Contec PC-686CPCI-LV Bedienungsanleitung
PC-686(CPCI)-LV
CompactPCI Single Board Computer
For socket 370 CPU (Celeron™, Pentium III™)
With LAN/VGA
User’s Manual
Copyright
Copyright 2001 CONTEC Co., Ltd. All RightsReserved. No part of
this document may be copied or reproduced in any form by any means
without prior written consent of CONTEC Co., Ltd.
CONTEC Co., Ltd. makes no commitment to update or keep current the
information contained in this document. The information in this
document is subject to change without notice.
All relevant issues have been considered in the preparation of this
document. Should you notice an omission or any questionable item in this
document, please feel free to notify CONTEC Co., Ltd.
Regardless of the foregoing statement, CONTEC assumes no responsibility
for any errors that may appear in this document nor for results obtained by
the user as a result of using this product.
Acknowledgments
IBM/AT and PS/2 are trademarks of International Business Machines
Corporation.
Award is a registered trademark of Award Software International, Inc.
Intel®,Celeron™and Pentium III™are registered trademarks of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
All Other product names or trademarks are properties of their respective
owners.
Liability
The obligation of the warrantor is solely to repair or replace the product.
In no event will the warrantor be liable for any incidental or consequential
damages due to such defect or consequences that arise from inexperienced
usage, misuse, or malfunction of this device.
Limited One Year Warranty
CONTEC Industrial CPU board is warranted by CONTEC Co., Ltd. to be
free from defects in material and workmanship for up to one year from the
date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight
prepaid with a copy of the original invoice and a Return Merchandise
Authorization to the distributor or the CONTEC group office from which it
was purchased.
This warranty is not applicable for scratches or normal wear, but only for
the electronic circuitry and original boards. The warranty is not
applicable if the device has been tampered with or damaged through abuse,
mistreatment, neglect, or unreasonable use, or if the original invoice is not
included, in which case repairs will be considered beyond the warranty
policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of
the original invoice. Please obtain a Return Merchandise Authorization
Number (RMA) from our Sales Administration Department before
returning any product.
*No product will be accepted by CONTEC group without an RMA
number.
Caution about Battery
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Table of Contents
PC-686 (CPCI)-LV User’s Manual i
Table of Contents
CHAPTER 1INTRODUCTION......................................................................... 1
1.1 Specification.......................................................................................... 1
1.2 Mechanical & Environmental ............................................................... 2
1.3 Check List ............................................................................................. 3
1.4 Description............................................................................................ 4
1.5 Power Management Features................................................................ 7
1.6 Power Requirements.............................................................................. 9
1.7 Connector & Jumper Location ............................................................ 10
1.8 Block Diagram .................................................................................... 11
CHAPTER 2HARDWARE INSTALLATIONS..................................................... 13
2.1 Installation procedure ......................................................................... 13
2.2 CPU Installation: ................................................................................ 14
2.3 Main Memory Installation: DIMM1, DIMM2, DIMM3....................... 15
2.4 RJ-45 LAN connector: CN1................................................................. 20
2.5 Serial Port connector: CN2.................................................................. 21
2.6 Parallel Port Connector: CN3.............................................................. 23
2.7 PS/2 Mouse & Keyboard stack Connector: CN4 .................................. 24
2.8 USB Connector: CN5 .......................................................................... 24
2.9 VGA Connector: CN6.......................................................................... 26
2.10 LCD Connector: CN7.......................................................................... 27
2.11 CPU FAN Connector: CN8 ................................................................. 28
2.12 Floppy Disk Connector: CN9............................................................... 29
2.13 External Battery Connector: CN10...................................................... 30
2.14 Primary IDE port Connector: CN11.................................................... 30
2.15 CompactPCI connector P2: CN12 ....................................................... 32
2.16 CompactPCI connector P1: CN13 ....................................................... 33
Table of Contents
ii PC-686 (CPCI)-LV User’s Manual
2.17 CompactPCI connector P3: CN14........................................................34
2.18 Reset button: S1 ...................................................................................34
2.19 LED Indicator......................................................................................34
CHAPTER 3 JUMPER SETTING ...................................................................35
3.1 Infrared (IrDA) port: JP1.....................................................................35
3.2 Watchdog Timer output selector: JP2...................................................35
3.3 CN16 RS-232C/RS-422/RS-485 Selector: JP3/JP5...............................36
3.4 RS-422/RS-485 Terminator: JP4..........................................................39
3.5 On board LAN selector: JP6.................................................................39
3.6 DISK ON CHIP Memory Add. Selector: JP7........................................40
3.7 Display Type Setting: JP8.....................................................................40
3.8 CPU frequency ration setting: JP9 .......................................................40
3.9 Clear CMOS Content: JP10 .................................................................41
3.10 External/Internal battery selector: JP11...............................................41
CHAPTER 4CPU BOARD RESOURCES .......................................................43
4.1. I/O MAP...............................................................................................43
4.2. MEMORY MAP...................................................................................44
4.3. DMA Channels.....................................................................................45
4.4. PCI Configuration Space Map .............................................................45
4.5. Interrupters..........................................................................................46
4.6. PCI Interrupters Routing Map .............................................................47
CHAPTER 5SOFTWARE UTILITIES ..............................................................49
5.1. Intel®440BX chipset Driver..................................................................49
5.2. Graphic Driver .....................................................................................50
5.3. LAN Driver ..........................................................................................53
5.4. Watchdog-Timer (WDT) Setting...........................................................54
5.5. Update new version BIOS.....................................................................55
Table of Contents
PC-686 (CPCI)-LV User’s Manual iii
5.6. Hardware Monitor............................................................................... 56
CHAPTER 6BIOS SETUP......................................................................... 65
6.1. Introduction ........................................................................................ 65
6.2. Main Menu.......................................................................................... 68
6.3. Standard CMOS Setup......................................................................... 70
6.4. BIOS Features Setup........................................................................... 72
6.5. Chipset Features Setup........................................................................ 76
6.6. Power Management Setup................................................................... 80
6.7. PnP/PCI Configuration....................................................................... 85
6.8. Defaults Menu..................................................................................... 88
6.9. Integrated Peripherals......................................................................... 89
6.10. Supervisor/User Password Setting .................................................... 92
6.11. Exit Selecting................................................................................... 93
6.12. POST Messages................................................................................ 94
6.13. POST Beep....................................................................................... 94
6.14. Error Messages ................................................................................ 95
6.15. POST Codes....................................................................................101
Table of Contents
iv PC-686 (CPCI)-LV User’s Manual
CHAPTER 1 –Introduction
PC-686 (CPCI)-LV User’s Manual 1
Chapter 1 Introduction
1.1 Specification
-Processor Socket: Socket 370
-Processor: Intel®Celeron™300MHz –566MHz; Pentium III™
(FSB:100MHz) 500MHz –700MHz
-Host Bus: CompactPCI Bus
for PICMG2.0 R2.1 Bus Master is supported till 4 Max.
-Chipset: Intel®440BX
-Cache Size: 128KB L2 cache is integrated in the Celeron™CPU
256KB L2 cache is integrated in the Pentium III™CPU
-Memory: Up to 768MB SDRAM
-Memory Sockets: Three 168-pin DIMM sockets for SDRAM in 8MB,
16MB, 32MB, 64MB, 128MB and 256MB configurations.
-BIOS: Award BIOS, PnP support
Flash EEPROM (256KB) for BIOS update
Power management
Frequency / Voltage control
-Bus Speed: 66MHz/100MHz
-Super I/O: Winbond W83977TF chipset
-Parallel port: One high-speed parallel port, SPP/EPP/ECP mode
-Series Port: Two 16550 UART port, COM2 is RS-232C/RS-422/RS-485
configurable
-Enhanced IDE: One EIDE port, up to 2 IDE devices, support Ultra
DMA 33
-FDD Interface: Two floppy drives (360KB, 720KB, 1.2MB, 1.44MB,
2.88MB, LS-120)
-USB Interface: One stack connector support 2 USB ports
-Watchdog Timer: Software programmable 16 levels, Reset or NMI
(Jumper selectable)
CHAPTER 1 –Introduction
2PC-686 (CPCI)-LV User’s Manual
-Hardware Monitor: Winbond W83781D
-IrDA: One 1x6 Pin-header
-Keyboard connector: PS/2 keyboard connector
-Mouse connector: PS/2 Mouse connector
-VGA Connector: C&T 69000 Controller, 15 pin D-type VGA
Connector
-LCD: C&T 69000 Controller, 41pin VESA Connector (for OEM)
-LAN: Intel 82559 LAN controller, RJ-45 connector
-SSD: DIP socket supports DiskOnChip flash disks (2MB~144MB)
-RTC: battery backup by Lithium Battery (CR2032)
The coin type Lithium battery specification is shown in table
Specification CR2032
Nominal Voltage 3V
Nominal Capacity 220mAh
Nominal Weight 3.1g
1.2 Mechanical & Environmental
-POWER CONSUMPTION
(Pentium III 700MHz)
+5VDC @6.50A Max.
+12VDC @250mA Max.
+3.3VDC @4.00A Max.
(Celeron 566MHz)
+5VDC @4.50A Max.
+12VDC @250mA Max.
+3.3VDC @3.50A Max.
-OPTERATING TEMPERATURE: 0 ~ 60ºC.
-STORAGE TEMPPERATURE: - 40 ~ 80ºC.
-HUMIDITY: 10% to 90%
Inhaltsverzeichnis
Andere Contec Hauptplatine Handbücher
Contec
Contec ITX-i7435/ATX Bedienungsanleitung
Contec
Contec SCP-8550-LLV Bedienungsanleitung
Contec
Contec SPI-8150-LLVA Bedienungsanleitung
Contec
Contec SBC Series Bedienungsanleitung
Contec
Contec GCOM-2C2-PCI Bedienungsanleitung
Contec
Contec GMB-AQ675-LLVA Bedienungsanleitung
Contec
Contec GMB-L3WHL200 Bedienungsanleitung
Contec
Contec AIO-121602AL-PCI Bedienungsanleitung
Contec
Contec GMB-Q7710-LLVA Bedienungsanleitung
Contec
Contec SPI-8451-LLVA Bedienungsanleitung
Contec
Contec GMB-C2165-LLVA Bedienungsanleitung
Contec
Contec SPI-6941-LV Bedienungsanleitung
Contec
Contec SIS-8601-LVA Bedienungsanleitung
Contec
Contec SLC-8550-LVA Bedienungsanleitung
Contec
Contec EmCORE-i612VLS/C400 Bedienungsanleitung
Contec
Contec Single Board Computer Half-size PICMG 1.3 with LAN, Audio, SATA... Bedienungsanleitung
Contec
Contec GMB-AQ47000 Bedienungsanleitung
Contec
Contec SPI-Q6700-LLVA Bedienungsanleitung
Contec
Contec SPI-8450-LLVA Bedienungsanleitung
Contec
Contec GMB-C2160-LLVA Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Bedienungsanleitung
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
