Comfee CO-A181ABK Bedienungsanleitung
INSTRUCTION MANUAL
AIR FRYER OVEN
C O - A 181A ( B K )
DIRECTORY
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE.
If you follow the instructions, your oven will provide you with many
years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY.
SPECIFICATIONS ....................................................................................................................................
IMPORTANT SAFEGUARDS.................................................................................................................
PARTS AND ACCESSORIES...............................................................................................................
FEATURES AND BENEFITS....................................................................................................................
BEFORE YOUR FIRST USE.....................................................................................................................
OPERATION .............................................................................................................................................
CARE AND CLEANING .........................................................................................................................
EN-2
EN-3
EN-7
EN-8
EN-9
EN-10
EN-12
EN-2
SPECIFICATIONS
Gross Weight
120V~ 60Hz
1500W
Parameter
Model
Rated Voltage
Power
Product Size (LxWxH)
Content
14.41*13.98*14.49 inch / 366*355*368mm
22.04 lbs / 10 Kgs
CO-A181A(BK)
EN-3
When using an electrical appliance, basic safety
precautions should always be followed, including
the following:
1. Read all instructions.
2. Unplug from outlet when not in use and before
cleaning. Allow to cool before cleaning or handling,
putting on or taking off parts.
3. Do not touch hot surfaces. Use handles, or knobs.
4. To protect against electrical shock, do not place
any part of the Air Fryer Oven in water or other
liquids. See instructions for cleaning.
5. This appliance should not be used by or near
children or individuals with certain disabilities.
6. Do not operate any appliance with a damaged
cord or plug, or after the appliance has
malfunctioned or has been dropped or damaged
in any way or is not operating properly. Return the
Air Fryer Oven to the store or retailer where
purchased for examination or repair, or adjustment.
7. The use of accessory attachments not recommended
may cause injury.
8. Do not use outdoors.
9. Do not let cord hang over the edge of the table or
countertop, where it could be pulled on inadvertently
by children or pets, or touch hot surfaces, which
could damage the cord.
IMPORTANT SAFEGUARDS
EN-4
10. Do not place Air Fryer Oven on or near a hot gas
or electric burner or in a heated oven.
11. Do not use this Air Fryer Oven for anything other
than its intended purpose.
12. Extreme caution should be exercised when using
containers constructed of materials other than
metal or glass in the oven.
13. To avoid burns, use extreme caution when removing
Air Fryer Oven accessories or disposing of hot grease.
14. When not in use, always unplug the unit. Do not
store any materials other than manufacturer’s
recommended oven proof accessories in this Air
Fryer Oven.
15. Do not place any of the following materials in the
Air Fryer Oven: paper, cardboard, plastic and similar
products.
16. Do not cover Crumb Tray or any part of the oven
with metal foil. This will cause over heating of the
oven.
17. Oversize foods, metal foil packages and utensils
must not be inserted in the Air Fryer Oven, as they
may involve a risk of fire or electric shock.
18. A fire may occur if the Air Fryer Oven is covered or
touching flammable materials such as curtains,
draperies or walls, when in operation.Do not store
any items on top of the appliance when in operation.
Do not to operate under wall cabinets.
19. Do not clean with metal scouring pads. Pieces can
break off the pad and touch electrical parts,
involving a risk of electric shock.
EN-5
20. Do not attempt to dislodge food when the Air Fryer
Oven is plugged into electrical outlet.
21. Warning: To avoid possibility of fire, NEVER leave
Air Fryer Oven unattended during use.
22. Use recommended temperature settings for all
cooking/baking,roasting and Air Frying.
23. Do not rest cooking utensils or baking dishes on
glass door.
24. Turn the ON/Oven Timer and the ON/Toaster Timer
dials to the OFF position to turn off the Air Fryer
Oven.
25. Do not operate your appliance in an appliance
garage or under a wall cabinet.When storing in an
appliance garage, always unplug the unit from the
electrical outlet. Not doing so could create a risk
of fire, especially if the appliance touches the walls
of the garage or the door touches the unit as it
closes.
26. Extreme caution must be used when moving an
appliance containing hot oilor other hot liquids.
27. To disconnect, turn any control to "off", then remove
plug from wall outlet.
28. A fire may occur if the Air Fryer Oven is covered or
touching flammable material, including curtains,
draperies, walls, and the like, when in operation.
Do not store any item on top of the appliance
when in operation.
SAVE THESE INSTRUCTIONS
EN-6
Please read and keep these instructions handy. These
instructions will help you use your Air Fryer Oven to its
fullest so that you will achieve consistent, professional
results.
SPECIAL CORD SET INSTRUCTIONS
A short power-supply cord is provided to reduce the
risks resulting from becoming entangled in or tripping
over a longer cord.Extension cords are available and
may be used if care is exercised in their use.If an
extension cord is used, the marked electrical rating
of the extension cord must be at least as great as the
electrical rating of the appliance, and the longer cord
should be arranged so that it will not drape over the
countertop or tabletop, where it can be tripped over
unintentionally or pulled on by children.
NOTICE
This appliance has a polarized plug (one blade is
wider than the other). As a safety feature, this plug
will fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do
not attempt to defeat this safety feature.
FOR HOUSEHOLD USE ONLY NOT
INTENDEDFOR COMMERCIAL USE
EN-7
PARTS AND ACCESSORIES
A.Rotisserie spit assembly
B.Wire rack
C.Baking pan
D.Air fryer basket
The Wire Rack can be used in three rack positions, bottom, middle, and top.
The Baking/Drip Pan is can be placed in any of the three rack positions.
Use for roasts and whole chicken. Force Shaft lengthwise through meat and
center. Slide Forks onto shaft from either end into meat, then lock in place
with Set Screws. There are indentations on the shaft for the set screws. You
can adjust the screws closer to the middle if needed but never but never
outward towards the ends.
D. Air fryer basket
The Air Fryer Basket is grated to allow air to pass through the basket for
even cooking. The Air Fryer Basket should be placed in the middle rack
position unless a recipe states otherwise.
E. Fetch rack
F. Removable crumb tray
A. Rotisserie Spit assembly
B. Wire rack
C. Baking pan
A
B
C
D
E
G
F
H . Air fryer oven
G. Rolling cage
H
EN-8
FEATURES AND BENEFITS
1.POWER ON LIGHT
Indicator light will turn on and remain lit when oven is in use.
2.ON/OFF TIME knob
Use to select time for adjusting.
3.TEMPERATURE °F knob
Use to select temperature for adjusting.
4.FUNCTION knob
Use to select different cooking functions.
5.Light Button
Push the button to turn on the interior oven light. The light will not
work if the power is off.
E. Fetch rack
The Fetch Rack is easily to take out roasted whole chicken.
F Removable crumb tray
The Removable Crumb Tray slides out from the bottom front of the Air Fryer
Oven for easy cleaning. Always ensure that the Removable Crumb Tray is
placed underneath the bottom heating elements whenever the oven is
being used.
.
The Rolling cage is used to cook small food that needs to be rotated,
such as french fries and chicken nuggets.
G.Rolling cage
5
1
432
EN-9
Oven Rack
Rack have 3 rack positions, top, middle and bottom position.
BEFORE YOUR FIRST USE
• Unpack the Air Fryer Oven and remove all packaging materials.
Clean the Air Fryer Oven according to the Care & Cleaning section
of this manual.
• Place the Air Fryer Oven, on a flat, stable, level surface. Ensure that the
oven is 2 to 4 inches away from the wall or any other objects.
• We recommend performing a trial run of your Air Fryer Oven to
eliminate any protective substance from the heating elements. Conduct the
trial run in a well-ventilated area as a small amount of smoke and odor may
be detected. This is normal and should be expected.
1.Top position
2.Middle position
3.Bottom position
