CFP2107 Series
Intelligent Disk Drive
Product Manual
October 1995
Pre-Release
Revision A
3081 Zanker Road
San Jose, CA 95134-2128
(408) 456-4500
FCC Notice This equipment generates and uses radio frequency energy and, if not installed
and used properly; that is, in strict accordance with the manufacturer's
instructions, may cause interference to radio and television reception. It has
been type tested and found to comply with the limits for a Class B computing
device in accordance with the specifications in Part 15 of FCC Rules, which are
designed to provide reasonable protection against such interference in a
residential installation. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause interference
to radio or television reception, which can be determined by turning the
equipment on and off, you are encouraged to try to correct the interference by
one or more of the following measures:
• Reorient the receiving antenna.
• Relocate the computer with respect to the receiver.
• Move the computer into a different outlet so that the computer and receiver
are on different branch circuits.
If necessary, you should consult the dealer or an experienced radio/television
technician for additional suggestions. You may find the following booklet
prepared by the Federal Communications Commission helpful:
How to Identify and Resolve Radio-TV Interference Problems
This booklet (Stock No. 004-000-00345-4) is available from the U.S. Government
Printing Office, Washington, DC 20402.
Warning: Changes or modifications made to this equipment which have not
been expressly approved by Conner Peripherals, Inc. may cause radio and
television interference problems that could void the user's authority to operate
the equipment.
Further, this equipment complies with the limits for a Class B digital apparatus
in accordance with Canadian Radio Interference Regulations.
Cet appareil numérique de la classe B est conforme au Règlement sur le
brouillage radioélectrique, C.R.C., ch. 1374.
Conner and the Conner logo are registered trademarks of Conner Peripherals,
Inc. All other trademarks mentioned in this manual are property of their
respective owners.
Copyright 1994, 1995, Conner Peripherals, Inc.
All rights reserved.
Document No. 501-071 10/95
Important Information About this Manual
All information contained in or disclosed by this document is considered
proprietary by Conner Peripherals, Inc. By accepting this material, the recipient
agrees that this material and the information contained therein are held in
confidence and in trust and will not be used, reproduced in whole or in part, nor
its contents revealed to others, except to meet the purpose for which it was
delivered. It is understood that no right is conveyed to reproduce or translate
any item herein disclosed without express written permission from Conner
Peripherals, Inc.
Conner Peripherals, Inc. provides this manual "as is," without warranty of any
kind, either expressed or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose. Conner
Peripherals, Inc. reserves the right to change, without notification, the
specifications contained in this manual.
Conner Peripherals, Inc. assumes no responsibility for the accuracy,
completeness, sufficiency, or usefulness of this manual, nor for any problem that
might arise from the use of the information in this manual.
Table of Contents Page i
Table of Contents
1. Overview of the Drives 1
What are the Drives? 1
Differences Between the Models 1
Features of the Drive 2
Drive Composition 3
Mechanical Design Features 3
Drive Assembly Housing 4
Head Positioning Mechanism 5
Read/Write Heads and Disks 5
Data and Power Connections 5
Electrical Design Features 5
Integrated Circuit 5
Circuit Board 5
Firmware 6
2. Specifications 9
Specifications in this Chapter 9
Drive Capacity 10
Formatted Capacity* 10
Physical Configuration 10
Physical Configuration 10
Performance Characteristics 11
Seek Times (typical)* 11
Average Latency 11
Rotation Speed (+0.1%) 11
Controller Overhead 11
Start Time(Power Up)* 11
Stop Time at Power Down 11
Interleave 11
Read/Write Characteristics 12
Recording Method 12
Recording Density (maximum) 12
Flux Density (maximum) 12
Host Interface Characteristics 12
Command Set 12
Data Transfer Rate 12
Maximum Synchronous Transfer Offset: 12
Maximum Tagged Command Queue Depth: 12
Buffer Size: 12
Reliability 13
Data Reliability 13
Component Design Life 13
Mean Time Between Failures: 13
Preventive Maintenance 13
Power Requirements (Typical) 13
Minimum/Maximum Voltage: 13
Environmental Tolerances 14
Table of Contents Filepro CFP2107 Series
Page ii Filepro CFP2107 Series
Magnetic Field: 14
Acoustic Noise: 14
Safety Standards 15
Physical Characteristics - CFP2107E 16
16
Physical Characteristics - CFP2107S 17
Physical Characteristics - CFP2107W 18
3. Drive Operations 19
Functions of the Drive 19
Drive Operational Modes 19
Data Error Correction 20
Downloadable Microcode 20
Command Execution and Buffer Management 21
Tagged Command Queuing 21
Seek Ordering 21
Rotational Ordering 21
Coalescing 22
Read Look Ahead Code 22
Write Caching 24
4. Installing the Drive 25
Take These Precautions 25
Installing the Drive 25
Installing a CFP2107E 26
Setting the Drive's Jumpers - CFP2107E 26
Setting the SCSI Bus Address - CFP2107E 26
Disabling Spin-Up at Power On - CFP2107E 27
Delaying Spin Up at Power On - CFP2107E 27
Cabling the Drive - CFP2107E 27
Attaching Power to the Drive - CFP2107E 28
Mounting the Drive - CFP2107E 29
Mounting Screw Holes 29
Cooling 29
Installing a CFP2107S 30
Setting the Drive's Jumpers - CFP2107S 30
Setting the SCSI Bus Address - CFP2107S 31
Disabling Spin-Up at Power On - CFP2107S 32
Delaying Spin Up at Power On - CFP2107S 32
Disabling the SCSI Bus Parity - CFP2107S 33
Disabling SCSI Bus Terminator Power (TERMPWR) -
CFP2107S 33
Setting the Bus Termination - CFP2107S 34
Cabling the Drive - CFP2107S 35
SCSI Bus Cable 35
Spindle Synchronization 35
Attaching Power to the Drive - CFP2107S 36
Attaching a Remote LED - CFP2107S 36
Mounting the Drive - CFP2107S 36
Mounting Screw Holes 36
Cooling 36
Installing a CFP2107W 38
Setting the Drive’s Jumpers - CFP2107W 38
Filepro CFP2107 Series Table of Contents
Technical Reference Manual Page iii
Setting the SCSI Bus Address - CFP2107W 39
Disabling Spin-Up at Power On - CFP2107W 40
Delaying Spin Up at Power On - CFP2107W 40
Disabling the SCSI Bus Parity - CFP2107W 41
Disabling SCSI Bus Terminator Power (TERMPWR) -
CFP2107W 41
Using the J5 Auxiliary Connector 41
- SEL0 41
- XTFAULT 42
- SEL1 42
- VUNIQ 42
- SEL2 42
- SPSYNC 43
- SEL3 43
- XTACTV 43
- GROUND 43
+5 Volts 43
- FAULT 43
Setting the Bus Termination - CFP2107W 44
Cabling the Drive - CFP2107W 45
SCSI Bus Cable 45
Mixing Wide and Narrow SCSI Devices on a SCSI Bus 45
Spindle Synchronization Error! Bookmark not defined.
Attaching Power to the Drive - CFP2107W 47
Attaching a Remote LED - CFP2107W 47
Mounting the Drive - CFP2107W 47
Mounting Screw Holes 47
Cooling 48
5. Interface Physical Characteristics 49
Electrical Description 49
Output Characteristics 49
Input Characteristics 50
Model-Specific SCSI Physical Characteristics 50
CFP2107E (WIDE, 80-pin Single Connector Attachment [SCA]) 51
External Terminator Power 51
Internal Termination 51
Cable Requirements 51
Connector Requirements 52
Single Connector Attachment (SCA) Signal Definitions 52
Power 52
Spindle Sync 52
LED Out 52
Motor Start Controls 53
SCSI ID Selection 53
Interface Pin Assignments 54
Interface Timing Requirements 55
Model CFP2107S (Narrow, 50-pin SCSI) 56
External Terminator Power 56
Internal Termination 56
Cable Requirements 57
Connector Requirements 58
Interface Pin Assignments 59
Interface Timing Requirements 60
Table of Contents Filepro CFP2107 Series
Page iv Filepro CFP2107 Series
Model CFP2107W (Wide, Unitized SCSI-3 P-Connector) 61
External Terminator Power 61
Internal Termination 61
J5 Auxiliary Connector Signal Characteristics 62
Cable Requirements 62
Connector Requirements 63
Interface Pin Assignments 64
Interface Timing Requirements 65
6. SCSI Command Implementation 67
SCSI Command Summary 67
Drive Dependent SCSI Data 67
Format Drive Page - 03H68
Drive Geometry Page - 04H70
Notch and Partition Parameters Page - 0CH71
Technical Reference Manual Page 1
Overview of the Drives
1
What are the Drives?
The CFP2107 series is a family of high performance 3.5-inch low-profile (1.0 inch
high) 2.1GB (formatted) disk drives. They all offer 8.5 millisecond average seek
time for Reading, 9.0 millisecond seek time for Writing, with an average latency
of only 4.17 ms. High capacity is achieved by utilizing a zone density recording
technique using 15 recording zones at an areal density of 317 Mbits per square
inch. These drives feature high performance while maintaining low power
consumption to reduce power supply current and system cooling requirements in
disk arrays.
They are designed to operate on the Small Computer System Interface (SCSI)
and are SCSI-2/3 command compatible. The mechanical and major electronic
components are identical between the models and differ only in the host
interface implementation:
Drive Model Form Factor
Interface
Capacity
CFP2107E 1 inch high, 3.5 inch
80-pin Single Connector
FAST WIDE
2147 MB
CFP2107S 1 inch high, 3.5 inch
50-pin FAST
2147 MB
CFP2107W 1 inch high, 3.5 inch
68-pin FAST WIDE
2147 MB
CFP2107WD 1 inch high, 3.5 inch
68-pin FAST WIDE
Differential
2147 MB
The CFP2107WD drive is documented separately in the CFP2107WD SCSI Wide
Differential Intelligent Disk Drive Product Manual. The remainder of the
drives, which are documented in this manual, are referred to collectively in this
manual as “the drive” for simplicity.
Differences Between the Models
The three drive models differ only on the host interface implementation:
CFP2107E: SCSI 80-pin Wide Single Connector Attachment (SCA) interface
designed for applications such as Redundant Arrays in which the drives are
plugged directly into a backplane. The drive also implements a Wide SCSI
interface for high interface bandwidth.
CFP2107S: SCSI 50-pin standard interface designed for applications which
implement the standard SCSI-2 architecture.
CFP2107W: SCSI 68-pin Wide interface designed for applications which
require high interface bandwidth and the option of cabled interconnect. The
drive utilizes the Unitized Connector defined by the Small Form Factor
Committee (refer to SFF-8009). The Unitized Connector combines the SCSI-3 P-
Chapter 1 Overview of the Drives
Page 2 Filepro CFP2107 Series
connector Wide interface, the standard 4-pin power and a 2mm pin pitch
Auxiliary connector into a single molded assembly.
CFP2107WD: SCSI 68-pin wide differential interface designed for applications
which require high interface bandwidth and the option of cabled interconnect.
The drive utilizes the Unitized Connector defined by the Small Form Factor
Committee (refer to SFF-8009). The Unitized Connector combines the SCSI-3 P-
connector Wide interface, the standard 4-pin power and a 2mm pin pitch
Auxiliary connector into a single molded assembly. The wide SCSI differential
implementation conforms to the SCSI-3 Parallel Interface Specification 855D.
Features of the Drive
The drive provides the following features:
•Automatic Spindle Synchronization
•512 KB segmentable cache buffer with adaptive cache management
•Least Recently Used (LRU) Cache replacement
•Automatic on-the-fly data error correction utilizing a 96-bit Reed-Solomon
EDAC.
•Independent 48-bit CRC miscorrection detection.
•On the fly header error detection and correction.
•High performance rotary voice coil actuator with embedded servo system
•No thermal recalibration required to maintain performance levels
•High Shock resistance
•Automatic actuator latch against the inner stop upon power down with
dedicated landing zone
•Active Termination with removable Resistor Packs
•Active Negation output drivers for greater interface reliability
•SCSI-2/3 Compatibility
•Dual Microprocessor-controlled diagnostic routines that automatically
execute at start-up
•Sealed HDA
•Down-loadable Code through SCSI Interface
•1,7 run length limited code
•Programmable Block Size (512 or 1024)
•Tagged Command Queuing with Seek Re-ordering and Write/Read
Coalescing
Inhaltsverzeichnis
Beliebte CD/CDR-Laufwerk Handbücher anderer Marken
SmartDisk
SmartDisk Firewire CD-R/W Bedienungsanleitung
Axis
Axis CD-ROM SERVER Bedienungsanleitung
LG
LG CRD-8322B Bedienungsanleitung
Memorex
Memorex 32023234 - 52x32x52x External USB2.0 CD... Montageanleitung
Yamaha
Yamaha CD Recordable/Rewritable Drive CRW3200 Bedienungsanleitung
Sony
Sony CRX230AE Bedienungsanleitung
