USER MANUAL
HDBase-T Smart System - P31H-01
All-in-One A/V Control System
Front View
Back View
Optional Smart Keypad Control
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
Page 1
Table of Contents
1. Introduction ................................................................ 2
2. Features .................................................................. 2
3. Package Contents ............................................................ 2
4. Technical Specifications .......................................................3-4
5. Operation Controls & Functions ................................................... 5
5.1. Transmitter Front and Rear Panel ............................................5-6
5.2. Receiver Front and Rear Panel ..............................................7-8
5.3 Control Panel Front and Rear Panel ............................................ 9
6. Connection Diagram.......................................................... 10
7. Web Server - LOGIN ......................................................... 11
8. Web Server - MAIN ........................................................12-13
9. Web Server - CONTROL .....................................................14-16
10. Web Server - INPUT/OUTPUT ................................................17-18
11. Web Server - SYSTEM .....................................................19-20
12. System on/Off Subroutine ..................................................... 21
13. Display On/Off Subroutine ..................................................... 22
14. System Reset ............................................................. 23
Warranty ................................................................... 24
Safety Information ............................................................. 24
HDBase-T Smart System - P31H-01
Thank you for purchasing this product
For optimum performance and safety, please read these instructions care¬fully before connecting, operating,
or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electri¬cal components that may be damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. In order to protect and extend the life of your equipment, use of surge
protection systems is highly recommended.
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
Page 2
HDBase-T Smart System - P31H-01
1. Introduction
The P31H-01 is an intelligent, all-in-one AV system. It offers video extension of two HDMI and one VGA signal,
video switching, system control, and analog audio amplification. Uncompressed video, audio, and control can
be transmitted up to 230ft/70m, using HDBaseT™ technology over a single cat 6/6a cable. For convenience,
the P31H-01 can be controlled by its web GUI or an optional control panel: KP-100.
2. Features
• HDMI 1.4b, HDCP 2.2 and HDCP 1.4 compliant.
• Video resolutions up to 4K2K@30Hz, 1080p@120Hz, and 1080P 3D@60Hz.
• Audio up to 7.1 channels of High Definition audio pass through
(LPCM, Dolby TrueHD, and DTS-HD Master Audio).
• HDBaseT™ over a single cat 6/6a cable up to 230ft/70m distance.
• Support multi-VESA Standard VGA formats input.
• Supports balanced MIC input.
• 2x30watts@4 ohms amplifier output.
• Supports interactive display USB pass-through.
• Supports Web GUI control.
• Two relay outputs.
• Supports RS-232 control.
3. Package Contents
• 1 x 2-Gang Extender Transmitter
• 1 x HDMI Extender Receiver
• 1 x 24V3.75A DC Power Supply
• 1 x User Manual
• 2 x Mounting ears
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
Page 3
HDBase-T Smart System - P31H-01
Technical
HDMI Compliance HDMI 1.4b
HDCP Compliance HDCP 2.2 and HDCP 1.4
Video Bandwidth 10.2 Gbps
Video Resolution up to 4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 8-bit,10-bit, 12-bit
HDMI Audio Formats
(Pass-through)
LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-
HD Master Audio, Dolby Atmos, DTS:X
ESD Protection Human body model — ±8kV (air-gap discharge) & ±4kV (contact discharge)
Connections
Transmitter
Inputs 2x HDMI IN Type A [19-pin female]
1x VGA [DB15 VGA female]
1x AUDIO IN [3.5mm Stereo Mini-jack]
1x RS-232/POWER [RJ45]
Outputs 1x HDBaseT Out [RJ45]
Receiver
Inputs 1x HDBaseT In [RJ45]
1x MIC IN [Screw Terminal]
1x USB [USB A TYPE]
1x TCP/IP[RJ45]
Outputs 1x HDMI OUT Type A [19-pin female]
1x RS-232 [Screw Terminal]
1x RELAY [Screw Terminal]
1x AUDIO OUT [Screw Terminal]
1x 2x30watts@4 ohms amplifier output [Screw Terminal]
4. Technical Specifications
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
Mechanical
Housing Metal Enclosure
Color Black, White
Dimensions Transmitter:
115.9mm [W] x 114.3mm [D] x 38.7mm [H]
Receiver:
250mm [W] x 104mm [D] x 30mm [H]
Control Panel:
69.9mm [W] x 114.3mm [D] x 22.2mm [H]
Weight Transmitter: 305g
Receiver: 790g
Control Panel: 180g
Power Supply Input: AC100 - 240V 50/60Hz
Output: DC 24V/3.75A (US/EU standards, CE/FCC/UL certified)
Power Consumption 75W (Max)
Operation Temperature 32 - 104°F / 0 - 40°C
Storage temperature -4 - 140°F / -20 - 60°C
Relative Humidity 20 - 90% RH (no condensation)
HDBase-T Smart System - P31H-01
Page 4
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
1. HDCP LED: HDCP compliance indicator.
• OFF: HDMI input is not carrying HDCP content
• ON: HDMI input is carrying HDCP content
2. LINK LED: HDBaseT Link status indicator.
• OFF: No Link
• GREEN: Link successful
• Blink GREEN: Link abnormal
3. VGA LED: VGA signal indicator.
• OFF: There is no +5V HPD or VGA signal detected on input
• FLASHING: +5V HPD or VGA signal is detected
• GREEN: VGA is active input and VGA signal is detected
4. POWER LED: System power indicator.
5. VGA IN: Connect with VGA source.
5. Operation Controls and Functions
5.1 Transmitter Front and Rear Panel
HDBase-T Smart System - P31H-01
Page 5
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
6. ADUIO IN: Connect with external audio source for VGA signal.
7. HDMI 1 LED: HDMI 1 signal indicator.
• OFF: There is no +5V HPD or HDMI signal detected on input
• FLASHING: +5V HPD or HDMI signal is detected
• GREEN: HDMI is active input and HDMI signal is detected
8. HDMI 1 IN: Connects to HDMI source device.
9. SOURCE: Press it to select one source.
10. TO PC: Connect PC to transmit USB control signal from the Receiver USB device in.
11. HDMI 2 LED: HDMI 2 signal indicator.
• OFF: There is no +5V HPD or HDMI signal detected on input
• FLASHING: +5V HPD or HDMI signal is detected
• GREEN: HDMI is active input and HDMI signal is detected
12. HDMI 2 IN: Connects to HDMI source device.
13. HDBaseT OUT: Connects to HDBaseT Receiver with a Cat 6/6a cable.
14. RS-232/POWER: Connects to Control Panel via Cat 5e/6/6a cable.
15. 24VDC (OPTIONAL): Connects 24V/1A adaptor to AC wall outlet for power supply.
16. MICRO-USB: For firmware update.
17. DIP SWITCH: Select upgrade type.
HDBase-T Smart System - P31H-01
Page 6
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
1. MIC GAIN: Set the MIC input gain.
2. POWER LED: System power indicator.
3. LINK LED: HDBaseT Link status indicator.
• OFF: No Link
• GREEN: Link successful
• Blink GREEN: Link abnormal
4. HDCP LED: HDCP compliance indicator.
• OFF: HDMI input is not carrying HDCP content
• ON: HDMI input is carrying HDCP content
5. ACT: System work indicator.
• OFF: System standby or power off
• Blink GREEN: System working
6. SERVICE: For firmware update.
7. TCP/IP: Connect to a PC access to the WEB GUI for system configuration.
8. HDBaset IN: Connects to HDBaseT Transmitter with a Cat 6/6a cable.
9. HDMI OUT: Connects to a HDMI display device.
5.2 Receiver Front and Rear Panel
HDBase-T Smart System - P31H-01
Page 7
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
10. USB DEVICE: Connect to an interactive display.
11. RS-232: RS232 control for the display.
12. RELAY: To control the projector screen rise and fall.
13. AUDIO OUT: Connect to a speaker.
14. MIC LINE SWITCH:
• When the switch is set to “MIC”, the microphone input is used to connect a dynamic microphone.
• When the switch is set to “LINE”, the microphone input is used for connecting a line level audio
source or wireless microphone output.
15. MIC IN: Using Phoenix terminal cable to connect microphone input.
16. 2X30 watts @ 4Ω/ 2X15 watts @ 8Ω:Connect to speaker out.
17. DC 24V: Connect 24V/3.75A adaptor to AC wall outlet for power supply.
HDBase-T Smart System - P31H-01
Page 8
1723 W. 4th Street Tempe Arizona 85281
USER MANUAL
1. VOLUME Knob and Volume level indicator: Adjust amplifier output volume.
• Clockwise adjustment to increase the volume.
• Counter-clockwise adjustment to decrease the volume.
2. DISPLAY ON: Run Display ON Subroutine, see section 13.
3. HDMI 1: Select HDMI 1 signal as input source.
4. VGA: Select VGA signal as input source.
5. DISPLAY OFF: Run Display OFF Subroutine, see section 13
6. HDMI 2: Select HDMI 2 signal as input source.
7. SYSTEM: Long-press this button for 3 seconds to run System ON/OFF Subroutine, see section 12
8. RS-232/POWER: Connects to Transmitter via CAT5e/6/7 cable.
5.3 Control Panel Front and Rear Panel
HDBase-T Smart System - P31H-01
Page 9
