DUOGEN
August 2004
PROCEDURE TO DOWNLOAD A NEW
FIRMWARE
Ref. A40R0
Application note A40R090103-A
CRE Technology believes that all information provided herein is correct and reliable and reserves the right to update
at any time. CRE Technology does not assume any responsibility for its use unless otherwise expressly undertaken.
CRE Technology
130 Allée Charles-Victor Naudin
Zone des Templiers - Sophia Antipolis
06410 BIOT - FRANCE
Téléphone : + 33 (0)4.92.38.86.82 - Fax : + 33 (0)4.92.38.86.83
SARL au Capital de 300.000 Euros - RCS Antibes : 7488 625 000 15 N°TVA
FR54 488 625 583
DUOGEN – Application note - A40R090103-A page 2/2
Procedure to download a new firmware in DUOGEN
Tools:
•Computer with Flash-it (Flash-it has to ordered directly to www.hse-electronic.com)
•DB9M/DB9F cable
•24VDC power supply
•A shunt for the Boot Strap
Procedure:
1. Get off the cover of DUOGEN.
2. Put the shunt on ST1. See picture below.
3. Connect the computer (serial port) to DUOGEN with DB9 cable.
4. Connect power supply on terminals 1 (+) and 2 (-) of DUOGEN.
5. Switch on the power.
6. Start Flash-it on the computer.
6.1. In “File” window: Select the Exe file *.h86
6.2. In “Config” window:
Bus Mode: Autodetect
Erase mode: Sector erase
6.3. In “Option” window:
User serial number generation: check Enable at address 0x001800
Prefix, example: 4503A
Number, example: 002
6.4. Then click on “Analysis + Download”
7. When download completed, Flash-it screen becomes green.
8. Switch off the power.
9. Put off the shunt on ST1.
ST1
DB9
