Compuprint MDP 30FB Bedienungs- und Wartungshandbuch

Rev. 003

Table of Contents

Introduction ............................................................................2

Command Summary in

Alphabetical Order................................................................3

EPSON/IBM Mode..................................................................9

Print and Line Feed Execution ........................9

Format Control.................................................12

Print Mode ........................................................36

Character Set....................................................59

Download Character........................................67

Bit-Image...........................................................73

Data Input Control.......................................... 83

Miscellaneous................................................... 87

COMPUPRINT Mode ......................................................... 92

Format Control................................................ 92

Native Character Set...................................... 95

Bar Codes ......................................................... 98

Bar Code Description.................................... 101

Miscellaneous................................................. 113

This appendix provides information about the commands supported by your printer.

The commands are organized by function groups. Each command has both a brief and

a detailed description.

Each command has the following structure:

• Name and function description. Information about protocol (IBM Proprinter

XL24E, IBM Personal 2391, EPSON ESC/P2)

• The hexadecimal and decimal codes for the command: nrepresents variable

parameters of the command. The functions of these parameters are explained in its

corresponding command description.

BEL Buzzer. (EPSON) 87

BS Print and space back one position. (IBM, EPSON) 87

CAN Cancels line. (EPSON) 83

CAN Cancels data. (IBM) 83

CR Prints all received data and the column counter is set to the left margin.

(IBM,EPSON) 9

DC1 Selects printer. (IBM) 84

DC1 Selects printer. (EPSON) 84

DC2 Sets 10 cpi printing. (IBM) 36

DC2 Cancels compressed printing. (EPSON) 36

DC3 Deselects printer. (EPSON) 84

DC4 Cancels double width printing. (IBM, EPSON) 37

DC4 DC4 ESC ! Bar Code Selection 98

DC4 DC4 ESC (GS Prints bar code symbols (Compuprint) 113

DC4 DC4 ESC @ Re-initializes the printer. (Compuprint) 113

DC4 DC4 ESC 3 1 Sets vertical spacing 12 lines/30 mm. (Compuprint) 92

DC4 DC4 ESC 3 3 Sets vertical spacing to 3 lines/30 mm. (Compuprint) 92

DC4 DC4 ESC 3 4 Sets vertical spacing 4 lines/30 mm. (Compuprint) 93

DC4 DC4 ESC 3 6 Sets vertical spacing 6 lines/30 mm. (Compuprint) 93

DC4 DC4 ESC 3 8 Sets vertical spacing 8 lines/30 mm. (Compuprint) 93

DC4 DC4 ESC A Sets the horizontal spacing to 15, 17, 20, 24 CPI. (Compuprint) 94

DC4 DC4 ESC DC4 Printer functions. 119

DC4 DC4 ESC g Selects LQ fonts (Compuprint). 95

DC4 DC4 ESC J Sets amplification factor. (Compuprint) 114

DC4 DC4 ESC R String rotation. (Compuprint) 115

DC4 DC4 ESC r Digit rotation. (Compuprint) 115

DC4 DC4 ESC S Selects character set ISO Character Sets or Code Pages. (Compuprint) 96

DC4 DC4 ESC u Selects the program setups. (Compuprint) 117

DC4 DC4 ESC VT Search for a blank line (without any marker). (Compuprint) 118

DC4 DC4 ESC X Reads the id of the cut sheets. (Compuprint) 118

DC4 DC4 ESC Y Selects emulation. (Compuprint) 116

DC4 DC4 ESC Z Makes AGA in column. (Compuprint) 117

DEL Deletes the last character. (EPSON) 85

ESC - Sets or cancels underlined printing. (IBM, EPSON) 37

ESC ! Master Select. (EPSON) 38

ESC # Cancels MSB control. (EPSON) 85

ESC $ Sets the absolute printing position. (EPSON) 12

ESC % Selects user-defined character set. (EPSON) 67

ESC & Defines user-defined characters. (EPSON) 68

ESC ( - Sets score line. (EPSON) 39

ESC ( ^ Prints data as characters. (EPSON) 59

ESC ( c Sets Page Format. (EPSON) 14

ESC ( G Selects Graphics Mode. (EPSON) 73

ESC ( t Assigns character table. (EPSON) 60

ESC ( U Sets units. (EPSON) 16

ESC ( V Sets absolute vertical print position. (EPSON) 17

ESC ( v Sets relative vertical print position. (EPSON) 18

ESC (C Sets page length in defined unit. (EPSON) 13

ESC * Sets dot graphics printing. (EPSON) 73

ESC . Print Raster Graphics. (EPSON) 75

ESC : Sets 12 CPI. (IBM) 40

ESC : Copies characters from ROM to RAM. (EPSON) 69

ESC ? Reassigns dot graphics mode. (EPSON) 76

ESC @ Initializes the printer. (EPSON) 88

ESC [ @ Sets double high printing and double line feed. (IBM) 40

ESC [ \ Sets vertical units. (IBM) 20

ESC [ g High Resolution Graphics. (IBM) 77

ESC [ I Sets font and pitch of a character. (IBM 2391 only) 42

ESC [ K Sets initial conditions. (IBM 2391 only) 89

ESC [ T Selects a Code page. (IBM 2391 only) 61

ESC [d Set the print quality. (IBM 2391 only) 42

ESC \ Sets the relative horizontal print position. (EPSON) 20

ESC \ Prints characters from all characters table. (IBM) 63

ESC ] Sets a reverse line feed. (IBM) 10

ESC ^ Prints a single character from the all characters table. (IBM) 63

ESC _ Sets or cancels overscore printing. (IBM mode) 45

ESC + Sets n/360-inch line spacing. (EPSON) 22

ESC = Defines downloaded characters. (IBM) 70

ESC = Sets MSB to 0. (EPSON) 85

ESC > Sets MSB to 1. (EPSON) 86

ESC 0 Selects 1/8-inch line spacing. (IBM, EPSON) 22

ESC 1 Selects 7/72-inch line spacing. (IBM) 22

ESC 2 Selects 1/6-inch line spacing. (EPSON) 23

ESC 2 Enables the line spacing set by ESC A command. (IBM) 23

ESC 3 Sets n/180-inch line spacing. (EPSON) 23

ESC 3 Sets graphics line spacing at n/216 inch. (IBM) 24

ESC 4 Sets top of form (first printable line). (IBM) 24

ESC 4 Sets italics printing mode. (EPSON) 45

ESC 5 Sets an automatic line feed after a carriage return. (IBM) 10

ESC 5 Cancels italics printing. (EPSON) 46

ESC 6 Enables Upper Control Codes. (EPSON) 64

ESC 7 Selects the Character Set 1. (IBM) 64

ESC 7 Enables Upper Control Codes. (EPSON) 64

ESC A Sets text line spacing at n/60 inch. (EPSON) 25

ESC A Sets text line spacing at n/72 inch. (IBM) 25

ESC B Sets vertical tabs. (IBM, EPSON) 26

ESC C Sets form length to nlines. (IBM, EPSON) 27

ESC c Sets horizontal motion index (HMI). (IBM, EPSON) 46

ESC C 0 Sets form length to ninches. (IBM, EPSON) 26

ESC D Sets horizontal tabs. (IBM, EPSON) 27

ESC d Spaces forwards relative dot position. (IBM) 28

ESC E Sets emphasized printing. (IBM, EPSON) 47

ESC EM Loading/ejection of paper. (EPSON) 28

ESC F Cancels emphasized printing. (IBM, EPSON) 47

ESC G Sets double strike printing. (IBM, EPSON) 48

ESC g Sets 15 CPI. (EPSON) 48

ESC H Cancels double strike printing. (IBM, EPSON) 48

ESC I Selects printing type for resident and DLL characters. (IBM) 49

ESC J Advances paper n/180 inch. (EPSON) 11

ESC J Graphics variable line spacing (n/216 inch). (IBM) 29

ESC k Selects LQ fonts. (EPSON) 65

ESC K Normal density dot graphics printing (60 dpi). (IBM, EPSON) 79

ESC l Sets left margin (10 cpi). (EPSON) 29

ESC L Double density dot graphics printing (120 dpi). (IBM, EPSON) 80

ESC M Selects 10.5 point, 12 cpi. (EPSON) 50

ESC N Sets the skipover perforation to nlines. (IBM, EPSON) 30

ESC O Disables the skipover perforation. (IBM, EPSON) 31

ESC P Selects 10.5 point, 10 cpi. (EPSON) 50

ESC P Sets or cancels proportional printing. (IBM) 51

ESC p Sets or cancels proportional printing. (EPSON) 51

ESC Q Sets the right margin (10 cpi). (EPSON) 31

ESC q Selects character style. (EPSON) 52

ESC Q Deselects Printer. (IBM) 86

ESC R Sets all tabs to power-on settings. (IBM) 32

ESC R Selects an international character set. (EPSON) 66

ESC S Sets subscript or superscript printing. (IBM, EPSON) 53

ESC SI Selects condensed mode. (IBM, EPSON) 54

ESC SO Sets double width printing (one line). (IBM, EPSON) 54

ESC SP Sets intercharacter space. (EPSON) 33

ESC T Cancels subscript or superscript printing. (IBM, EPSON) 55

ESC t Selects characters table. (EPSON) 66

ESC U Sets printing direction. (IBM, EPSON) 91

ESC W Sets or cancels double width printing. (IBM, EPSON) 55

ESC w Sets or cancels double height printing. (EPSON) 56

ESC X Sets left and right margins. (IBM) 33

ESC X Selects font by pitch and point. (EPSON) 56

ESC x Selects Letter Quality or Draft printing. (EPSON) 57

ESC Y Double density dot graphics printing at double-speed graphics (120

virtual dpi). (IBM, EPSON) 81

ESC Z Quadruple density dot graphics printing (240 virtual dpi). (IBM, EPSON) 82

FF Advances paper to the top of the next page. (IBM, EPSON) 34

HT Horizontal Tab. (IBM, EPSON) 34

LF Line Feed. (IBM, EPSON) 11

SI Sets condensed printing. (IBM, EPSON) 58

SO Sets double width printing (one line). (IBM, EPSON) 59

VT Vertical Tab. (IBM, EPSON) 35
