Corsair XENEON 32QHD240 Bedienungsanleitung
1
Precautions 2
Package Contents 3
Assembly 4
Tilt, Swivel and Height Adjustment 5
Cable Management, Camera Mount (optional) & Other Mounting options 6
Connectivity 8
Operation 9
Controls 9
On-Screen Display (OSD) 9
OSD – Picture Settings 10
OSD – OSD Setting 12
OSD – System Setting 13
OSD – Audio 15
OSD – Input Select 16
OSD – Information 17
Frequently Asked Questions / Troubleshooting 18
Specications 21
Technical Specifications 21
Supported Display Modes 22
TABLE OF CONTENTS
ENGLISH
ENGLISH
Product Setup, User Information, and Warranty/Dead Pixel policy can be
found at https://www.corsair.com/xeneon-quickstart Landing Page
Scan QR code for Quick Start Guide and Setup Videos
2
• Only use the accessories that are provided with the monitor or that are recommended by the manufacturer.
• Keep the plastic packaging bag for the product in a place that cannot be reached by children.
• Before connecting the monitor to the power outlet, make sure that the voltage rating of the power cable
is compatible with the power specification in the country where you are located.
• The power cord plug must be connected to a properly wired and grounded power outlet.
• Do not touch the plug with wet hands, otherwise can easily cause electric shock.
• Place the monitor in a stable and well-ventilated place.
• Do not place the monitor near any heat sources such as electric radiators or direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not cover or block the ventilation holes
with any objects.
• Do not use the monitor near water, drinks, or any type of liquids. Failure to do so may result in
electric shock or damage to the monitor.
• Make sure to unplug the monitor from the power outlet before cleaning.
• As the screen surface can be easily scratched, avoid touching the surface with any hard or sharp object.
Use a soft lint-free cloth instead of a tissue to wipe the screen. You may use a glass cleaner to clean the
equipment if required. However, never spray the cleaner directly onto the screen.
• Disconnect the power cable if the equipment is not being used for a long period of time.
• Do not attempt to disassemble or repair the monitor yourself.
PRECAUTIONS
ENGLISH
ENGLISH
3
A XENEON 32QHD240 DISPLAY PANEL
B MOUNTING POST (For CM-9020002 Only)
C STAND (For CM-9020002 Only)
D MOUNTING SCREWS (x4)
E AC ADAPTER
F AC POWER CABLE
G DISPLAYPORT CABLE (1.5M)
H HDMI CABLE (1.5M)
I USB-C CABLE (1.5M)
J USB-A TO USB-C CABLE (1.8M)
XENEON 32QHD240 DISPLAY CONTENTS
ENGLISH
ENGLISH
JIHG
CD
E
F
B
A
4
Before you begin, you will need a Phillips head screwdriver.
1. Remove the top layer of foam that includes accessories and stand to expose the rear of the panel.
2. Carefully open the foam bag covering the panel (see image 1) to expose the mounting area. Do not remove
the panel from the bag.
3. Align the monitor post with the mounting slots on the back of the panel (see image 2). Slide the upper hooks
into the mounting slots on the rear of the panel. Using a Phillips screwdriver, secure the post to the panel with
the 4 screws (see image 3).
4. Attach the stand base to the monitor post (see image 3) and tighten the captive thumbscrew into the bottom
of the post (see image 4).
5. Slowly remove the monitor from the packaging and sit upright on your desk. Do not touch the front of the panel
while lifting the monitor.
ASSEMBLY (For CM-9020002 Only)
ENGLISH
ENGLISH
1 2
3 4
5
Your Xeneon display features a sturdy and stylish stand that offers tilt, swivel, and height adjustment.
• Tilt -5 / +20 degrees
• Swivel ± 30 degrees
• Height Adjust Range 68mm
ENGLISH
TILT, SWIVEL AND HEIGHT ADJUSTMENT (For CM-9020002 Only)
ENGLISH
TILT
SWIVEL & HEIGHT ADJUSTMENT
6
Your Xeneon display has built-in RapidRoute cable management to keep your desktop tidy. There are 2 adjustable
cable clips that slide up and down the monitor post to allow for customizing your cable management needs.
Open each cable clip by pressing the thumb clasp to the left and pulling out on the cable clip.
ENGLISH
RAPIDROUTE CABLE MANAGEMENT (For CM-9020002 Only)
ENGLISH
7
Before mounting your display with compatible wall mount (VESA 100mm x 100mm), make sure that:
• You have removed the stand from the display with a Phillips screwdriver
• The wall mount bracket that you purchased supports the weight of this display
Review the instructions that came with your wall mount for more information about how to correctly mount
your display.
WARNING: Your display has four VESA mounting holes on the back. You must secure a wall mount bracket
to all four holes. If you do not use all four holes, your display may fall and cause property damage or personal
injury.
Note: Wall-mount screws are not included. Screws: type M4, 14mm to 16mm length depending on wall mount.
ENGLISH
WALL MOUNT COMPATIBILITY
ENGLISH
8
A. 3.5mm Audio Jack
Audio output from connected HDMI, DisplayPort, and USB-C Alt Mode devices.
B. HDMI 2.0 Ports
Dual HDMI inputs correspond to “HDMI-1” and “HDMI-2” inputs.
C. DisplayPort 1.4 Port
DisplayPort input corresponds to “DisplayPort” input.
D. USB Type-C Port
Supports DisplayPort Alt Mode and upstream USB input (connects to USB 3.0 ports). Corresponds
to “TYPE-C” input. This port or the USB Upstream Port must be connected to a USB-capable port
on your host device to support CORSAIR iCUE functionality and downstream USB 3.0 ports.
E. USB-IN Port
Upstream USB input port. This port or the USB Type-C Port must be connected to a USB-capable port
on your host device to support CORSAIR iCUE functionality and downstream USB 3.0 ports.
F. USB 3.0 Ports
Dual Type-A 5Gbps USB ports.
G. DC In
Connects to included AC adapter.
ENGLISH
CONNECTIVITY
ENGLISH
HDMI-1 HDMI-2 DP TYPE-C
DP ALT
USB-IN USB 3.0 USB 3.0 DC IN
AUDIO
OUT
A B C D E F G
9
Controls
By pressing the joystick inward, you can access your monitor’s display settings. You can use the joystick to navigate
the settings and pressing the joystick inward will confirm your selection.
On-Screen Display (OSD)
Your monitor includes a joystick on the rear, right facing side for opening
shortcuts and navigating display settings. Note that many of these
settings can also be controlled in CORSAIR iCUE software if you have
the USB hub connected to your computer via USB IN port.
Please install the latest version of iCUE (4.24 or later) available at
https://www.corsair.com/us/en/icue.
POWER ON/OFF
PRESS — Open Display Settings
UP — Open Brightness Slider
DOWN — Open Picture Mode Select
LEFT — Open Volume Slider
RIGHT — Open Input Source Select
ENGLISH
OPERATION
ENGLISH
