Concord Camera Eye-Q 3103 Bedienungsanleitung
Quick Start Guide
Camera Nomenclature
Back
Viewfinder
LED indicator
/ Zoom In / Up button
/ Continuous shutter / Right button
Battery cover
/ Zoom Out / Down button
LCD Monitor screen
Power button
/ /Stop button
/ Self-timer / Left button
/ / Flash / / Play / / Pause button
Battery Installation
1.Openthebatterycoverbypushingandslidingittotheside.
1
Self-timer lamp
Flash Viewfinder
Microphone
Lens
Exposure sensor
Front
button Shutter button
Mode dial
Speaker
Quick Start Guide
2.Check inscription on battery chamber for correct
negative/positive installation.
3.Install2-AA alkaline batteries.
4.Close the battery cover.
Camera Working Mode
You can select the camera’s working mode by using the
Mode dial located on the top of the camera. There are 4
working modes in this camera.
Auto Photo Mode ( )
Inthis mode, the camera will automaticallyset the
exposure and white balance according to your shooting
environment.
Manual Photo Mode ( )
You can manually set the exposure and white balance before shooting.
Playback Mode ( )
1.Replay or delete images from the camera.
2. Download and display images to your computer.
Video Mode ( )
1. Use this mode to record movies.
2. Youcanalso manuallysettheexposureandwhitebalancebeforerecordingthevideo.
Ali
g
n point
2
Quick Start Guide
Taking Pictures
There are two Modes you can choose from to take a picture. In the Auto
Mode, just press the shutter button and let the camera judge the
environmentalconditionsforyou. In theManual Mode, youcanmanually
adjust the exposure and set the white balance based on different
environmental conditions.Please refer to page 21 of the user's manual.
1. Turn the Mode dial to Auto ( ) or Manual ( ).
Taking a Picture
2. Press the POWER button ( ) to power on the camera.
Using the Digital Zoom
) to zoom out.4.Press the Down button (
3.Press the UP button ( )to zoom in on the subject.
1.Turn the Mode dial to Auto ( ) or Manual ( ).
2.Turnon theLCDscreenand theInformationdisplay(if not,press
DISPbutton).
When the LCD screen is on in Auto or Manual Mode, you can zoom
in on the subject before the image is taken.
3.Press the Shutter button halfway and
align the auto focus mark on the
subject you want to take. When the focus
islocked, the auto focus mark turns green.
If the display indicators on LCD screen turn
red, this means the camera’s auto exposure
and autowhitebalance functionisnotready
or the conditions are not ideal for optimal
quality picture taking. If you take the picture despite the
conditions, the picture may be over or under exposed.
4. Take a picture by pressing the shutter button further. When the camera
beeps, the image has been captured and will be recorded on the card
3
or in the internal memory.
* The camera will not emit a beeping sound if this function is disabled.
5. During recording to the memory card, the LED indicator will flash
Green. Once the LED indicator stops flashing, the recording has
finished.
Quick Start Guide
1. Turn the Mode dial to Playback ( ). The LCD screen displays
the last recorded image.
2. Use the RIGHT/LEFT button ( /) to view different pictures.
· Press the STOP button (
Youcan view up to 9 images at atimebyusingthe THUMBNAIL function ( ).
1.Turn the Mode dial to Playback mode ().
2. The LCD screen displays the last recorded image.
3.Press button twice to enter thumbnail mode.
You can view pictures and images in Playback mode.
Viewing Pictures in Thumbnail
Deleting Pictures
You can delete a single or all images while in Playback mode ().
Deleting a Single Image
1.Turn the Mode dial to Playback mode( ).
2.
Pressthe MENU button. Use the UP/DOWN to toggle between the options.
3. Press the SET button to make your selection.
·If you press STOP while the video is playing, the video
will return to the first image.
) to stop the video.
Reviewing Your Pictures and Videos
Viewing Pictures
4.UsetheUP/DOWNbuttontohighlightthe iconandreturntothe
MENU”. Press the down button to highlight the delete icon ( ).
Deleting All Unprotected Images
1.Turn the Mode dial to Playback mode( ).
menuand notdeletethe image. PressSETto returntothe “DELETE
5. Press the SET button to confirm your selection.
2. Press MENU button.
3. Press the UP/DOWN button to toggle between the options.
4. Press the SET button. Use the UP/DOWN buttons to toggle
between CANCEL and YES.
5. Press the SET button to confirm your selection.
NOTE: ·To view video clips, press the PLAY button ().
4
Quick Start Guide
5
Downloading Images to a Computer
Installing the Driver & Software
Installing the Driver
Installing Camera Drivers (Windows 98/98SE)
If your operating system is Windows 98/98SE:
1. Insert the CD into your PC CD-ROM drive.Make sure that
your camera is not connected to the computer.
2. A red check mark appears on the left side of each installaiton
NOTE:
If your system requires a manual installation: Click Run, type “(the
3. Click on install.
4. Follow the on-screen instructions. After the installation has finished,
reboot your computer. You are now ready to install the software.
CD-ROM drive):/install.exe”, then click OK.
choice. Remove all checks except the one for the camera
driver by clicking on the checks next to each choice.
Follow the directions that follow to install all the software.
Note: You do not need to install the drivers if you are running Windows,ME, 2000 or XP.
Please go to the "Installing the Software" section.
Note to Mac users: You do not need to install drivers or software to transfer pictures.
Please see "Downloading Images to a Computer" for instructions.
Installing the Software
6
Installing the Software (Windows Users)
If your operating system is Windows 98/98SE/2000/ME/XP:
1.Insert CD into your PC CD-ROM drive.Make sure that
2.A Welcome window will be displayed.
Click [Next>] to move to the next step.
your camera is not connected to the computer.
3. Click on install.
1. Click the MGI PhotoSuite 4 SE menu on autorun frame.
2. Click on Photo Studio, Movie Studio, Video Conferencing and
Panorama tools. A red check mark should appear in the circle next
to each option. Camera Driver does not need to be checked.
You may choose to skip the software installation procedure if you already
have photo editing software loaded on your computer or if you would like
to transfer pictures without editing them.
Please refer to the Downloading Images section for instructions on transferring
pictures to you computer.
7
Installing the Software
3. The Software License Agreement window will be displayed.
If you agree to this, click [YES], the window will then move to the
next step. If you disagree, click [NO] and the install program will
be canceled.
4. Click Next to continue the installation.
5. Select Destination Location. Click on Next
8
Installing the Software
6. We suggest creating a shortcut on your desktop by selecting this
option. Click Next to continue the installation.
7. Click Next to continue the installation.
8. Start Copying Files window will displayed.
Click [Next>] to start installation.
9
Installing the Software
9. Wait while the software is installed.
10. Click Finish to complete the the setup.
11.Click Continue.
