Thank You for purchasing this ASAP product!
Operation
The ASAP DR401 is a 4-port device designed to operate with the
phone company's Distinctive Ring service, allowing connection of up
to 4 separate telecommunication devices to a single telephone line.
The phone company's Distinctive Ring service (DRS) is offered in
most areas across the U.S. Phone companies offer this service under
various names, check with your local phone company for details.
When multiple phone numbers are added to a single line, the ASAP
DR401 works smoothly to process calls without depending on access
codes or transfer tones.
The ASAP DR401 will suppress the first incoming ring from passing
to any ports. The second ring will be transferred to the appropriate
port as designated:
port P1 ----- standard ring
port P2 ----- two-burst ring (short-short)
port P3 ----- three-burst ring
(short-short-long), (short-short-short),
(long-long-long), (long-short-short),
(short-long-long)
port P4 ----- three-burst ring
(short-long-short), (long-short-long),
(long-long-short)
1
The ASAP DR401 can be used in virtually any application. Listed
below are a few of the most common applications using the ASAP
DR401:
Children's Rooms Offices, breakrooms, & lobbies
Roommates Credit authorization terminals
Phone, fax, computer Departments in a retail
Multiple offices environment
Security systems Tank sensing devices
Polling equipment for remote
locations
Each device is allowed unlimited and exclusive connection time to the
phone line. Any other device connected to the ASAP DR401
attempting to access the line during a call will receive a busy tone
until the original call is complete.
Space is provided on the ASAP DR401 faceplate for documentation
of connected devices. The corresponding red LED (Light Emitting
Diode) will light when a device is connected to the telephone line.
WARNING: According to standard industry practice, surge protection
is recommended for use with all electronic devices. A surge
suppressor and/or line conditioning should be used on the input power
supply, as well as the connected telephone line.
Contact our toll-free Customer Service at 1-888-843-4399 for
questions about installation, operation or for application possibilities.
2
INSTALLATION (on a single telephone line)
1. Connect the incoming telephone line to the TEL LINE port.
2. Plug the small end of the AC power cord into the power
input port labeled "12 VAC" on the back of the DR401.
Plug the AC adapter into a standard 120-volt outlet. (Only
use a 12VAC, 0.4 - 1.0A, Class 2 power source with the
DR401.)
3. Connect telephone devices to the ports labeled P1, P2, P3
and P4.
* Caller ID requires service activation from the phone company.
(continued on page 4)
3
In this installation, phones not connected to the ASAP DR401 will
ring on every call regardless of the call destination. For
installation/operation without interference, see "Installation at the
DEMARC."
INSTALLATION (on a typical phone system)
4
Installation at the DEMARC
The following diagram shows an installation at the point
of DEMARC on line 1. Once connected in this configuration,
the telephones will not ring on an inbound call unless the
ASAP DR401 transfers a call to a designated port.
5
6
Three year limited warranty/Service information
WARRANTOR: Command Communications, Inc.
ELEMENTS OF WARRANTY: Command Communications, Inc.
warrants, for the duration of this warranty, the ASAP DR 401
(hereafter referred to as the "Product") to be free from defects in
materials and craftsmanship with only the limitations or exclusions set
out below.
WARRANTY DURATION: This warranty shall terminate and be of
no further effect three years after the date of original purchase of the
Product or at the time the Product is (A) damaged or not maintained
as reasonable and necessary, (B) modified, (C) improperly installed,
(D) repaired by someone other than the warrantor for defect or
malfunction covered by this warranty, (E) used in a manner or
purpose for which the Product was not intended, (F) damaged by an
act of God (such as a lightning strike), or (G) sold by the original
purchaser.
STATEMENT OF REMEDY: In the event the product does not
conform to this warranty at any time that this warranty is in effect, the
warrantor shall repair the defect, return it to you without charge for
parts, service, or any other costs incurred by the warrantor or its
representative in connection with the performance with this warranty.
This warranty does not cover or provide for the reimbursement or
payment of incidental or consequential damages. Some states do not
allow this exclusion or limitation of incidental or consequential
damages, so the above exclusion or limitation may not apply to you.
7
SERVICE INFORMATION/PROCEDURE FOR OBTAINING
PERFORMANCE OF WARRANTY:
1. Pack the ASAP DR 401 in the original carton or equivalent.
2. Enclose a copy of the bill of sale or other documentation showing
original purchase date.
3. Contact the dealer where you purchased the ASAP DR 401, or call
the service center listed below to obtain a return material
authorization number (RMA #).
4. Mail the above prepaid and insured to the warrantor at:
Command Communications, Inc.
7025 South Fulton Street, #120
Centennial, CO 80112
(303) 792-0870
Fax (303) 792-0899
Customer Service: 1-888-843-4399
Site: www.commandcommunications.net
NOTE: Any unit returned without an RMA # clearly marked on the
exterior package will be refused and returned at the sender's expense.
Command Communications, Inc. cannot be held responsible for any
loss or damage in transit.
Please retain proof of purchases to establish date of original purchase.
Your warranty starts with the date of original purchase.
8
LEGAL REMEDIES: This warranty gives you specific legal rights,
and you may also have rights that vary from state to state.
Though every effort has been made to ensure accuracy, these
instructions may include technical or typographical errors. Content of
these instructions may be changed from time to time due to product
improvement. These changes will be incorporated in new editions of
these instructions. We disclaim liability for any changes, errors, or
omissions.
International return policy
Command Communications, Inc. does not guarantee that this product
will be compatible with the telecommunications systems of all
countries. Modifications may have been made to products in order to
function in certain locations. Therefore, it is best to purchase our
products in the country in which it will be used.
If this product is purchased outside the U.S. from an authorized
Command Communications' dealer, it should be returned for repair at
the location where it was purchased, as provisions have been
established to handle warranty repair outside the U.S.
If you send the product directly to Command Communications for
repair, you will be responsible to pay all freight, handling, and
Custom charges (both ways).
9
