Continental Refrigerator DL1RI-SS Bedienungsanleitung

DDLL11RRII--SSSS

ROLL-IN & ROLL-THRU

REFRIGERATORS

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

Standard Features

•Modern, State-Of-The-Art Styling

•Performance Rated, "Plug" Refrigeration

System Utilizing Environmentally Safe R-134a

Refrigerant

•3" High Density, Non-CFC Polyurethane

Foam Insulation

•Chrome-Plated Flow Line Handles

•Cam-Action Lift-Off Hinges

•Self-Closing Doors

•Cylinder Lock in Each Door

•Automatic Hot Gas Condensate Evaporator

•273/8" Wide, 661/2" High Door Opening

•External Digital Thermometer

•Removable Stainless Steel Rack Guides

•Magnetic Snap-In Door Gaskets

•Unique Air Flow Distribution Ducts Keep Pan

Product at Uniformly Constant Temperatures

•Removable Stainless Steel Ramps

Models Available

•Roll-Thru •Glass Door

•Remote •Consult Factory

Standard (S/S Front, Aluminum Ends & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

DDLL33RRII--SSSS

REFRIGERATION SYSTEM

A "performance rated", air-cooled hermetically sealed,

capillary type refrigeration system is installed on the top

of each refrigerator. Plasticized fin coil and air circulat-

ing fans are contained within a concealed "plug" type

insulated housing, readily accessible on the top of the

cabinet and separate from the food zone to increase

food storage capacity. The entire "plug" system is fully

charged with environmentally safe R-134a refrigerant

and mounted on a sturdy steel, rail type base, which

can be easily removed if freezer conversion is desired.

Refrigerators are designed to maintain 38 to 40

degrees Fahrenheit (3-5 degrees Centigrade) while

operating with an unrestricted air supply in a maximum

ambient temperature of 100 degrees Fahrenheit. All

condensate water is evaporated by an automatic, non-

electric, corrosion-resistant condensate evaporator. A

strict quality-assurance team inspects all materials and

components to the most exacting standards. All mod-

els are factory performance-tested for a minimum of 16

hours prior to crating.

CABINET CONSTRUCTION

All materials are of top quality, and are

assembled under rigid supervision conform-

ing to strict quality assurance requirements.

The cabinet front, doors, and interior bottoms

are constructed of heavy gauge polished

stainless steel for durability. All cabinet joints

and seams are sealed vapor tight. Case is of

all metal welded construction and is internally

supported and braced for rigid unit construc-

tion. Cabinet design eliminates overlapping

panels with raw edges. Cabinet body and

doors are insulated with non-CFC, foamed in

place polyurethane foam with an average

thickness of 3 inches to ensure increased

energy efficiency. Full-length louvered air

grille located above the doors allows equal air

circulation to the condensing unit. Easily

removable, low-wattage, anti-sweat door

heaters concealed by a non-metallic, non-

conductive, high-impact thermal breaker strip

eliminate condensate build up on the cabinet

front. Automatic interior lighting is controlled

by door openings. Cabinets are equipped

with an easily removable stainless steel ramp

and interior rack guides.

DOOR CONSTRUCTION

Doors shells are constructed of a heavy

gauge stainless steel and are internally

braced and urethane foam insulated for

rigidity. Door corners are of welded con-

struction and polished. Replaceable

snap-in door gaskets are self-adjusting,

heavy-duty, magnetic type. Doors han-

dles and hinges are chrome-plated and

non-corrosive. Doors are provided with

built-in cylinder locks, which are keyed

alike. Hinges are cam action, lift-off type

featuring a positive safety stop at 120

degree

DDLL22RRII--SSSS

DLRI305

REFRIGERATORS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

DL1RI-SS DL2RI-SS DL3RI-SS

SPECIFICATIONS ONE SECTION TWO SECTION THREE SECTION

DIMENSIONAL DATA ROLL-IN ROLL-THRU ROLL-IN ROLL-THRU ROLL-IN ROLL-THRU

Net Capacity (cu. ft.) 32 32 64 64 96 96

Width, Overall (in.) 351/4351/4681/2681/21013/41013/4

Depth, Overall, Incl. Hdls. (in.) 351/239 351/239 351/239

Depth (Less Door(s))(in.) 32 32 32 32 32 32

Depth (Door(s) Open 90°)(in.) 65 98 65 98 65 98

Clear Door Width (in.) 273/8273/8273/8273/8273/8273/8

Clear Full-Door Height (in.) 661/2661/2661/2661/2661/2661/2

Height, Overall (in.) 86 86 86 86 86 86

No. of Full Door(s) 1 2 2 4 3 6

Rack Capacity* 1 1 2 2 3 3

REFRIGERATION DATA

Condensing Unit Size (H.P.) 1/31/31/21/23/43/4

Capacity (BTU/Hr)** 2560 2560 4010 4010 5930 5930

Refrigerant R-134a R-134a R-134a R-134a R-134a R-134a

ELECTRICAL DATA

Cabinet Specifications 115/60/1 115/60/1 115/60/1 115/60/1 115/208-230/60/1 115/208-230/60/1

Feed Wires (Incl. Ground) 3 3 3 3 4 4

Condensing Unit Specs. 115/60/1 115/60/1 115/60/1 115/60/1 208-230/60/1 208-230/60/1

Total Amperes 9.1 9.6 14.7 15.7 11.3 12.8

Cabinet Amperes 1.9 2.4 3.1 4.1 4.3 5.8

Defrost Amperes - - - - - -

Power Supply Cord yes yes yes yes no no

SHIPPING DATA

Height-crated (in.) 90 90 90 90 90 90

Width-crated (in.) 43 43 77 77 109 109

Depth-crated (in.) 42 42 42 42 42 42

Volume-crated (cu. ft.) 94 94 168 168 238 238

Weight Std-crated (lbs.) 415 475 680 780 840 960

Weight SS-crated (lbs.) 505 580 720 825 925 1050

Weight Std - uncrated (lbs.) 330 380 540 625 670 760

Weight SS - uncrated (lbs.) 405 460 575 660 740 840

*Maximum Rack Size including wheels - 27"W x 29"D x 661/4"H

**Rating @ +25° Evaporator, 90° Ambient

Note: All Specifications subject to change without notice

Note: If the cabinet is located directly against a wall and/or under low ceiling, a minimum clearance of 2" is required.

SIDE VIEW DL2RI DL3RI

DL1RI
