Cotek SK Series Bedienungsanleitung

SK Series

Pure Sine Wave Inverter

User’s Manual

Contents

1. Important Safety

Instructions……………………………………………… 1

1-1 General Safety Precautions…………………. 1

1-2 Precautions When Working With Batteries… 1

2. Features…………………………………………………………………... 2

2-1 Application………………………………..…… 2

2-2 Electrical Performance……………..………… 3~7

2-3 Mechanical Drawings………………………… 8~9

3. Introduction……………………………………………………………… 10

3-1 Front Panel Operations……………………… 10~13

3-2 Rear Panel Operations………………….…… 14~15

3-3 Protections Features…………………….…… 15

3-4 Installation……………………………………… 16

3-5 Making DC Wiring Connections ………..….. 17~19

3-6 AC Safety Grounding………………………… 20~21

3-7 Inverter Operation……………………….…… 21

4. Troubleshooting guide……………………………………………… 22

5. Maintenance…………………………………………………………… 23

6. Warranty……………………………………………………………… 23

7. Appendices…………………………………………………………….

7-1 CE (LVD EN60950-1) Declaration of

Conformity……………………………..……

7-2 FCC Declaration of Conformity…………..

7-3 e-mark (e13) Declaration of Conformity…

7-4 UL (UL458) NOTICE OF COMPLETION..

1. Important Safety Instructions

1-1. General Safety Precautions

1-1-1. Do not expose the Inverter to rain, snow, spray, bilge or dust.

To reduce risk of hazard, do not cover or obstruct the ventilation

openings. Do not install the Inverter in a zero-clearance

compartment. Overheating may result.

1-1-2. To avoid a risk of fire and electronic shock. Make sure that

existing wiring is in good electrical condition; and that wire size

is not undersized. Do not operate the inverter with damaged or

substandard Wiring.

1-1-3. This equipment contains components which can produce arcs

or sparks. To prevent fire or explosion do not install in

compartments containing batteries or Flammable materials or in

locations which require ignition protected equipment. This

includes any space containing gasoline-powered machinery,

fuel tanks, or joints, fittings, or other connection between

components of the fuel system.

1-2. Precautions When Working with Batteries

1-2-1. If battery acid contacts skin or clothing, wash immediately with

soap and water. If acid enters eye, immediately flood eye with

running cold water for at least 20 minutes and get medical

attention immediately.

1-2-2. Never smoke or allow a spark or flame in vicinity of battery or

engine.

1-2-3. Do not drop a metal tool on the battery. The resulting spark or

short-circuit on the battery of other electrical part may cause an

explosion.

1-2-4. Remove personal metal items such as rings, bracelets,

necklaces, and watches when working with a lead-acid battery,

A lead-acid battery produces a short-circuit current high enough

to weld a ring or the like to metal, causing a severe burn.

WARNING!

Before using the Inverter, read and

save the safety instructions.

2. Features

Pure sine wave output (THD < 3%)

Output frequency：50 / 60Hz switch selectable

Input & output fully isolation design

Low power “ Power Saving Mode “ to conserve energy

High efficiency 89~94%

Capable of driving highly reactive & capacitive loads at start moment.

Tri-Color indicators display input voltage & output load level

Loading controlled cooling fan

Advanced microprocessor

Protection：Input low voltage Overload Short circuit

Low battery alarm Input over voltage Over temperature

2-1. Application

2-1-1. Power tools – circular saws, drills, grinders, sanders, buffers,

weed and hedge trimmers, air compressors.

2-1-2. Office equipment – computers, printers, monitors, facsimile

machines, scanner.

2-1-3. Household items – vacuum cleaners, fans, fluorescent and

incandescent lights, shavers, sewing machines.

2-1-4. Kitchen appliances – coffee makers, blenders, ice markers,

toasters.

2-1-5. Industrial equipment – metal halide lamp, high – pressure

sodium lamp.

2-1-6. Home entertainment electronics – television, VCRs, video

games, stereos, musical instruments, satellite equipment.

2-2. Electrical Performance

Specification Model No.

Item SK700-112 SK700-124 SK700-148 SK700-212 SK700-224 SK700-248

Continuous Output Power 700W

Maximum Output Power (3Min.) 800W

Surge Rating 1400W

Input voltage 12V 24V 48V 12V 24V 48V

Output Voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%

Frequency

(Switch Selectable) 50 / 60Hz +/- 0.05%

Output Waveform Pure Sine Wave ( THD < 3% )

Efficiency (full load) 89.0% 91.0% 92.0% 91.0% 93.0% 94.0%

No Load Current Draw 1.25A 0.64A 0.31A 1.20A 0.60A 0.28A

Stand-By Current Draw 0.25A 0.15A 0.08A 0.25A 0.15A 0.08A

Input Voltage Regulation 10.5-15

VDC

21.0-30

VDC

42-60

VDC

10.5-15

VDC

21.0-30

VDC

42-60

VDC

Input Level Indicator Red / Orange / Green LED

Load Level Indicator

Failure Indicator Red LED

Protection Overload, Short Circuit, Reverse Polarity (Fuse),

Over / Under Input Voltage, Over Temperature.

Remote Control Unit CR-6 / CR-7 / CR-8 Optional

Safety UL458 EN60950-1

EMC FCC Class A

EN55022: 1997

EN55024: 1997

EN61000-3-2: 1998

EN61000-3-3: 1995

e-Mark

Operating Temperature Range 0 - 40 ℃

Storage Temperature Range -30℃to 70℃

Cooling Loading controlled cooling fan

Dimensions 295(L)*180(W)*72(H)mm / 11.61(L)*7.09(W)*2.83(H) Inch

Weight 2.7kg / 5.4 Lbs.

Note: The specifications are subject to change without notice

Specification Model No.

Item SK1000-

112 SK1000-

124 SK1000-

148 SK1000-

212 SK1000-

224 SK1000-

248

Continuous Output Power 1000W

Maximum Output Power

(3Min.) 1150W

Surge Rating 2000W

Input voltage 12V 24V 48V 12V 24V 48V

Output Voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%

Frequency

(Switch Selectable) 50 / 60Hz +/- 0.05%

Output Waveform Pure Sine Wave ( THD < 3% )

Efficiency (full load) 89.0% 92.0% 93.0% 91.0% 94.0% 95.0%

No Load Current Draw 1.43A 0.75A 0.38A 1.25A 0.65A 0.35A

Stand-By Current Draw 0.25A 0.15A 0.09A 0.25A 0.15A 0.09A

Input Voltage Regulation 10.5-15

VDC

21.0-30

VDC

42-60

VDC

10.5-15

VDC

21.0-30

VDC

42-60

VDC

Input Level Indicator Red / Orange / Green LED

Load Level Indicator

Failure Indicator Red LED

Protection Overload, Short Circuit, Reverse Polarity (Fuse),

Over / Under Input Voltage, Over Temperature.

Remote Control Unit CR-6 / CR-7 / CR-8 Optional

Safety UL458 EN60950-1

EMC FCC Class A

EN55022: 1997

EN55024: 1997

EN61000-3-2: 1998

EN61000-3-3: 1995

e-Mark

Operating Temperature Range 0 - 40 ℃

Storage Temperature Range -30℃to 70℃

Cooling Loading controlled cooling fan

Dimensions 383(L)*182(W)*88(H)mm / 15.08(L)*7.17(W)*3.46(H) Inch

Weight 4 kg / 8.8 Lbs.

Note: The specifications are subject to change without notice.

Specification Model No.

Item SK1500-

112 SK1500-

124 SK1500-

148 SK1500-

212 SK1500-

224 SK1500-

248

Continuous Output Power 1500W

Maximum Output Power

(3Min.) 1725W

Surge Rating 3000W

Input voltage 12V 24V 48V 12V 24V 48V

Output Voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%

Frequency

(Switch Selectable) 50 / 60Hz +/- 0.05%

Output Waveform Pure Sine Wave ( THD < 3% )

Efficiency (full load) 88.0% 91.0% 92.0% 90.0% 93.0% 94.0%

No Load Current Draw 1.45A 0.75A 0.40A 1.40A 0.70A 0.40A

Stand-By Current Draw 0.28A 0.15A 0.09A 0.28A 0.15A 0.09A

Input Voltage Regulation 10.5-15

VDC

21.0-30

VDC

42-60

VDC

10.5-15

VDC

21.0-30

VDC

42-60

VDC

Input Level Indicator Red / Orange / Green LED

Load Level Indicator

Failure Indicator Red LED

Protection Overload, Short Circuit, Reverse Polarity (Fuse),

Over / Under Input Voltage, Over Temperature.

Remote Control Unit CR-6 / CR-7 / CR-8 Optional

Safety UL458 EN60950-1

EMC FCC Class A

EN55022: 1997

EN55024: 1997

EN61000-3-2: 1998

EN61000-3-3: 1995

e-Mark

Operating Temperature Range 0 - 40 ℃

Storage Temperature Range -30℃to 70℃

Cooling Loading controlled cooling fan

Dimensions 415(L)*191(W)*88(H)mm / 16.34(L)*7.52(W)*3.46(H) Inch

Weight 4.8 kg / 10.56 Lbs.

Note: The specifications are subject to change without notice.

Specification Model No.

Item SK2000-

112 SK2000-

124 SK2000-

148 SK2000-

212 SK2000-

224 SK2000-

248

Continuous Output Power 2000W

Maximum Output Power

(3Min.) 2300W

Surge Rating 4000W

Input voltage 12V 24V 48V 12V 24V 48V

Output Voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%

Frequency

(Switch Selectable) 50 / 60Hz +/- 0.05%

Output Waveform Pure Sine Wave ( THD < 3% )

Efficiency (full load) 89.0% 92.0% 93.0% 91.0% 94.0% 95.0%

No Load Current Draw 2.8A 1.5A 0.7A 2.64A 1.32A 0.65A

Stand-By Current Draw 0.60A 0.30A 0.15A 0.60A 0.25A 0.15A

Input Voltage Regulation 10.5-15

VDC

21.0-30

VDC

42-60

VDC

10.5-15

VDC

21.0-30

VDC

42-60

VDC

Input Level Indicator Red / Orange / Green LED

Load Level Indicator

Failure Indicator Red LED

Protection Overload, Short Circuit, Reverse Polarity (Fuse),

Over / Under Input Voltage, Over Temperature.

Remote Control Unit CR-6 / CR-7 / CR-8 Optional

Safety UL458 EN60950-1

EMC FCC Class A

EN55022: 1997

EN55024: 1997

EN61000-3-2: 1998

EN61000-3-3: 1995

e-Mark

Operating Temperature Range 0 - 40 ℃

Storage Temperature Range -30℃to 70℃

Cooling Loading controlled cooling fan ( 65℃ON , 45℃OFF)

Dimensions 422(L)*208(W)*166(H)mm / 16.6(L)*8.18(W)*6.53(H) Inch

Weight 9 kg / 19.8 Lbs.

Note: The specifications are subject to change without notice.

Specification Model No.

Item SK3000-

112 SK3000-

124 SK3000-

148 SK3000-

212 SK3000-

224 SK3000-

248

Continuous Output Power 3000W

Maximum Output Power

(3Min.) 3450W

Surge Rating 6000W

Input voltage 12V 24V 48V 12V 24V 48V

Output Voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%

Frequency

(Switch Selectable) 50 / 60Hz +/- 0.05%

Output Waveform Pure Sine Wave ( THD < 3% )

Efficiency (full load) 88.0% 91.0% 92.0% 90.0% 93.0% 94.0%

No Load Current Draw 2.0A 1.6A 0.8A 2.8A 1.5A 0.7A

Stand-By Current Draw 0.55A 0.35A 0.19A 0.55A 0.35A 0.19A

Input Voltage Regulation 10.5-15

VDC

21.0-30

VDC

42-60

VDC

10.5-15

VDC

21.0-30

VDC

42-60

VDC

Input Level Indicator Red / Orange / Green LED

Load Level Indicator

Failure Indicator Red LED

Protection Overload, Short Circuit, Reverse Polarity (Fuse),

Over / Under Input Voltage, Over Temperature.

Remote Control Unit CR-6 / CR-7 / CR-8 Optional

Safety UL458 EN60950-1

EMC FCC Class A

EN55022: 1997

EN55024: 1997

EN61000-3-2: 1998

EN61000-3-3: 1995

e-Mark

Operating Temperature Range 0 - 40 ℃

Storage Temperature Range -30℃to 70℃

Cooling Loading controlled cooling fan

Dimensions 452(L)*208(W)*166(H)mm / 17.80(L)*8.18(W)*6.53(H) Inch

Weight 9.8 kg / 22 Lbs.

Note: The specifications are subject to change without notice.

Inhaltsverzeichnis

Andere Cotek Wechselrichter Handbücher

Cotek

Cotek SR series Bedienungsanleitung

Cotek

Cotek SK120 Series Bedienungsanleitung

Cotek

Cotek SK700-112 Bedienungsanleitung

Cotek

Cotek S600 Series Bedienungsanleitung

Cotek

Cotek SP Series Referenzhandbuch

Cotek

Cotek S600 Series Bedienungsanleitung

Cotek

Cotek SK120 Series Bedienungsanleitung

Cotek

Cotek SR-1600 Plus-124 Bedienungsanleitung

Cotek

Cotek S1500-112 Bedienungsanleitung

Cotek

Cotek SK700-112 Bedienungsanleitung

Cotek

Cotek SD2500 Bedienungsanleitung

Cotek

Cotek SR1000 Bedienungsanleitung

Cotek

Cotek SE350 series Bedienungsanleitung

Cotek

Cotek SP Series Bedienungsanleitung

Cotek

Cotek SR1000 Bedienungsanleitung

Cotek

Cotek S Series Bedienungsanleitung

Cotek

Cotek S150 Series Bedienungsanleitung

Cotek

Cotek SD Series Bedienungsanleitung

Cotek

Cotek S1500-112 Bedienungsanleitung

Cotek

Cotek SR series Bedienungsanleitung

Cotek

Cotek ST Series Bedienungsanleitung

Cotek

Cotek SD2500-112 Bedienungsanleitung

Cotek

Cotek SE200-124 Bedienungsanleitung

Cotek

Cotek SR-1600 Plus -148 Bedienungsanleitung

Beliebte Wechselrichter Handbücher anderer Marken

Fourgroup

Fourgroup Easy Bedienungsanleitung

Velleman

Velleman PI300M Bedienungsanleitung

Sungrow

Sungrow SG350HX-US Bedienungsanleitung

WilTec

WilTec 61897 Bedienungsanleitung

SMA

SMA SUNNY BOY STORAGE 2.5 Bedienungsanleitung

Simplicity

Simplicity LANDLORD 316 Bedienungsanleitung

Santak

Santak SMAX 3000 Bedienungsanleitung

ATON

ATON RA.Store-3 Bedienungsanleitung

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Bedienungsanleitung

Tektronix

Tektronix CFG250 Bedienungsanleitung

Champion

Champion 200989 Bedienungsanleitung

Vanner

Vanner 20-500 Series Bedienungsanleitung

GE GEP Bedienungsanleitung

Astrel Group

Astrel Group Power Reducer Kurzanleitung

MULTIQUIP

MULTIQUIP GDP-5H Leitfaden

GoWISE

GoWISE PS1007 Bedienungsanleitung

Promate

Promate PM13500D ES Bedienungsanleitung

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Bedienungsanleitung
