Cooke & Lewis OVTC60CL Bedienungsanleitung
60CM SINGLE
ELECTRIC OVEN
WITH TWIN ZONE
OVTC60CL - Version: 01
GB IE Double oven - Barcode: 5052931258765
WARNING: Read the instructions before using the appliance.
Off
O
OVTC60CL-C&L-A5-GB-IM-09.indd 1 11/4/13 3:00 PM
Off
O
[02] x 1
[01] x 1 [03] x 1
[04] x 2 [05] x 1
[06] x 4
OVTC60CL Single oven
1 : 1
[07] x 4
(Ø4mm x 25mm)
OVTC60CL-C&L-A5-GB-IM-09.indd 2 11/4/13 3:00 PM
3
Let's
get started...
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Getting started…
Your product 04
Before you start 05
Safety 06
In more detail…
Operation 12
Care and maintenance 25
Recycling and disposal 30
Technical and legal information 30
Guarantee 31
CE Declaration of conformity 33
Appendix...
34
Installation
GB
IE
OVTC60CL-C&L-A5-GB-IM-09.indd 3 11/4/13 3:00 PM
4
Getting started...
GB
IE
OVTC60CL Single oven
Your product
Note!
Shelf levels are numbered from the bottom up. Levels 4 and 5 are
used mainly for the grill function. Please refer to the cooking guides
provided throughout this manual to determine appropriate shelf levels
for your dishes.
This diagram may be slightly different from the layout of the appliance.
Your product
O
1. ON/OFF & Zone selection dial 2. Temperature button
3. Function button 4. Display
5. Time button 6. Twin zone - active zone selection
7. Time/Temp/Function control dial
A. Control panel
B. Top heating/grill element
C. Oven cavity divider
D. Glass door
E. Shelf guide levels 1-5
F. Shelf guides
13
2 4 5
6 7
[E]
[A]
[D]
[B]
[C]
[F]
OVTC60CL-C&L-A5-GB-IM-09.indd 4 11/4/13 3:00 PM
5
Getting started...
OVTC60CL Single oven GB
IE
Before you start
Things to check before you start
To avoid the risks that are always present when you use an electrical
appliance it is important that this appliance is installed correctly and that
you read the safety instructions carefully to avoid misuse and hazards.
Please keep this instruction booklet for future reference and pass it on to
any future owners. After unpacking the appliance please check that it is
not damaged. If in doubt, do not use the appliance but contact Customer
Services on 0844 800 1128 (UK), 0144 75261 (Ireland).
Check the package and make sure you have all of the parts listed.
Decide on the appropriate location for your product.
If this product contains glass please take care when tting or handling to
prevent personal injury or damage to the product.
The specications plate is available on this appliance. This plate displays
all the necessary identication information for ordering replacement parts.
If you sell the appliance, give it away, or leave it behind when you move
house, make sure you also pass on this manual so that the new owner
can become familiar with the appliance and its safety warnings.
You will need
We advise when installing
this appliance two people are
recommended.
Installation guide
located at the end of
the guidebook
OVTC60CL-C&L-A5-GB-IM-09.indd 5 11/4/13 3:00 PM
6
Getting started...
GB
IE
OVTC60CL Single oven
Safety
These instructions are for your safety. Please
read through them thoroughly prior to
installation and retain them for future reference.
• All installation work must be carried
out by a competent person or qualied
electrician.
• This appliance must be installed correctly
by a suitably qualied person, strictly
following the manufacturer’s instructions.
This appliance complies with all current
European safety legislation, however, the
Manufacturer must emphasise that this
compliance does not prevent the surfaces of
the appliance from heating up during use and
remaining hot during its operation.
Do not allow the electric cables to touch the
hot parts of the appliance.
Make sure that the power cord is not caught
under or in the appliance and avoid damage to
the power cable.
Do not remove the plug in the presence of
ammable gas.
OVTC60CL-C&L-A5-GB-IM-09.indd 6 11/4/13 3:00 PM
7
Getting started...
OVTC60CL Single oven GB
IE
Safety
Do not install the appliance outdoors in a
damp place or in an area which may be prone
to water leaks such as under or near a sink
unit. In the event of a water leak allow the
machine to dry naturally.
Please dispose of the packing material
carefully.
Do not use ammable sprays in close vicinity
to the appliance.
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Regularly check the power plug and power cord
for damage. If the supply cord is damaged,
it must be replaced by the manufacturer, its
service agent or similarly qualied persons in
order to avoid a danger or injury.
A steam cleaner is not to be used.
OVTC60CL-C&L-A5-GB-IM-09.indd 7 11/4/13 3:00 PM
8
Getting started...
GB
IE
OVTC60CL Single oven
Safety
The appliance is not intended to be operated
by means of external timer or separated
remote-control system.
The appliance is for domestic use only.
The Manufacturer declines all liability for
personal or material damage as a result of
misuse or incorrect installation of this appliance.
Danger of burns! During use the appliance
becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
Warning! Accessible parts may become hot
during use. Children should be kept away.
Warning! If the door or door seals are
damaged, the oven must not be operated until
it has been repaired by a competent person.
Do not lean on the door or place any objects
on the door of the appliance. This can damage
the door hinges.
The oven should be cleaned regularly and any
food deposits removed.
Warning! Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
The oven must be installed in accordance with
installation instructions and all dimensions
must be followed.
OVTC60CL-C&L-A5-GB-IM-09.indd 8 11/4/13 3:00 PM
9
Getting started...
OVTC60CL Single oven GB
IE
Safety
Before connecting the appliance to the power
supply, check that the power supply voltage
and current rating corresponds with the power
supply details shown on the appliance rating
label.
Never use a damaged appliance! Disconnect
the appliance from the electrical outlet and
contact your retailer if it is damaged.
Danger of electric shock! Do not attempt
to repair the appliance yourself. In case of
malfunction, repairs are to be conducted by
qualied personnel only.
To avoid damaging the cord, do not squeeze,
bend or chafe it on sharp edges. Keep it away
from hot surfaces and open ames as well.
Lay out the cord in such a way that no
unintentional pulling or tripping over it is
possible.
Keep the appliance and its cord out of reach of
children.
If an extension cord is used, its capacity needs
to be suitable for the power consumed by the
appliance.
Do not operate the appliance with wet hands
or while standing on a wet oor. Do not touch
the power plug with wet hands.
OVTC60CL-C&L-A5-GB-IM-09.indd 9 11/4/13 3:00 PM
10
Getting started...
GB
IE
OVTC60CL Single oven
Safety
Connect the power plug to an easily
reachable electrical outlet so that in case of an
emergency the appliance can be unplugged
immediately. Pull the power plug out of the
electrical outlet to completely switch off
the appliance. Use the power plug as the
disconnection device.
Disconnect the power plug from the electrical
outlet when not in use and before cleaning.
Always turn the appliance off before
disconnecting the power plug.
This appliance is classied as protection
class I and must be connected to a protective
ground (Earth).
Means for full disconnection must be
incorporated in the xed wiring in accordance
with the wiring rules. To achieve this install an
appropriate circuit breaker (CB) and residual
current device (RCD). It should be installed in
an easily reachable place so that in case of
emergency the appliance can be disconnected
from power immediately.
The xed wiring must be protected against
heat surfaces.
Do not hang an objects to the handle of the
oven door.
OVTC60CL-C&L-A5-GB-IM-09.indd 10 11/4/13 3:00 PM
