be in pairing mode for 20 seconds.
4
Successful pairing will be indicated by an
audible melody played in the sound processor.
6
Pairing with your mobile phone
Switch on
Remove
cap
Switch on your Phone Clip and remove the silver cap.
1
Make sure your mobile phone’s Bluetooth®function is
switched on. Refer to your mobile phone user guide or
visit www.jabra.com for instructions.
2
LED
Press the blue Bluetooth pairing button on the Phone Clip
once to activate the pairing mode for 2 minutes. During
pairing the LED will turn blue.
3
On your mobile phone search for new Bluetooth devices and
select “Hearing Aid Phone” from the list.
4
If your mobile phone asks for a passcode,
enter “0000” (four zeros).
5
Your Phone Clip is now paired with your mobile phone.
If your mobile phone asks which Bluetooth service you wish
to enable, select “Headset”.
6
BUN349 ISS2 SEP16
Cochlear Americas
13059 East Peakview Avenue
Centennial, CO 80111 USA
Telephone: 1 303 790 9010
Support: 1 800 483 3123
Cochlear Canada Inc.
2500-120 Adelaide Street West
Toronto, ON M5H 1T1 Canada
Telephone: 1 416 972 5082
Fax: 1 416 972 5083
www.Cochlear.com/US
©Cochlear Limited 2016. All rights reserved. Hear now. And always and other trademarks and registered
trademarks are the property of Cochlear Limited or Cochlear Bone Anchored Solutions AB. The names of
actual companies and products mentioned herein may be the trademarks of their respective owners.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Cochlear is under license.
Support
For full details about the Cochlear Wireless Phone Clip,
please refer to the User Manual.
For full details about the Cochlear Baha Sound Processor,
please refer to the User Manual part A.
Visit www.Cochlear.com/US to learn about
our full range of apps and wireless accessories.
