Convergence TinyScope CAM Bedienungsanleitung
Hi，Read me
before you explore the
world with TinyScopeCAM
User Manual
English
Microscopic Camera
Tinysc
Inventory
TinyScope Microscopic Camera x1
Biological Slide x4
Dropper x2
Date Cable x1
1
3
5
7
Petri Dish ×2
Adaptor ×2
User Manual
（warranty card）x1
2
4
6
Note: The package and contents in the picture are only for reference.
It should be based on actual objects.
8
7Cleaning Cloth x1 8
Storage Bag x1
1
4
1
7
3
5
2
6
WiFi Box ×1
Product Specification
1
5
3
2
4
Plan apochromatic objective
Type-C data cable interface
1
3
5
Illumination module
Magnetic cover plate
(bright field illumination side)
Magnetic cover plate
(dark field illumination side)
Note: The two sides of the magnetic cover plate shown in the figure are
for reference only, and the structural shape of the functional area is
subject to the actual object.The bright and dark field illumination are
on the same magnetic cover plate, and they are distinguished by the front
side and the back side.
2
4
2
Connect TinyScope CAM to Android phone
Download [TinyScope] APP.
Click on[OTG];then click on[OTG test] to determine
whether your phone supports OTG function.
User Tutorial （Observe Opaque Objective)
01
Open [TinyScope]APP-
Click on“ ” icon.
02
03
If your phone supports OTG function, please click
on [OTG tutorial] again to match your mobile phone
brand and follow the step to turn on [OTG] function.
04
3
Plug the adaptor into the USB port of the data cable
(then both ends of the data cable are Type-c ports).
Plug two ends of the data cable that has been connected
into the port of your smart phone and TinyScopeCAM
respectively. After successful connection, the light
guide area of this product will illuminate.
Light Guide module
05
Your phone will pop up a window [Please
select an application for the USB device]；
choose [TinyScope].
06
If your phone pops up a window asking
for your permission like [Allow “TinyScope”
to access the USB device or not? ],please
choose [Yes].
07
After successful connection,the light guide
area will illuminate, and the mobile phone
screen will jump to the TinyScope APP interface.
08
Move TinyScope CAM’s lens close to an opaque
planar object, and a clear image on your screen
indicates a successful connection.
09
4
Android
phone
For Android version 10 or above
please note
5
In March 2020, the official Android system released the relevant
security patch to solve the problem:the early version of Android
10 cannot correctly request USB device permissions. If you have
not installed the patch, it may cause a black screen while using
our APP. We strongly recommend that you install the patch.
In addition, the App which is available on Google Play cannot be
compatible with early versions of Android 10 due to the API level
restrictions on all uploaded Apps in Google store.
Therefore, If the Tinyscope APP cannot be used normally, and
you are not sure whether the patch has been installed,please
refer to the following two methods to solve the problem.
Method 1
Download the Tinyscope app from Google Play, connect the USB
cable, select USB mode, update App to Android 10 compatible
version using the window prompt after you connect. After
updating the app can be used normally.
Method 2
Using a browser to download the compatible version of the APP
directly from our TinyScope official website .（ https://www.tiny-
scope.com/downloads ）; Click "Download for Android" to
download and install the APK.
Open the TinyScope App on iPhone; select the
interface for the microscope camera,and then
the view of TinyScope CAM displays in real time.
04
On setting page of the microscope,you can select
different resolution options.
05
Connect TinyScope CAM with WIFI module.
01
Long press the button to open the WIFI image
transmission module; then the indicator light
is on,and wait for 3S to 5S.
02
Open the WIFI connection selection interface on
your iPhone;
connect to the WIFI named [ScopeCAM_XXX];
and the initial password is 12345678.
03
Connect TinyScope CAM to iPhone
6
WiFi
Box
Connect TinyScope CAM to PC
(Windows/Mac OS)
Adjust the data cable to USB/Type-C
（The ends of the data cable should be USB and
Type-C port, so if you have connected with the
adaptor,please remove it）.
01
Connect TinyScope CAM and PC with the data cable.
02
Open [QuickTime Player]-Click on [File] in the
upper left corner
-Click on [New Movie Record].
03
Click on [ ] button - click [Camera].
04
Mac OS：
Adjust the data cable to USB/Type-C
（The ends of the data cable should be USB and
Type-C port. If it have already connected with
the adaptor,please remove it）.
01
Search [Camera] in Windows 10
(Enter Camera in the search bar at the bottom
of the desktop).
02
Click to open [Camera] application.
03
Windows :
7
Petri dish
01
01
02
02
03
Instructions
Cautions
8
The thickness of the glass bottom in the center of the petri dish is
0.15-0.20mm. The sample should be as close to the bottom as possible
when it is placed in the groove. The observation depth of field of the micro-
scope camera is 0-0.15mm above the glass surface of the petri dish.
Use the dropper to pick up the liquid sample and squeeze it
out into the middle of the center groove of the petri dish. If the
sample contains any solid material, try to make sure they are
situated close to the glass bottom of the dish.
If the sample is a living organism (such as an insect, etc.),
please keep the sample as settled as possible. After placing
the sample in the groove, cover with the sheet cover to prevent
the sample from moving out of focal range. When observing
transparent objects or objects with lighter colors, we recom-
mend that you use a black sheet cover. When observing
darker objects, you should use a white sheet cover to enhance
the contrast.
If you are observing Anaerobes, you must seal the lid of the
petri dish, Aiming the centre of groove to the camera lens,-
place the petri dish over the TinyScope CAM for observing.
The magnetic cover plate is not needed when viewing a petri
dish sample. If the contrast is not ideal for observation of the
sample, please move to a darker area to observe.
The petri dish can be washed and reused. Please clean it
carefully to avoid breaking the glass bottom. Keep the petri
dish clean and dry. Do not use bathroom tissue to clean the
glass, please use the supplied lens cloth for wiping and clean-
ing the glass.
The two opposite sides of magnetic cover plate are bright field
side and dark field side, respectively.
Choose the dark field side-the black side when observing with
a liquid sampler,while choose the bright field side-the white
side when observing biological slides.
Observe Biological Slides
Take the magnetic cover plate off from the right
side of TinyScopeCAM；
01
03
Place the slide/liquid sampler over the lens
with the front side of towards the lens；
(the front side: texts are readable from left to right )
02
Instructions
Dark Field
Illumination Module
Bright Field
Illumination Module
9
Please ensure that the surface of the observed object is close
to the bottom of the petri dish to avoid unfocusing.
