RF500A GATEWAY

SYSTEM MANUAL

RF500A Gateway System Manual

Contents

Check Packed Items.........................................................................................................................................................5

RF500A Gateway.................................................................................................................................................5

RF500 Transmitters.............................................................................................................................................5

RF500 Product Range......................................................................................................................................................6

RF500 Gateway...................................................................................................................................................6

RF500 Transmitters are available as follows:.......................................................................................................6

RF512 Temperature Transmitter............................................................................................................ 6

RF512M Temperature Transmitter Backbone Option..............................................................................6

RF513 Temperature and Humidity Transmitter.......................................................................................6

RF513M Temperature and Humidity Transmitter Backbone Option........................................................6

RF515 Analog Input Transmitter and RF515A Connection Box.............................................................7

RF516 Precision Temperature Transmitter..............................................................................................7

RF542 Temperature Transmitter ............................................................................................................7

Optional Accessories...........................................................................................................................................7

Safety Information.............................................................................................................................................................8

Warning................................................................................................................................................................8

WEEE..................................................................................................................................................................9

Powering On and Off......................................................................................................................................................10

Switch On..........................................................................................................................................................10

Gateway Switch OFF.........................................................................................................................................11

Gateway Reset .................................................................................................................................................11

Transmitter Activation........................................................................................................................................12

RF500A-CONFIG - RF500A Conguration Utility............................................................................................................13

Requirements for RF500A-CONFIG...................................................................................................................13

Installation of USB Drivers.................................................................................................................................13

Obtain Comark USB Drivers..................................................................................................................13

USB Driver Installation Instructions.......................................................................................................14

InstallationofRF500A-CONFIG..........................................................................................................................15

Obtain RF500A-CONFIG Utility.............................................................................................................15

RF500A-CONFIG Installation Instructions.............................................................................................15

Running RF500A-CONFIG for the First Time.......................................................................................16

Gateway Commissioning................................................................................................................................................17

Requirements for Commissioning.......................................................................................................................17

Setting of Gateway IP Address using RF500A-CONFIG....................................................................................17

Viewing the Gateway Login Page......................................................................................................................19

Setup of First Administrator.................................................................................................................................20

Gateway Language............................................................................................................................................20

Gateway Name..................................................................................................................................................21

GatewayClockSetup..........................................................................................................................................21

Network Setup...................................................................................................................................................22

Network Details ....................................................................................................................................22

Gateway Programming and Use ....................................................................................................................................23

RF500 System Components...........................................................................................................................................24

Know your Gateway...........................................................................................................................................24

RF500A Front Panel Indicators..............................................................................................................24

BottomConnections...............................................................................................................................25

AlarmOutputs........................................................................................................................................26

Side Switches and Indicators.................................................................................................................26

Know your Transmitter.......................................................................................................................................27

Transmitter Display.................................................................................................................................29

RF542 Network Transmitter - Detailed Operation .............................................................................................30

Connections to Network .......................................................................................................................30

RF542 Setup Procedure.......................................................................................................................31

Equipment Installation.....................................................................................................................................................33

Gateway Fixing..................................................................................................................................................33

Transmitter Fixing..............................................................................................................................................33

Mains Wiring......................................................................................................................................................33

Ventilation..........................................................................................................................................................33

RF500 Wireless Monitoring System Overview................................................................................................................34

Gateway – Introduction......................................................................................................................................34

Overview of RF500 Mesh Networking................................................................................................................35

Meshing Transmitters and Backbone Transmitters.............................................................................................37

Automatic Data Retrieval (ADR)........................................................................................................................37

Gateway Specication – RF500A....................................................................................................................................38

Transmitters Specication...............................................................................................................................................39

RF542 Network Specication..............................................................................................................................42

Changing Lithium Battery on RF500 Series Transmitters...............................................................................................43

Battery Reordering.............................................................................................................................................43

BatteryChangeProcedure..................................................................................................................................44

Check for Transmitter Errors...............................................................................................................................45

Gateway Indication of Low Battery......................................................................................................................45

Pinout and Wiring............................................................................................................................................................46

Door Connector .................................................................................................................................................46

Power Connector...............................................................................................................................................46

Lumberg Connector...........................................................................................................................................47

Gateway Relay Outputs ....................................................................................................................................48

FCC Approvals................................................................................................................................................................49

Equipment Ratings..........................................................................................................................................................50

Supply Voltage...................................................................................................................................................50

EnvironmentalConditions...................................................................................................................................50

Gateway Storage/Operating Conditions................................................................................................50

RF51X Transmitter Operating Conditions..............................................................................................50

RF542 Transmitter Operating Conditions.............................................................................................51

RF5XX Transmitter Storage Conditions.................................................................................................51

RF515 Maximum Input Conditions......................................................................................................................51

Maintenance and Cleaning.............................................................................................................................................52

Service and Repair..........................................................................................................................................................52

EC-Declaration of Conformity.........................................................................................................................................53

Transmitter Fault Codes..................................................................................................................................................54

Gateway Fault Conditions...............................................................................................................................................55

Appendix A – Gateway Connection via RJ45 Cross-Over Ethernet Cable......................................................................56

Appendix B - Setting a Fixed IP Address.........................................................................................................................57

Denitions of Gateway Terminology.................................................................................................................................59

Glossary..........................................................................................................................................................................62

Check Packed Items

Please conrm that the kit contents are all present and correct. If you believe any parts are missing or damaged

please contact Comark or your local Distributor to arrange replacements.

Software and USB drivers are no longer provided on CD and can be downloaded free of charge from our website.

See “RF500A-CONFIG - RF500A Conguration Utility” {Page 13} for instructions on how to download and install the

software and drivers.

RF500A Gateway

The RF500A Gateway is available in two variants:

• RF500A Standard

• RF500AP Power over Ethernet enabled

The actual Gateway model is indicated on the side label by a check

mark adjacent to the model code.

The RF500A and RF500AP Gateway Kits consist of the following items:

• RF500A Gateway Part No. RF500A or RF500AP

• Transmitter Activator Part No. RF525

• High Gain Antenna Part No. RF504

• AC Adaptor with Mains Lead with either UK, EU or US plug

• Ethernet Cable

• USB Cable (Required for conguration only)

RF500 Transmitters

RF512, RF513, RF515 & RF516 transmitters are packed with a mounting bracket and 2-tie-wraps.

RF542 transmitters are additionally packed with:

1x RF520 AC Adaptor including regional mains plug attachment

1x Cat5e Ethernet Cable

1x RF525 Transmitter Activator

1x RF542 Quick Reference Guide

ON / OFF AUX

STATUS

1 2 3 4

RF500A

SERIAL

No.

Comark Instruments, 52 Hurricane way,

Norwich, Norfolk, NR6 6JB. UK

Tel: 01603 (+44 1603) 256647

Email: [email protected]

www.comarkltd.com

Comark Instruments, PO Box 9090,

Everett, WA 98206, USA

Tel: (503) 643 5204

Email: service@comarkUSA.com

www.comarkUSA.com

RF500AP

MADE IN UK

FOR INDOOR USE ONLY

DO NOT MOVE WHEN

IN OPERATION

RF500 Product Range

RF500 Gateway

The RF500 Gateway is available in two variants:

• RF500A Standard

• RF500AP Power over Ethernet enabled

RF500 Transmitters are available as follows:

RF512 Temperature Transmitter

• Integral temperature sensor plus connectors for two external temperature sensors and an external door

sensor

• External temperature range: –40°C to +125°C

RF512M Temperature Transmitter Backbone Option

• Integral temperature sensor plus connectors for two external temperature sensors and an external door

sensor

• External temperature range: –40°C to +125°C

• Includes High Gain Antenna and RF520 AC adaptor

RF513 Temperature and Humidity Transmitter

• Integral temperature sensor, one integral humidity sensor and connector for an external door sensor

• Integral temperature range: –30°C to +70°C

• Humidity range: 10-90% RH

RF513M Temperature and Humidity Transmitter Backbone Option

• Integral temperature sensor, one integral humidity sensor and connector for an external door sensor

• Integral temperature range: –30°C to +70°C

• Humidity range: 10-90% RH

• Includes High Gain Antenna and RF520 AC adaptor

RF515 Analog Input Transmitter and RF515A Connection Box

• Two analog input channels, each capable of conguration as 0-1V, 0-10V or 4-20mA using RF515A

connection box

RF516 Precision Temperature Transmitter

• Integral temperature sensor, and connector for one external temperature Pt100 sensor and an external door

sensor

• External temperature range: –200°C to +400°C

RF542 Temperature Transmitter

• Connectors for two external temperature sensors and an external door sensor

• External temperature range: –40°C to +125°C

• Includes RF520 AC adaptor

Optional Accessories

RF520 AC adaptor for RF512, RF513, RF516 and RF542

RF502 RF Bridge - 0.5m lead to enable transmission through RF resistant barriers

RF503 RF Bridge - 1.0m lead to enable transmission through RF resistant barriers

RF515A 2-Channel Terminal Box with 0.25m lead terminated with 6-Pin Lumberg Plug

Includes two sets of 10R, 2K and 18K2 precision resistors

RF521 Door Sensor for hinged doors

RF522 Door Sensor for roller shutter type doors

RF525 Transmitter Activator

RFJACK Alarm Output jack (2.5mm)

RFALARM Alarm Output lead - 2m g-8 wire terminated with 2.5mm jack

Safety Information

Under no circumstances may a user make any changes to the RF500A Gateway that would alter its performance. Any

modication would void the CE compliance of the Gateway and may invalidate the warranty.

If the equipment is used in a manner not specied by Comark Instruments, then the protection provided by the

equipment may be impaired.

No user serviceable parts are provided in RF500 Comark Wireless Monitoring Equipment. Contact Comark

Instruments or your local distributor for all service requirements.

Warning

• Before connecting or disconnecting the antenna, ensure anti-static precautions are observed.

• Use only the FRIWO 12V AC adaptor; Type FW74010/12 as supplied with the RF500A Gateway.

• Do not modify the RF500A Gateway AC adaptor in any way.

• Use only the PHIHONG, PSM11R-050 5V AC adaptor or FRIWO type FW7662/05 with RF500 transmitters.

It is supplied by Comark Instruments as three variants:

RF520 Transmitter AC adaptor with UK mains plug

RF520/EU Transmitter AC adaptor with European mains plug

RF520/US Transmitter AC adaptor with North American mains plug

RF520/AUS Transmitter AC adaptor with Australian mains plug

• Do not modify the AC adaptor in any way.

• RF500 transmitters contain a C-size lithium cell (AA-size for RF542). This cell must not be incinerated or

subjected to temperatures in excess of 100°C. Do not deform, mutilate, crush, pierce, disassemble, recharge

or short circuit. Such abuse can result in loss of seal, and/or cell explosion. Also exposure to humid conditions

for long periods should be avoided.

• Do not insert metal objects into connectors.

• Ensure the antenna is securely connected before powering the equipment. Internal damage may result

otherwise.

• The Gateway and Transmitters have been designed to operate with the antenna supplied by Comark, and

having a maximum gain of 7dBi. Antennas not supplied by Comark Instruments or having a gain of greater

than 7dBi are strictly prohibited for use with this device.

WEEE

RF512, RF513, RF515, RF516 and RF542 transmitters contain a non rechargeable lithium

battery. This battery must be disposed of in accordance with local regulations.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Comark Tor Handbücher

Comark

Comark RF500 Benutzerhandbuch

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

Huawei

Huawei EchoLife HG620 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung
