Comprag FV3013 Bedienungsanleitung

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

Инструкция

по эксплуатации

Компрессор COMPRAG FV3013

Цены на товар на сайте:

https://www.v-p-k.ru/f/fv-3013/

www.remeza.group

+7 (800) 778-91-20

бесплатный

www.v-p-k.ru

+7 (800) 777-83-75

бесплатный

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

No part of the text and /or diagram may be reprinted or used without the prior written permission of Comprag.

The manufacturer reserves the right to make changes to a product design in order to enhance its technological and

operational parameters without notifying the user.

The product type may considerably differ to that displayed in documents.

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

Table of contest

Safety guidelines

1.1 Symbols used in the instructions

1.2 General safety guidelines

1.3 Safety precautions for start-up

1.4 Safety precautions during operation

1.5 Safety precautions for maintenance and repair

Technical data and functional description

2.1 Technical data

2.2 General description

2.3 Function diagram and main components

2.4 Functional description

2.5 Regulating system

2.6 Electrical diagram and main components

2.7Electrical connection values

Start up

3.1 Lifting and carrying

3.2 Dimensions

3.3 Requirements on installation area

3.4 Connection to the compressed airline

3.5 Connection to power supply

Operation

4.1 Controller and operating panel

4.2 Error indication

4.3 Starting the compressor

4.4 Switching off the compressor

Maintenance

5.1 Maintenance schedule

5.2 Checking oil level

5.3 Checking drive belt

5.4 Replacing oil and oil filter

5.5 Replacing air filter

5.6 Changing drive belt

5.7 Changing air-oil separator

5.8 Cleaning radiator

5.9 Checking suction valve

5.10Servicing bearings of electric motor

Fault handling

6.1Faults and corrective actions

Storage and disposal

7.1Storage conditions

7.2 2 Disposal of oils and process condensate

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

Safety guidelines

1.1

Symbols used in the instructions.

Lethal hazard.

Warning.

Attention.

1.2

General safety guidelines.

Carefully familiarise yourself with the technical documentation, operat-

ing instructions andsafety guidelines. Most accidents as- sociated with

the use of compressor equipment occur as a result of non-compliance

with safety guidelines. Prevent hazards from developing and adhere to

the safety guidelines. The main rules are given in the following section.

The user is solely liable for injuries or damages which occur due to

non-compliance with safety guidelines during installation, opera-

tion or servicing, as well as unauthorised use of equipment!

1. The operator must stringently adhere to safety guidelines provided for by these instruc-

tions and local legislation!

2. When choosing between these safety guidelines and the regulations provided for by local

legislation, those rules which provide for more stringent requirements shall apply.

3. Only trained maintenance personnel with the relevant level of professional training are

permitted to operate, service and repair Comprag equipment.

4. Compressed air flowing immediately from the compressor may contain oil and impurities

and is not suitable for breathing! Compressed air has to be purified to an air purity grade

suitable for breathing, in accordance with the standards prescribed by local legislation.

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

5. Compressed air is an extremely hazardous energy source. Compressed air must not be

used for unintended purposes! Do not use it to clean clothing and footwear and never

point compressed air hoses at people and animals! When using air to clean equipment,

take extra caution and wear safety goggles!

6. All maintenance, repair, setup and installation work etc. must be performed while the

equipment is turned off, disconnected from the power source, with compressed-air hos-

es disconnected from the equipment, and with the use of safety goggles! Ensure that

equipment is disconnected from the compressed air system and is not under pressure.

1.3

Safety precautions for start-up

The user is solely liable for injuries or damages which occur due to

non-compliance with safety guidelines during installation, operati-

on or servicing, as well as unauthorised use of equipment!

1. Equipment must only be unloaded/loaded using the appropriate handling devices or

hoisters. Equipment must not be manually lifted or moved. Do not leave equipment

suspended. Use a helmet during unloading operations.

Arrange the equipment in a dry and clean facility which provides shelter from precipitation.

The facility must be well ventilated, and forced ventilation should be provided if necessary.

3. Worn, damaged or spoiled compressed-air hoses should not be used. Ensure that hoses

correspond to the equipment in terms of nominal diameter and working pressure.

4. When using several compressor stations in a system, each compressor must have a manu-

ally operated valve for cutting off any of the compressors in the case of emergency.

5. Explosive and fire-hazardous admixtures such as solvent vapours and carbon dust etc.

must not be released into the atmosphere.

6. Ensure unrestricted access to the compressed-air hose from the compressor. Do notclut-

ter it and do not store flammable materials in its immediate vicinity.

7. Do not pinch or deform the compressed-air feed hoses.

8. Do not cover holes used to provide equipment with air for cooling. Ensure the facility

is well ventilated.

9. When using remote control, the equipment must give a legible and clear warning of this:‘AT-

TENTION: this machine is being controlled remotely and may start operating without warning!’

An operator who is remotely controlling equipment must ensure that no installation or other

work is being performed with the equipment at that moment. Once the equip- ment is turned

off remotely, the operator must ensure that the equipment is actually turned off!

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

10. Equipment must be earthed. Provide short-circuit protection. The starting knife switch must be

in the immediate vicinity of the equipment and protect against unauthorised start-up.

The user bears full responsibility for compliance with the operating con-

di- tions of the electrical motor installed in the equipment. Equipment

must be used with protection devices. The protection devices must pro-

tect the electric motor from short circuits, overloading (systematic and

start-up) and open-phase conditions. Installation of protection devices is

the responsibility of the user.

11. There must be an information plate affixed next to the control panel on equipment with

an independent control system featuring an automatic restart function: ‘ATTENTION: This

machine may start operating without warning!’

12. Any tanks and vessels working under pressure must be fitted with safety-relief valves! Unau-

thorised installation, disassembly or adjustmentof attached safety-relief valves is not allowed.

1.4

Safety precautions during operation.

The user is solely liable for injuries or damages which occur due to

non-compliance with safety guidelines during installation, opera-

tion or servicing, as well as unauthorised use of equipment!

1. Ensure that hoses correspond to the equipment in terms of nominal diameter and working

pressure. Check the attachment of every hose coupling before start-up. An insecurely fastened

hose may cause serious injury.

2. Never turn on equipment if you suspect the presence of highly flammable impurities in the air!

3. The operator remotely controlling equipment must ensure that no installation or other work is

being performed with the equipment at that moment! An information plate must be affixed to

the equipment in relation to this: ‘ATTENTION: this machine is being controlled remotely and

may start operating without warning!’

4. An operator is not allowed to operate equipment if the operator is fatigued, in a state

of intoxication from alcohol, drugs or medicine that reduces the body’s reaction time.

5. The equipment must not be operated if parts of the casing have been removed. Doors or pan-

els may be opened for short durations for inspection and scheduled checks. It is advisable to

wear hearing protection.

In some types of equipment, open doors or removal of panels du-

ring operation may lead to overheating.

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

6. Personnel in conditions or a facility where the sound pressure level reaches or exceeds

90 dB (A), must wear ear protectors.

7. If the air used for cooling equipment is used while the facility is being heated, undertake

measures for it to be filtered so that it is suitable for breathing.

8. Regularly check that:

•safety devices and attachments are in place;

•all hoses and pipes are in good condition and sealed;

•there are no leaks;

•brackets and structural components are tightened;

•all electrical cables and contacts are in good condition and safe to use;

•safety devices are fully functional and there is no contamination etc;

•all structural components are in working order, with no signs of wear and tear.

1.5

Safety precautions for maintenance and repair

The user is solely liable for injuries or damages which occur due to

non-compliance with safety guidelines during installation, operati-

on or servicing, as well as unauthorised use of equipment!

1. Only original spare parts and ancillary items may be used. Using spare parts from other

manufactures may lead to unpredictable results and consequently accidents.

2. When performing installation and repair work, always wear goggles!

3. Before connecting or disconnecting equipment, disconnect it from the main pneumatic

system. Ensure that the hoses aren’t under pressure!

4. Before beginning installation or other work, ensure that equipment is not pressurised.

Installation work must not be carried out on equipment under pressure.

5. All maintenance work should be carried out only when the temperature of all structural

elements falls to room temperature.

6. Never use highly flammable solvents or carbon tetrachloride for cleaning structural ele-

ments. When wiping, take precautions against the poisonous vapours of cleaning fluids.

7. Whencarryingoutinstallationand repairwork,an informationplateshouldbe affixedto thecontrol

panelto warnagainst unauthorisedstart-up.Forexample,“Do not turn on. Personnel operating!”

8. The operator remotely controlling equipment must ensure that no installation or other

work is being performed with the equipment at that moment! An information plate must

be affixed to the equipment in relation to this: See 1.3.9.

Maintain cleanliness in the facility where the equipment is installed. Close open inlets and out-

lets during installation with dry clothes or paper to prevent rubbish entering the equipment.

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

10. Welding or other similar operations must not be carried out in the immediate vicinity of

the equipment and vessels under pressure.

11. If there is any suspicion of overheating, combustion or other emergency, turn off the equip-

ment. Immediately disconnect it from the power supply. Do not open the doors of equip-

ment until the temperature falls to room temperature, in order to prevent burns or injury.

12. Naked flames must not be used as a light source for inspecting and checking equipment.

13. Never use caustic solvents, which may damage materials of the pneumatic system.

14. After performing installation or other work, ensure that no instruments, rags or spare

parts have been left inside the equipment.

15. Pay particular attention to the safety-relief valves. Thoroughly inspect them and remove

any dust and dirt. They must not be allowed to suffer any loss in function under any cir-

cum- stances. Remember that your safety depends on their functionality!

16. Before beginning work in normal mode after maintenance or repair work, check that the

working pressure, temperature and other characteristics are correctly set. Ensure that all

control devices are installed and functioning properly.

17. When replacing filters, separators etc., wipe away dust, dirt and oil residue from the area

where they are installed with a dry cloth.

18. Protect the motor, air filter, electrical components and control components etc. from

coming into contact with condensate. For instance, blow down with dry air.

19. Use protective gloves during installation and repair work in order to avoid burns and

injury (for instance, during oil change).

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

Technical data and functional description

Entitlement to free handling of faults arising during the guarantee pe-

riod is forfeited when:

-No warranty service coupon for the compressor or it is filled out in-

correctly

No records for the compressor’s scheduled maintenance are entered

in the compressor’s service book

Unoriginal parts and lubricants are used

2.1

Technical data

Article

Model

Drive power,

compressor

(kW)

Max. operat-

ing pressure

(bar)

Output

(m3/min)

Rated

voltage,

compressor

(phase/V/Hz)

Noise

(dB)

Screw

connection

Oil

capacity,

liter

11410704

FV3008

5-8

5,10

3/380/50

1-1/4"

11410705

FV3010

5-10

4,60

11410714

FV3708

5-8

6,20

11410715

FV3710

5-10

5,50

11410804

FV4508

5-8

7,50

1-1/2"

11410805

FV4510

5-10

6,50

11410814

FV5508

5-8

9,00

11410815

FV5510

5-10

7,90

2.2

General description

The FV-Series oil-filled screw compressor series is designed for uninterrupted and efficient

compressed-air production.

The FV-Series compressor is an electric motor-operated, intake-regulated, belt-driven and air-

cooled compressor,enclosed in a sound-insulated canopy. An electronic controller pro-Log with

an LCD indicator panel is provided, including start and stop buttons and an emergency stop

button. Pressure and temperature relays are used for system control and protection.

+7 (800) 777-83-75(звонок бесплатный)

www.v-p-k.ru FV3013

2.3

Function diagram and main components

Fig. 2.3 Function diagram FV30-55

Main components

Electric motor

Min. Pressure valve

Belt drive

Non-return valve

Air end

Heat-exchanger, Air section

Air filter

Heat-exchanger, Oil section

Intake valve

Thermostatic valve

Air-Oil separation tank

Oil filter

Safety valve

Drain valve

Air-Oil separator

Oil filling plug

Throttle valve

Oil level sight glass

Non-return valve

Air outlet valve

Air ffow

T Temperature sensor

Pressure sensor
