Countbox STD-1 Bedienungsanleitung
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
User Guide
Version 3.2
CountBOX smart device
Visitors counting video system
This guide familiarizes the user with the technical characteristics and functionality of the CountBOX smart
device visitors counting video system, Version 3.2 (hereinafter CountBOX STD-1).
The documentation includes connection, authentication, setup and operating manuals CountBOX STD-1, a
web interface description of the device, and a chapter dedicated to creating queries with the use of WEB API
for programmers and system administrators.
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
Contents
Getting started …………………………………………………………………………………………………………………………………..............3
1. Fundamental Principles .................................................................................................................................. 4
2. Technical Requirements and Characteristics .................................................................................................. 5
3. Device Connection and Assembly ................................................................................................................... 6
4. CountBOX STD-1 Startup and Shutdown Process ............................................................................................7
5. CountBOX STD-1 Installation .......................................................................................................................... 9
5.1 Device setup ............................................................................................................................................. 9
5.1.1 "System" tab ................................................................................................................................ 10
5.1.2 "Network" tab .............................................................................................................................. 11
5.1.3 "Miscellaneous" tab ..................................................................................................................... 14
5.2 IP address identification for CountBOX STD-1 ....................................................................................... 17
5.3 Editing CountBOX STD-1 User Accounts ................................................................................................. 18
5.4 Algorithm Setup ..................................................................................................................................... 19
5.4.1 Intersection line setup ................................................................................................................. 19
5.4.2 Object Size Setup ......................................................................................................................... 23
5.4.3 Algorithm checkup ....................................................................................................................... 25
5.5 Generating Reports ................................................................................................................................ 26
5.5.1 Diagram Report ............................................................................................................................ 26
6. Description of LED Indicator Functions ......................................................................................................... 27
7. Factory Reset ................................................................................................................................................ 29
8. CountBOX STD-1 software interface reference ............................................................................................ 31
8.1 Web API ………........................................................................................................................................ 31
8.1.1 API access address....................................................................................................................... 31
8.1.2 Authentication….......................................................................................................................... 31
8.2 API requests ……..……………………………………………….................................................................................. 31
8.2.1 Locations………………………………………….......................................................................................... 32
8.2.2 Finances ……………........................................................................................................................ 33
8.2.3 Visitors ………………………………………………….................................................................................... 39
8.2.4 Profile ……………………………………………………................................................................................... 46
8.2.5 Errors…………………………………………................................................................................................ 48
Appendix A. Interface description .................................................................................................................. 50
Appendix B. Possible error codes in error_id field …….................................................................................... 53
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
Getting started
The CountBOX STD-1 is designed for counting visitors in various public places, such as banks, offices
or shops — any place where attendance analysis is required.
This device captures and processes video data and records results in an embedded database
(hereinafter DB). It is also possible to see CountBOX STD-1 results in the form of a diagram and
report.
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
1. Fundamental Principles
The CountBOX STD-1 operating principle consists of counting visitors passing through the coverage
zone of a video camera. The calculation is carried out in two directions: incoming and outgoing. The
general number of incoming and outgoing visitors is recorded in a DB. The statistics can then be
used in any number of ways according to the user’s demands.
CountBOX STD-1 performs the following functions:
1. Collects statistics
2. Saves statistics in DB
3. Displays statistics in CountBOX STD-1 web interface in the form of a diagram
4. Exports statistics to reports in XML/CSV format.
CountBOX STD-1 combines the following functions:
1. Receiving video images (fig. 1.1)
2. Accessing web interface (fig. 1.2)
3. Video analysis (fig. 1.3)
4. Device status indication (fig. 1.4)
5. DB storage (fig. 1.5)
6. Automatic restart in case of failure/hang-up (fig. 1.6)
7. Factory reset (fig. 1.7).
Figure 1: CountBOX STD-1 functions
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
2. Technical Requirements and Characteristics
In order to provide the CountBOX STD-1 with good working capacity, there are certain requirements
for throughput, device voltage and the user’s computer software. See table 1 for the description of
technical requirements.
Table 1: Technical requirements
Requirement type
Characteristic type
Property value
Hardware requirements
Throughput At least 2 Mbit/s
Connection method UTP–based Ethernet network
Voltage
PoE 802.3af, class 0
Minimum screen resolution
1024x768
Software requirements
Compatible browsers
Mozilla Firefox
—
28.0
Google Chrome —
33.0.1750.154m
Safari — 6.0.5 (8536.30.1)
Internet Explorer —
8.0.7600.16385;
9.0.8112.16421;
10.0.9200.16844
Browser plugins JavaScript, Cookies
Device ports available to the
browser
for http protocol — 80; 1024
— 32668
for https protocol — 443
Time synchronization with NTP server
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
3. Device Connection and Assembly
Assembly of the CountBOX STD-1 should be carried out in accordance with the following
requirements:
1. The device must be installed over a doorway with a height of 2.7-5 meters (with lenses
adjustment up to 15 meters).
2. The device’s optical axis must be oriented perpendicular to the floor.
3. Device coverage zone must not be narrower than a hallway (corridor), where counting of visitors
will take place.
Device connection to the local network is carried out with the help of a PoE–injector1. All the device
power and local network requirements are listed in chapter 2, "Technical Requirements and
Characteristics". The connection scheme of CountBOX STD-1 to the local network is shown in fig. 2.
Figure 2: Connection scheme of CountBOX STD-1 to the local network
After assembly and connection, in accordance with the scheme, are finished (see fig. 2), the
CountBOX STD-1 is ready for setup.
1 Power over Ethernet (PoE) — a technology to power the end device through regular Ethernet twisted pair
wires combined with network information.
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
4. CountBOX STD-1 Startup and Shutdown Process
Authorization in CountBOX smart device web interface is required for CountBOX STD-1 startup.
Follow the steps below to authorize:
1. Enter the IP address in browser’s address bar 1 (http://192.168.10.10 by default). If the IP address
is unknown or has been lost, you can define it by searching CountBOX STD-1 in the network2.
2. Enter user name/password3 in the authorization window (fig. 3) of CountBOX STD-1 web interface
(fig. 3.1):
a) admin/admin for the administrator
b) user/user for the user
The " " button is displayed during entering the password. This button is used to view the
password. It is necessary to press and hold the button the required time to view the password.
3. Click "Login" (fig. 3.2).
Figure 3: Authorization window of CountBOX STD-1 web interface
As a result, the CountBOX STD-1 web interface is displayed (fig. 4).
1Information about compatibility of CountBOX STD-1 software with browsers is provided in chapter 2,
"Technical Requirements and Characteristics".
2 Information about CountBOX STD-1 IP address definition is provided in chapter 5.2, "IP address
identification for CountBOX STD-1 ".
3Information about account settings is provided in chapter 5.3, "Editing CountBOX STD-1 User Accounts".
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
Figure 4: CountBOX STD-1 web interface
For CountBOX STD-1 shutdown, click "Logout" in the upper right corner
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
5. CountBOX STD-1 Installation
CountBOX STD-1 installation is performed by device and algorithm setup. Device setup includes the
following steps:
1. System settings setup
2. Network settings setup
3. Users’ accounts editing.
Algorithm setup includes the following steps:
1. Intersection line setup
2. Object size setup
3. Algorithm checkup.
5.1 Device setup
CountBOX STD-1 setup is carried in the "Device" tab (fig. 5.1). This tab also contains information
about the device model (fig. 5.2) and firmware version (fig. 5.2).
Figure 5: "Device" tab
Description of the "Device" tab is given in table 2.
User guide
Countbox STD-1
info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT
Table 2: Description of the "Device» tab
Number in
fig. 5 Tab name Description
3 System Used for setting the date, time and CountBOX STD-1 name
4 Network Used for network connection setup and obtaining
CountBOX STD-1 domain name
5 Update Used for CountBOX STD-1 firmware update
6 Miscellaneous Used for getting log-files, DB cleanup and CountBOX STD-1
reload
5.1.1 "System" tab
The "System" tab (fig. 6.1) is used for setting the date, time and device name. It also contains
information about the CountBOX STD-1 serial number.
Figure 6: "System" tab
Description of the "System" tab is given in table 3.
