Compaq MP2800 Gebrauchsanweisung

QuickSpecs

Compaq MP2800 Microportable Projector

DA-10728 Canada — Version 8 — July 24, 2001

ODELS

Compaq MP2800 Microportable Projector

180228-001

Option Part Numbers

215464-001 – Lamp

QuickSpecs

Compaq MP2800 Microportable Projector

DA-10728 Canada — Version 8 — July 24, 2001

T A

LANCE

• 3 lbs (1.4 kg)/118 cubic inches (1937 cubic centimetres)

• 1100 ANSI, 1500 peak lumens

• Texas Instruments DLP technology

• Native XGA resolution

• Integrated zoom lens

• Multimedia adapter and remote control

• Two-year worldwide limited warranty

PECIFICATIONS

Brightness 1100 ANSI, 1500 peak lumens

Portability General Fits in existing notebook carrying case along with notebook

computer. Additional traveling case also included.

Size/Volume (HxWxD) 7.11 x 2.71 x 8.71 in and 118 cubic in/ 18.06 x 6.89 x 22.13

cm and 1937 cubic cm

Weight 3 lbs/1.36 kg

Casing Magnesium (Stronger than plastics; 30%lighter than

aluminum)

Display Resolution Displays native XGA (1024 x 768) resolution but will automatically scale up from VGA and SVGA or down from SXGA to fill

screen. Will also scale from Macintosh 832 x 624 compatible.

Image Quality Technology Texas Instruments Digital Light Processing (DLP) technology

Contrast 400:1 contrast full-on; 150:1 checkerboard

Colour SMPTE-C, 24 bit, 16.7M

White Point 8000° Kelvin

Uniformity 70%

Plug and Play Yes

Lens Type Adjustable Focal Length Zoom lens (1.2x) and manual

adjustable focus

Throw Ration (D/W) 2.0:1 – 2.4:1

Lens Height 6in/15.18 cm

Throw distance 3.74 to 32.8 feet/114 to 1000 cm

Offset 128% of image above centreline

Focus Manual focus via focus ring around lens

Keystoning Digital keystone correction

Connectivity Signal Interface Standard analog VGA, DVI, S-Video, RCA Video, and audio

cables

User Interface Standard Compaq 3 button OSD (includes zoom and

keystone correction), Power and Re-synch

Standards Supported VGA and DVI

USB Capabilities 8-pin to USB/RS-232 cable included with Multimedia Adapter

for remote mouse functions

Supports VGA, SVGA, XGA and SXGA resolutions

Approvals/Certifications CE Yes

C.I.S.P.R. Yes

VDE / TUV Yes

UL Approval Yes

FCC Class B Approval Yes

Multimedia Adapter Yes

Remote Control Yes

On-Screen Controls Yes

QuickSpecs

Compaq MP2800 Microportable Projector

DA-10728 Canada — Version 8 — July 24, 2001

PECIFICATIONS

(continued)

Language Selection English Yes

German Yes

French Yes

Spanish Yes

Italian Yes

Dutch Yes

Japanese

Chinese Yes

Yes

User Controls Brightness, Contrast Yes

Positioning Yes

Keystone Correction Yes

Digital Zoom Yes

Clock Yes

Clock Phase Yes

Colour Temperature Yes

Picture Control Yes

HDTV Settings Yes

Menu Location Control Yes

Power Saver Yes

Lamp Hours Yes

Lamp Hours Reset Yes

Standby Lamp Delay Yes

Serial Number Yes

Master Reset Yes

Image Control (upside down, reverse, upside down and

reversed) Yes

Tilt Feature Up to 10 degrees

Horizontal Frequency 31.5 to 80 kHz for analog signals and 31.5 to 60 kHz for digital signals

Vertical Frequency 48 to 85 Hz for analog signals and 48 to 85 Hz for digital signals

Power Consumption 5 Watts (standby)/185 Watts (full power)

Operating Temperature 50°to 104°F/10°to 40°C

Operating Humidity 20% to 80%

Video Projector is capable of displaying video from a VGA or DVI source (example: DVD on Portable PC). Video and S-Video

capability (from DVD, Camcorder, or VCR) through the included multimedia adapter

HDTV Support 720p, 1080i

Audio Multimedia adapter has integrated 8-watt Premier•Sound speaker system.

Power supply 90V to 255V (auto switching): warm restrike after 45 seconds

Lamp/Module User Replaceable

Warranty The MP2800 projector comes with a two-year worldwide limited warranty. In North America, Europe and Asia Pacific, the

Advanced Unit Replacement program offers a new or "like new" replacement of a defective unit in 48 hours during the two-

year warranty period. In all other regions, a replacement is available by mail-in. There is a 90-day standard bulb warranty.

Within the bulb warranty period, defective bulbs will be replaced via overnight shipment. Multimedia adapter comes with a

two-year worldwide limited warranty. Compaq telephone hotline support is available 7 x 24 (terms and conditions vary from

region to region).

Note: Certain restrictions and exclusions apply. For details, consult the Product Information Centre at 1-888-88-COMPAQ.

of Microsoft Corporation in the U.S. and other countries. The information in this publication is subject to change without notice. Printed in Canada.
