Coffee Queen Harmony Bedienungsanleitung
Yourretaildealer
...............................................................................
...............................................................................
User manual
”...WITH A PASSION FOR COFFEE”
Rev. 080215
U / GB
Harmony
COFFEE QUEEN
...............................................................................
...............................................................................
1. Table (list) of contents.
1. Tableofcontents page. 2
2. General 3
3. Overviewofcomponentsfront 4
3. Overviewofcomponentsmixingsystem 5
4. SERVICE:Installationandstart 6 - 7
Placethe brewer
Connections:Electricity/Water
Startingupmachine
Fillcanisters with ingredients
Fillbean container with coffee beans
5. Operation
Brewingof coffeein cup 8
Brewingof jug 9
6. Cleaningprogram
Automaticcleaning of mixingbowls 10
AutomaticcleaningofIn/Outletvalves 11
Rotatebrewmechanism withoutwater or ingredients 12
Automaticcleaning of brewmechanism, mixingbowl 13-14
7. Weeklycleaning
dismantlemixersystem 15
washtheseparts 15
assemblemixer system 16
8. Cleaningandmaintenance
Outwardcleaningandwhen needed 17
Cleaning,grinder 17
Cleaningand dismantlingof coffee filter 18
8. Maintenance,grinder 19
9. Cup counterand Easyaccess 20
10. Safetyfunctions 21
11. Failure messages 21
12. Storage/Transport. 21
13. Dimensionsketch 22
14. Circuit diagram. 23
15. Installationofcoinmechanism 24
2.
2. General. Harmony
We congratulate toyour choiceofa CoffeeQueen Harmony Freshbrewmachine.
Please read this manual before you take the machine into operation for the first time.
Themanualcontains importantinstructions for asafe andproperuse ofthe machine.
Alwayskeepthis manualwithin reach forthe user!
Coffee Queen / Harmony
- Makingfreshlycoffee cupbycup
- Withan internalgrinder for grinding of coffee beans
- Jugfacilitywith key switch
- 10 choices of drinks,
- 3ingredientscanisters +bean container,
- Brewingmechanismwith coffeefilter
- Electronicallytemperaturecontrolled
- Adjustablecoffeestrength
- Illuminatedcupwhilebrewing
- Clockfunctions
Facts:
Height 925 mm
Width 420 mm
Depth 580 mm
Weight 43kg(+groundcabinet 25kg) packing approx.5kg
Tankage 2,4 litre
Electricity 230V/2200W
Waterconnection ½”outside thread (enclosed)
Ingredientscanisters 1. espresso
1.chocolate
1.topping
1.coffee beans
3.
3. Overview of components, front Harmony
4.
Outlet for drinks
Cupholder
Drip tray insert
Drip tray
Drinks
Door lock
Display
Strength of drinks ++ / - -
Key switch
Bean container
Lid, bean container
Optional:
Base cabinet with storage and
largewaste bin.
3. Overview of components, mixer system. Harmony
5.
Detail;Ingredients; Width; Height; Capacity./cups Volume/litre Amount/unit
Canister; coffee beans 165 190 2,5kg / 208 7,3 1
Canister; espresso 67 250 0,5kg / 220 2,55 1
Canister; chocolate 67 250 1,5kg / 50 2,55 1
Canister; topping 67 250 1,1kg / 120 2,55 1
Brewing
mechanism
Outlet
drinks Waste box
Bean
container
ON/OFF
switch
FUSE holder
Grinder
Mixer bowls
Chute
Ingredients-
canister
Door lock
6.
ON / OFF
switch
4. Service. Installation and start Harmony
1. Placethe breweron aflat Connect theelectrical plugto aseparate
levelandwaterproofsurface. grounded wall socket230V 10A
OBSERVE!
Make sure there is a space behind
the machine for free flow of air.
( minimum 10cm ).
2. Connectattached watertube to coldwater withan R 1/2”.
Makesurethat thewater hose notare kinkedanywherewhen machineis
pushedinto place.
Please flush water tube before connecting it to machine, this to avoid any
particles to damage the inlet valve.
3. Openthewaterinlet.
4. Turnon the ON-OFFswitchinside thedoor.
Water is beenfilled intothetankautomatically with
2,4 litresof water.Theheatingwill not startbefore
thewaterlevelreaches thelevelsensor.
Set temperature is approx 97ºC.
5. Close door.
90º
7.
4. Service. Installation and start Harmony
6. Fill canisters with ingredients.
Takeout(this toavoidunnecessary
spillagein the machine)ingredient
canistersandfill themwithingredients.
7. When placing the ingredient canisters;
Makesure that theoutlet pipeson the
ingredientcanisters are touchingthe steam
traps(A).
(A).
(A).
8. Fill bean container with coffee beans.
1.Remove lidon beancontainer and fill bean
containerwith coffeebeans without
additives (as tasted oils or sugar).
2.Openclosing hatchon bean container.
When water in tank have the right temperature
the message ”Low temp.” will disappear and ”please wait”
the machine is ready to use.
8.
Brewing of coffee in cup, etc.
1. Placea cup in the centreof thecup holder..
2. The strength has a standard setting,
if you wish to increase or decrease it, do as follows
ifnot continue topoint 3.
Stronger drink;
Increase by pushing + or ++ for 5% or 10%
alternative
Weaker drink;
Decrease by pushing - or -- for 5% or 10%
(theindication lampwill goup ordown
dependingof choice).
3. Choosedrinkby pushingonthe buttontothe right
ofeachmenu.
The display will show; ”Please wait”, and the cup
willbeilluminated.
Wait until thelight oncup andmessage
”Please wait”
hasbeenturned offbeforeyou take yourcup.
Enjoyyourdrink.
5. Operation: Brewing of coffee in cup Harmony
2.
3.
Brewing of jug.
1. Liftupthecupholder.
Placea jugin thecentre of drip tray.
2. Turnonthe keywithjugsymboleclockwise.
3. 6cups of brewing is standardsettings,
Changeamountof cupsbypushing + or- button.
Optionalup to12 cups ordown to1 cup brewing.
4. Pushthebutton for drink1.
Wait until the light and message ”Pleasewait” has
beenturnedoff beforeyoutake out thejug.
Servea jugwith goodcoffee.
5. Operation: Brewing of jug Harmony
9.
Serving pot 1, 8L
art.nr.110001
Servingpot 1,2L
art.nr.1103091
2. 3.
4
1
10.
6. Cleaning program. Harmony
2.
By cleaning means that water is flushed and whipper motor rotates.
Themixer bowls caneasily becleaned with thekey switch
in”cup”(normal) position.
Automatic cleaning of mixer bowl No:2
Weekly cleaning! Automatic cleaning of mixing bowls 2 or 3.
Ifyouonly wish tocleanthe mixer bowlandwhipper house;Followthese
instructions:
1. Place a jug in the drip tray.
2. Turnthe key (1)slowly ninety degreesandback again.
3. Push button (3) for 6 seconds.
After4seconds thesignal willgo faster.
After6 seconds the mixer bowland thewhipper houseno.2
startsto be cleaned for5 seconds.
The display shows: ”Cleaning 2”.
Automatic cleaning of mixer bowl No:3
1. Place a jug in the drip tray.
2. Turnthe key slowlyninetydegrees andbackagain.
4. Push button (4) for 6 seconds.
After4seconds thesignal willgo faster.
After6 seconds the mixer bowland thewhipper houseno.3
startsto be cleaned for5 seconds.
The display shows: ”Cleaning 3”.
3.
4.
