IPC-6+
www.commproduct.com
Thank you for purchasing our COMM Integrated
Control Switches!
COMM Integrated Control Switches (IPC Series) - Designed to control your
Audiovisual Equipment in the most simplified ways via RS-232 commands;
reasonably priced and works with most projectors and plasma displays.
One Touch Selection with LED Back-Lit Indications on the selectors’ buttons,
you can easily control your displays with its various selector buttons (e.g.
select the different input source, volume and/or screen controls etc)
Built-In Signal Amplifiers of 250MHz / 350MHz bandwidths to minimize
signal-loss worries.
Widely used in Classrooms, Auditoriums, Lecture Theatres, Conference
Rooms etc.
MAIN FEATURES
•Display Controller for your Projector, Display
(Power ON/OFF, input source selections, volume control) via RS232
Commands
•One Touch Selection with LED Back-Lit Indications
•INPUTS :1 HDMI, 2 USB Type B , 2 VGA with 2 mini jack audio, 1 mini jack
Microphone
•OUTPUTS: 1 HDMI, 1 USB and 2 VGA
•Built-In VGA Selector and VGA Splitter
•Digital Volume Control for sound level adjustments
•Volume Control Knob for MIC Inputs sound adjustments
•Optional: Comm Contact Relay Module for Screen Control
•STANDBY mode - MIC Volume Control usable
•VGA Monitor Out - Monitor is usable even when projector is OFF
A
www.commproduct.com
TABLE OF CONTENTS
1Function Keys……………………….…..... 1
2Internal Board Connections……….….... 2
3Connections………………………….….… 3
3.1 HDMI Connections…………….….....3
3.2 Power Connections………………... 4
3.3 RS-232 Connections……………..... 5
3.4 Audio/VGA/ USB Connection ...…. 6
3.5 Contact Relay Module .................... 7
4 Specifications……………………..…….… 8
5Standard Package……………………..…. 9
6Troubleshooting……………….................10
7Notes……………………………….………..11
8Connections Diagram…………………… 12
B
www.commproduct.com
1
1. Function Keys
1 2 3 4 5 6
19 8
17
7
15
16
11
14 13
10
9
12
Model No: IPC-6+
1. Display ON
2. Display OFF
3. Picture Blank Toggle Button
4. Mute ON/OFF
5. Screen/ Volume Control DOWN
6. Screen Selector
7. Screen/ Volume Control UP
8. HDMI with USB 2 / Wireless
Selector
9. Audio Selector
10. HDMI Signal Input
11. HDMI Reset
12. VGA Signal Monitor Out
13. VGA 2 Signal and Audio Input
14. VGA 1 Signal and Audio Input
15. MIC In –3.5mm
16. MIC Volume Control Knob
17. USB 2 Input
18. USB 1 Input
19. PC1 / USB1 or PC2 / USB2
Signal In Selector
18
13
14
www.commproduct.com
14
1. RS232 Connection
2. Dip-Switch Settings
3. Programming Connection
4. Power Connection
5. HDMI Connection
6. Mini Jack Audio Connection
7. USB Connection
8. Screen control (Optional CRM-1- contact relay
module)
9. VGA Connection
3
68
2
2. Internal Board Connections
2
5
79
www.commproduct.com
1. HDMI (Female)
3.1. HDMI Connection
1
3
www.commproduct.com
3.2. Power Connection
OR
2. Positive + on Power Adapter
3. Negative - on Power Adapter
1. Direct plug-in to 12V DC Power Adapter
(Power Adapter Supplied with every purchase)
1
2
3
4
www.commproduct.com
3.3. RS232 Connection
21
1.Ground (GND) –RS232 to Projector (GND)
2.Transmit (TX) –RS232 to Projector Received (RXD)
Please refer to Dip Switch Settings (Separate Appendix)
for the different projectors’ settings.
5
www.commproduct.com
10 1112
10. Audio Left
11. Audio Right & Left Ground
12. Audio Right
13. Mini Jack Audio
14. GND (Black)
15. D - (Green)
16. D + (White)
17. VBUS Red
3.4. Audio, VGA & USB Connection
6
13
1 2 3 4 5 6 7 8 9
1. Red
2. Red Ground (GND)
3. Green
4. Green Ground
5. Blue
6. Blue Ground
7. H Ground (GND)
8. V Ground (GND)
9. H/V Ground (GND)
14 15 16 17
www.commproduct.com
3.5. Contact Relay Module Connection
Contact Relay Module CRM-1
(Optional Item for Screen Control)
7
1
2
3
4
4 3 2 1
Connection:
1: Ground (Red)
2: UP (Blue)
3: Down (Green)
4: 5VDC (White)
