Convoy Technologies Performance Series Kurzanleitung

Convoy Technologies Inc.

Owner’s / Installaon Manual

Performance Series

M7204RF

LCD COLOR MONITOR

Please read this manual thoroughly before operang the unit, and keep it for further reference.

6409 Highview Drive, Fort Wayne, IN, 46818 USA

. The Humidity is Rh90%.

, and the oper

Owner’s / Installaon Manual

Performance Series

M7204RF

PRECAUTIONS

1. Precauons

Storage and keeping

Do not expose the monitor to excessive heat or cold. The storage temperature of this device is

ang temperature is

Never use this device near a bathtub, wash basin, kitchen, damp basement, swimming pool or similar place.

Never use this device in environments with excessive moisture, dust or smoke.

Avoid dropping or striking this device.

Never puncture, scratch or use abrasive cleaning materials on this device.

The monitor is not designed to be waterproof.

Operang Precauons

Make sure all cables are connected properly observe polarity. Improer cable connecons may damage the monitor. Re

move the power cable connecons when you do not intend to use the unit.

Convoy Technologies Inc.

6409 Highview Drive, Fort Wayne, IN, 46818 USA

-30°C ~ 75°C

-20°C ~ 60°C

1. Precauons

Maintenance

1. Remove all the cable connecons from the monitor before cleaning the unit.

2. Use a mild household detergent and clean the unit with a slightly damp, so cloth. Never use strong solvents such as thin-

ner or benzene, as they might damage the nish of the device.

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’

closure that may be of sucient magnitude to constute risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operang and maintenance (servcing) instruc-

ons in the literature accompanying the appliance.

This symbol is intended to alert the user not to waste electrical and electronic equipment.

CAUTION

You are cauoned that any changes or modicaons not expressly approved in this manual could void your warran-

tee and necessitate expensive repairs.

Declaraon of conformity

This device complies with Part 15 of the FCC Rules. Operaon is subject to the following two condi-

ons: This device may not cause harmful interference. This device must accept any interference

received, including interference that may cause under desired operaon.

Owner’s / Installaon Manual

Performance Series

M7204RF

PRECAUTIONS

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator& your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

Convoy Technologies Inc.

6409 Highview Drive, Fort Wayne, IN, 46818 USA

Owner’s / Installaon Manual

Performance Series

M7204RF

Note: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help.

Owner’s / Installaon Manual

Performance Series

M7204RF

Mounng the Monitor

1) Select a locaon allowing 2” space between monitor and walls, cabinets, or other objects to allow adequate air circulaon

around it. Avoid enclosed spaces, areas with excessive vibraon or subject it to severe impacts.

2) Never use this device in environments with excessive moisture, dust or smoke. Do not place cables where they may be

pinched or stepped on. Monitor is not designed to be waterproof.

3) The device may be powered by a 12 or 24 volt automove baery or vehicle electrical system.

4) Make sure all cables are connected properly, observe polarity. Improper cable connecons may damage the monitor. Remove

the power cable connecons when you do not intend to use the unit.

Installaon Notes: Trigger wire funcon

• Cycle between either CAM 1, CAM 2, CAM 3, CAM 4. When the trigger wire is energized, the monitor automacally switches

to view THAT Camera. When voltage is removed from the trigger wire, monitor returns to previous view. The Monitor only

has one RF receiver, so it can only view one wireless camera image at a me.

• If the monitor is o, when the trigger wire is energized, the monitor will turn on to show THAT Camera. This safety feature is

parcularly useful for night driving, as the monitor light can be distracng to the operator.

• To get the camera into “Pairing Mode” hold the Pairing buon 6 seconds. Hold the “Pair” buon on the M7204RF 3 seconds.

The monitor will start counng down from 50 sec, and when it nds and pairs with the camera, you will see “SAVE DATA” on

the screen, then the picture from the camera.

M7204RF Harness:

• Red and Black—Power (12-24VDC) and Ground

• Green—Trigger Wire for Channel 1

• White—Trigger Wire for Channel 2

• Yellow—Trigger Wire for Channel 3

• Blue—Trigger Wire for Channel 4

Convoy Technologies Inc.

6409 Highview Drive, Fort Wayne, IN, 46818 USA

Owner’s / Installaon Manual

M7204RF Operaon

(1) - buon – For adjusng Down

(2) + buon – For adjusng UP

(3) MENU – Access menu, select items

(4) CAM – Switches between all cameras Connected to Monitor one at a me.

(5) PAIR – Hold for 3sec to enter Pairing Mode

(6) POWER – Turns monitor On and O.

(7) Power indicactor Light.

(8) Loudspeaker

Pressing MENU shows the MAIN MENU. MENU also will select and or change a feature’s ON/OFF status. If a feature is adjustable,

aer selecng it with MENU, use -/+ to adjust.

• -/+ buons adjust Volume. Aer pressing MENU, they will highlight a feature, hit MENU to select that feature, then either

MENU again to toggle on or o, or -/+ to adjust the feature shown.

• To adjust the Aspect Rao from 16:9 to 4:3, select “ZOOM” in the “OPTION ” menu and use “MENU” to toggle one or the oth-

er.

• If installing monitor upside down, select “Rotaon” in the “OPTION” menu and use “MENU” to adjust (LU = le-up, LD = le-

down, RD = right-down, RU = right-up) RU is the normal view, LU is the mirror view. LD and RD if monitor is upside down from

the ceiling.

Pressing MENU will reveal the MAIN MENU page. Use ↕ buons to select a feature, and ↔buons to ad-

just.

• ↔buons adjust Volume. Aer pressing MENU, they adjust the feature shown. Use ↕ buons to select

the feature on a MENU page.

• To adjust the Aspect Rao from 16:9 to 4:3, select “MENU”, “OPTION”, “ZOOM”, then menu will change

it.

• When installing monitor upside down, select Rotaon in the OPTION menu and use MENU to adjust (LU

= le-up, LD = le-down, RD = right-down, RU = right-up) RU is the normal view, LU is the mirror view.

LD and RD if monitor is upside down from the ceiling.

• Video Select buon 1-4 select that camera.

Using the Remote Control

Convoy Technologies Inc.

6409 Highview Drive, Fort Wayne, IN, 46818 USA

Owner’s / Installaon Manual

Replacing the Remote Baeries

Troubleshoong

Specicaons Warranty and Support Informaon

7” TFT-LCD Color Monitor

Audio Output: 0.5 W

Loudspeaker: 1ea 15x40mm

Power Supply: Automobile

Storage Baery

(12-24V)

Power Consumpon: 4W Max,

0.33amps

Video Input: 4

Resoluon: 800x3 (RGB),

480

Contrast: 500:1

Brighness: 510cd/m²

Viewing Angle: 50°-U, 70°-D,

R/L 70°

Operang Temperature: -20°C—°C

Subject to the provisions described below, this CT product is protected for 1

year against defects in material and workmanship. Should a product fail to

perform as described above within the warranted period, it will be repaired or

replaced with the same or funconally equivalent product by CT. This warrant

does not apply if , in the judgement of CT, the product fails due to damage

from shipment, handling, storage, accident, abuse or misuse, or if it has been

used or maintained in a manner not conforming to product manual instruc-

ons, has been modied in any way. Repair by anyone other than CT or an ap-

proved agent will void this warranty. The maximum liability of CT under this

warranty is limited to the purchase price of the product covered by the warran-

ty. All defecve products should be returned to CT with shipping charges pre-

paid. CT will not accept collect shipments.

Symptom possible Causes/Soluons

No picture. No sound Improper connecon of automobile adapter. Use of un-authorized power supply. Power switch is on OFF posion

No picture Check whether locking cable is properly connected.

No sound Check whether locking cable is properly connected, or the sound volume is set too low

Dark picture Check whether brightness and contrast are adjusted correctly; Check whether the environments temperature is too low.

No color Adjust the color sengs.

Upside down or lateral

inverted picture Use the remote/ MENU-OPTION-ROTATION buon to set proper orientaon

No reversing funcon

(i.e. Picture) Check the wires (black/ red/ Green) that may be loose

Performance Series

M7204RF

Convoy Technologies Inc.

6409 Highview Drive, Fort Wayne, IN, 46818 USA

+60

Operating Frequency Range: 2403 to 2478MHz
