How to fit and operate your Deluxe Roman blind
You should have:
First check you’ve got
all the fittings that
come with your blind.
Brackets: Safety hook: Wood screws:
quantity to suit x 1 chain operated x 4
length of blind
Standard fixings for the most common installations supplied
Getting started
YOU WILL NEED:
•A drill with correct bit
•A crossheaded
screwdriver
•A metal tape measure
•A pencil
•Your brackets are
packed separately in
the box. Please ensure
you’ve located them
before disposing of
the packaging.
•The brackets are a
universal type that
can be used to top fix
the blind into a recess
or face fix into a
frame or a wall.
•Please read the
following instructions
carefully before you
start fitting your blind.
1
To fix the brackets
1. Locate the measuring points you used to
calculate the width of the blind. You may be
able to use the blind as a template.
2. Ensure the brackets are positioned a suitable
distance away from any window handles or
obstructions to allow the blind to operate
smoothly.
3. Ideally, position the brackets 5cm in from
each end of the head rail. Any additional
brackets supplied should be fitted centrally.
4. Hold a bracket in position and mark where the
screws will go, using the relevant holes in the
bracket as a guide.
5. If you’re fitting to a wall or lintel, use a drill
with the suitable sized bit to make your holes,
and push in rawplugs.
6. If you’re fitting into a wooden frame, screw your
brackets into position. You may want to make pilot
holes to allow easier fixing of the screws.
7. Fix the bracket into place and repeat on
the other side of the blind.
TIP –If fitting outside the recess, use a spirit
level to ensure that the brackets are level. If a
spirit level is not available measure down
from the ceiling in three places to get the
brackets as level as possible
2
To fix the blind
1. Open the locking arm on each bracket as far
as it will go.
2. Clip the front edge of
the head rail over the
bracket, at a slight angle
away from you, then
push up into place at the
back.
3. Push the locking arms
across into the closed
position and check
the blind is secure.
4. For a neat finish you can pull the fabric
away from the rail slightly when fitting the
bracket to hide the lip on the bracket.
TIP –To slightly straighten or adjust the drop of
the blind, you can adjust the position of the
fabric by raising or lowering the fabric by
changing the position of the Velcro where it is in
contact with the headrail
HBLXXXXX -XX/XX/15 continued overleaf
Safety tips:
There are things that
you can do to reduce
risk in your home.
•Move beds, cots and
furniture away from
the window.
•Do not let cords or
chains hang loose.
Make sure they are
kept out of reach of
children at all times.
•Do not tie loose
cords and chains
together.
•Check the condition
of all safety devices
if not used regularly
and replace if the
device is faulty.
Operating
your blind:
Operating your blind
is easy. Just follow
these instructions.
•Simply pull the chain
to move the blind up
and down.
How to fit and use your
Child Safety Devices
3
Warning
Blinds can be potentially dangerous to small children. Please be aware that swallowing small parts can
cause internal asphyxiation. Looped or low hanging cords, chains or tapes can create hazardous loops
which could lead to the risk of strangulation. We do everything we can to ensure your chosen product
is child safe. As a minimum all of our blinds meet the European Standard BS EN 13120 for safety. Our
instructions and the supplied Child Safety device(s) are intended for you to ensure that your blind is as
safe as possible.
The information below gives guidance for fitting the provided child safety devices. All safety devices must
be correctly installed for the protection from strangulation of young children and the proper use of the
blind. Please read the instructions carefully and keep safe for future reference.
Only use the devices and cords provided with your blind. Videos showing how to fit and reconnect child
safety devices are available, along with replacements at www.makeitchildsafe.co.uk.
4
To reconnect the inner cord breakaway clip
1. The inner cord breakaway clip is attached to the cord and the tape on the reverse of the blind.
The clip will break away in two parts if any reasonable weight is placed between the cord and the
back of the blind.
2. One inner cord breakaway clip will be used on
each cord where it crosses a tape. See fig. 1.
fig 1
3. If the clip breaks apart, push the small c-clip section
(which will remain on the cord) onto the front of the
post part (which will remain on the tape). See fig. 2.
fig 2
4
Deluxe Roman (Sidewinder)
Fitting the safety hook
1. Put the control chain into the hook at
the maximum distance from the control
mechanism. Ensure that the chain is taut and
that the hook is at the bottom of the loop.
2. Screw the hook to a wall adjacent to the blind. If
the hook has a slot, ensure the screw is placed
at the bottom of the slot and that the chain is
taut before screwing in place. This will prevent
the hook from moving up and down during
operation and ensure that the correct tension is
maintained. See fig. 1. Fig. 1.
