Creative Outdoor Solutions FHTA80008 Bedienungsanleitung

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only (outside any enclosure)

Do Not Use For Cooking.

WARNING

FOR YOUR SAFETY:

If the information in this manual is not

followed exactly, a ﬁre or explosion may

result causing property damage, personal

injury or loss of life.

WHAT TO DO IF YOU SMELL GAS:

• Do NOT try lighting any appliance.

• Do NOT touch any electrical switch; do

NOT use any phone in your building.

• Immediately call your gas supplier from a

neighbor’s phone.

• Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call

the ﬁre department.

Installation and service must be performed

by a qualiﬁed installer, service agency or

gas supplier.

Save these instructions for future

reference.

If you are assembling this unit for someone

else, give this manual to him or her to read

and save for future reference.

WARNING

FOR YOUR SAFETY:

Improper installation, adjustment,

alteration, service or maintenance can

cause injury or property damage.

Read the installation, operation and

maintenance instructions thoroughly before

installing or servicing this equipment.

DANGER

If you smell gas:

1. Shut off gas to appliance.

2. Extinguish any open ﬂame.

3. If odor continues, keep away from the

appliance and immediately call your gas

supplier or your ﬁre department.

WARNING

FOR YOUR SAFETY:

1. Do NOT store or use gasoline or other

ﬂammable vapors or liquids in the vicinity of

this or any other appliance.

2. An LP-cylinder not connected for use shall

not be stored in the vicinity of this or any

other appliance.

DANGER

Do NOT leave this appliance unattended while

it is in operation.

CARBON MONOXIDE HAZARD

• This appliance can produce carbon monoxide which has

no odor.

• Using it in an enclosed space can kill you.

• Never use this appliance in an enclosed space such as a

camper, tent, car or home.

·DANGER

Table of Contents

Important Safety Information............................................ . . . . . . . . . . 2

Propane (LP) Dangers and Warnings .......................................... . . . . . . . . . 4

Hose & Regulator Assembly and Replacement .................................... . . . . . . . . . 5

Parts List ............................................. . . . . . . . . . . ........ . . . . . . . . . 7

Assembly Instructions .................................................... . . . . . . . . . . 7

Lighting Instructions ...................................................... . . . . . . . . . . 8

Care and Cleaning ..................................................... . . . . . . . . . . 8

Gas Component Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Troubleshooting ....................................................... . . . . . . . . . . 8

Warranty ........................................................ . . . . . . . . . .. . . . . . 9

California Proposition 65: Combustion by-products produced when using this product contain chemicals

known to the State of California to cause cancer, birth defects, and other reproductive harm.

California Proposition 65:Wash your hands after handling this product.

California Proposition 65: Handling the brass material on this product exposes you to lead, a chemical.

known to the State of California to cause cancer, birth defects, or other reproductive harm.

This appliance complies with “ANSI Z21.97-2014/CSA 2.41-2014, Outdoor Decorative

Gas Appliances.”

USC

Item# 0698669

Factory Model# FHTA80008

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

IMPORTANT SAFETY INFORMATION

WARNING FIRE TABLE IS FOR OUTDOOR USE ONLY

WARNING Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death,

or in a fire or an explosion causing damage to property.

IMPORTANT NOTICE Read and understand all warnings and precautions prior to assembly and use of your gas fire table.

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

Note The use and installation of this product must conform to local codes. In the absence of local codes, use the National

Fuel Gas Code, ANSI Z223.1/NFPA54. Reference to Natural Gas and Propane Installation code CS A B149.1 or Propane

Storage and Handling code B149.2.

Minimum Clearence from Unit to Combustible Materials

72’’ (182.9cm) from the top: 48’’ (121.9cm) from all sides and back. Do not locate this fire table under any overhead enclosure.

IF YOU SMELL GAS

·Shut off gas supply to the fire table.

Extinguish any open flame.

Do not try lighting any appliance.

Do not touch any electricel switch; do not use any phone in your building.

Immediately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions.

If you cannot reach you gas supplier, call the fire department.

Keep these instructions for future reference. If you are assembling this unit for someone else, give this manual to him or

her to read and keep for future reference.

This gas fire table must be used ONLY outdoors in a well-ventilated space and shall NOT be used inside a building,

garage, or any other anclosed area.

DO NOT use this outdoor gas fire table for indoor heating. TOXIC carbon monoxide fumes can accumulate and cause

asphyxiation.

NEVER LEAVE this gas fire table unattended when in use.

Do not store or use gasoline or other flammable vapors and liquids within 25 feet (7.62m) of this or any other appliance.

Do not store any combustible materials in the base enclosure.

The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or

safely operate this outdoor fire table.

• DO NOT use in an explosive atmosphere. Keep gas ﬁre table area a clear and free from combustible materials, gasoline

• This outdoor ﬁre table is not to be installed or used in or on recreation vehicles and/or boats.

• Always use in accordance with all applicable local, state and national codes. Contact your local ﬁre department for details

ﬂammable vapors and liquids.

on outdoor burning.

and other

Installation and repair should be done by a qualified service person. The appliance should be

inspected before use and at least annually by a qualified service person. More frequent cleaning

may be required as necessary. It is imperative that the control compartment, burners and circulating

air passageways of the appliance are kept clean.

Children and adults should be alerted to the hazards of high surface temperatures and be kept at a

safe distance while fire table is in use. This outdoor fire table is not to be operated by children.

Young children should be closely supervised when in the vicinity of this outdoor fire table.

Do not hang or place clothing or other flammable materials on or near the gas fire table.

Any guard or protective device removed for servicing the appliance shall be replaced prior to

operating the appliance.

This unit is to be used with propane gas only!(sold separately)

Do not attach a remote gas supply to this unit.

Only use propane gas for this unit.

This unit is not intended for natural gas.

Converting this unit to natural gas is dangerous and not recommended. The conversion of this unit will void the

manufacturer warranty.

Do not use a flame to check for gas leaks.

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

• Always use this outdoor ﬁre table on a hard, level non-combustible surface such a concrete, rock or stone. An asphalt or

• DO NOT use this outdoor ﬁre table if any part has been under water. Immediately call a qualiﬁed service technician to

and any gas control which has been under water.

•

• DO NOT lean over this outdoor ﬁre table when lighting or when in use.

• Use only the regulator and hose assembly provided. The replacement regulator and hose assembly shall be that speciﬁed by

the manufacturer.

• DO NOT attempt to disconnect the gas regulator from the tank or any gas ﬁtt ing while the outdoor ﬁre table is in use.

• Always shut off the supply at the tank valve and disconnect regulator from the tank when the ﬁre table is not in use

• DO NOT sit on the ﬁre table when the unit is in operation.

• DO NOT throw anything onto the ﬁre when the unit is in operation.

• Glass shards are very hot; please keep children or pets at a safe distance.

• It is essential to keep the outdoor ﬁre table valve compartment, burners, and circulating air passages clean. Inspect outdoor

ﬁre table before each use.

Prior to each ﬁre table operation, check the hose for evidence of excessive abrasion or wear by looking through the visual

replaced before using the gas ﬁre table. The hose assembly

assembly speciﬁed by the manufacturer. Please call Creative Outdoor Solutions at

866-292-8800.

IMPORTANT SAFETY INFORMATION (continued)

blacktop surface may not be acceptable for this purpose.

the ﬁre table and to replace any part or control system

Do not use in windy conditions.

•

Keep all electrical cords away from a hot outdoor fire table.

•

Certain areas of this outdoor fire table when in use will become too hot to touch. Do not touch hot surfaces until the unit has

cooled unless you are wearing protective gear such as insulated pot holders or heat resistant gloves or mittens to avoid burns.

Do not attempt to move or store this outdoor fire table until all parts are cool.

•

check hole. If the hose is damaged, cracked or cut, it must be

can only be replaced with a hose

•Before each use, remove the lava rocks. Examine the burner and its components. If dirty, clean with a soft brush and soapy

or foreign material, such as spider webs or nests in this

that the burner is damaged, the ﬁre table must not be used. The burner assembly

replaced. Please contact Creative Outdoor Solutions at 866-292-8800 for technical support.

• Place the hose out of the pathways where people may trip over it (if using external tank). Do not place the hose in

areas where it may be subjected

ATTENTION: Any alteration of the outdoor ﬁre table that is not speciﬁcally directed in the operations manual will void

water solution. Also examine the area around the burner. Any dirt

area should be removed. If it is evident

can not be

to accidental damage.

DANGER

This outdoor fire table is for use with liquid propane (LP) gas only. The conversion

to or attempted use of natural gas in this outdoor fire table is dangerous and could

result in serious personal injury, or property damage.

manufacturer warranty.

PROPANE (LP) DANGERS AND WARNINGS

LP GAS

LP gas is ﬂammable and hazardous if handled improperly. Become aware of the characteristics before using any LP gas product.

Propane Characteristics:

• Flammable, explosive under pressure, heavier than air and settles in pools in low areas.

• Use the same precautions you would with any open ﬁre when using this outdoor ﬁre table.

• DO NOT burn solid fuels such as: wood, charcoal briquettes, lump charcoal, manufactured logs, driftwood, trash, leaves,

wood in this outdoor ﬁre table.

• DO NOT use this outdoor ﬁre table until it is COMPLETELY assembled and all parts are securely fastened and tightened.

• DO NOT store another LP gas tank within 10 feet (3.05 m) of this outdoor ﬁre table while it is in operation.

• DO NOT use this outdoor ﬁre table near automobiles, trucks, vans or recreational vehicles.

• DO NOT use this outdoor ﬁre table under any overhead structure or near any unprotected combustible constructions.

paper, cardboard, plywood, painted or stained or pressure treated

Avoid using near or under overhanging trees and shrubs.

Do not paint or color any part of this heating unit.

•

Always remove protective cover before operating(if applicable).

Do not set the protective cover over the unit until it is turned off and completely cooled down.

•

Check for leaks after not using the unit for long periods of time.

•

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

inspect

•

www.CreativeOutdoorSolutionsCorp.com

PROPANE (LP) DANGERS AND WARNINGS

• The LP gas supply tank must be constructed and marked in acco rdance with the Speciﬁcations for LP gas LP gas tanks of

n (DOT) or the National standard of Canada, CAN/CSA-B339, LP gas tanks, Spheres

es for the Transportation of Dangerous Goods; and Commission.

• LP gas tank must be arranged for vapor withdrawal.

• The LP gas tank must have a listed overﬁlling prevention device (OPD) and a QCCI or Type I (CGA810) LP gas tank connection.

the U.S. Department of Transportatio

and Tub

• The LP gas tank must have a tank collar to protect the tank valve.

• Never use an LP gas tank with a damaged body, valve, collar, or footing. Dented or rusted LP gas tanks may be hazardous

supplier prior to use.

• The LP gas tank should not be dropped or handled roughly.

• Tanks must be stored outdoors out of the reach of children. Do NOT store in a building, garage, or any other enclosed area.

• Never store your LP gas tank where temperatures can reach ove r 125°F.

• Do not store the LP gas cylinder in direct sunlight or near a source of heat or combustion.

• Never keep a ﬁlled LP gas tank in a hot car or car trunk. Heat will cause the gas pressure to increase, which may open the

pe.

• Place dust cap on valve outlet whenever the LP gas tank is not in use. Only install the type of dust cap on the LP gas tank

the LP gas tank valve. Other types of caps or plugs may result in leakage of propane.

a. Do not store a spare LP gas cylinder under or near this appliance.

b. Never ﬁll the LP gas cylinder beyond 80% full.

c. If the information in (a) and (b) is not followed exactly, a ﬁre causing death or serious injury may occur.

• LP gas cylinders should be ﬁlled only by a certiﬁed LP gas dealer.

• The pressure regulator is set for 11 inches of water column ( pressure).

• The maximum inlet gas pressure for this outdoor ﬁre table is 14 inches of water column pressure.

• Never attempt to attach this appliance to the self-contained LP gas system of a camper trailer, motor home or house.

• Always use the pressure regulator and hose assembly provided with the appliance to connect to a LP gas cylinder. Never

pply. For technical support contact Creative Outdoor Solutions at 866-292-8800.

• Hand turn the manual gas control valve. Never use tools. If the valve will not turn by hand, do not try to repair it. Call a

f force or any self attempted repair may result in a ﬁre or explosion.

Connecting your gas cylinder:

Before connection, be sure that there is no debris caught in the head of the gas cylinder, head of the regulator valve or in the

ports. Connect regulator valve and hand-tighten ﬁrmly. Disconnect the propane cylinder from

the regulator valve when the ﬁre table is not in use. DO NOT obstruct the ﬂow of combustion air and ventilation air to the

burner.

LP gas cylinder must contain a shut-off valve as specified in the standard for compressed gas cylinder valve outlet and inlet

and inlet connection, ANSI/CGA-V-1-1977, CSA B96.

•

and should be checked by your LP gas

relief valve and allow gas to esca

valve outlet that is provided with

connect to an unregulated LP gas su

Certiﬁed Gas Technician. The use o

head of the burner and burner

LP GAS WARNINGS:

• Cylinders must be stored outdoors in a well-ventilated area out of reach of children.

• Disconnected cylinders must have threaded valve plugs tightly installed and must not be stored in a building, garage or any

• Never use a propane cylinder with a damaged body, valve, collar or footing.

• Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier.

• Be sure to use only one 20 lb (9.1 kg) LP gas cylinder with a Type 1 valve with this appliance as required by the American

Steering Committee.

• Only tanks marked “propane” may be used.

other enclosed area.

National Standards Institute (ANSI) and the Canadian Standards

• In its natural state, propane has no odor. For your safety, an odorant has been added.

• Contact with propane could burn your skin.

• Propane is extremely ﬂammable and hazardous if handled improperly.

Propane Characteristics

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

HOSE & REGULATOR ASSEMBLY AND REPLACEMENT

1. This ﬁre table comes equipped with a standard LP gas hose and regulator including the appliance side connection for a CGA

regulator supplied with this ﬁre table must be used. Only a hose

manufacturer can be used for replacement.

a. The CGA No 791 connection incorporates a magnetic ﬂow limiting device that acts

to limit the ﬂow of gas if a leak is detected

b. If the burner valve is open prior to the LP gas cylinder service valve being opened,

the connection will interpret this free ﬂow

c. The connection safety feature will reduce gas ﬂow from the regulator to the

appliance to a minimal level.

d. Be sure that the burner control valve is closed prior to opening the LP gas cylinder

service valve to ensure that the

mistakenly.

e. If the connection ﬂow limiting device is triggered mistakenly, close the LP gas

cylinder service valve and the burner valve,

reset, open the cylinder service valve, then open the burner valve and light the

ﬁreplace as per lighting instructions.

2. Be sure to protect the hose from any hot surfaces. Serious danger may result if the hose contacts any hot surface.

3. Regular maintenance of the hose and regulator:

a. Inspect the hose before each use of the ﬁre table. If the hose shows signs of

cracks, abrasions, cuts or damage of any

replace the hose as required before using the appliance. For assistance

or replacement of the hose, call Creative Outdoor Solutions Corporation at 866-292-8800. Use only

replacement parts from the

b. Inspect the seal inside the CGA No 791 service valve on the LP gas cylinder when

replacing the cylinder or at least once

damage, have the seal replaced by a certiﬁed gas dealer before operating the

appliance.

4. Do not use tools to tighten the CGA No 791 connection nut onto the LP gas cylinder service valve. Hand tighten only.

5. Be careful to not cross the threads on the connection when tightening the CGA No 791 connection on to the LP gas

6. “Leak Test” should always be performed after attaching the connection to the LP gas cylinder service valve. (See “Checking

for Leaks” section of this manual on page 13)

7. For the connection of the hose and regulator to the LP tank, refer to the “Connection” section of the LP gas cylinder section

above.

Glass Shards Warning:

1.Glass embers may have sharp edges, wear safety glasses and gloves when handling

No 791 Cylinder Connection Device. The LP gas hose and

and regulator speciﬁed by

between the regulator and the burner valve.

of gas to be a leak.

connection ﬂow limiting device is not triggered

wait 10 seconds to allow the device to

kind, do not operate the appliance. Fix or

with repair

manufacturer.

per year. If there is any indication of

cylinder service valve.

3. Pour the glass media evenly in to the burner area (with the exception of the screen-if applicable). The glass should be

1/2-1”above the burner.

2. Do not change or substitute the glass ember material provided with this fire pit. If replacing, use only

replacement glass embers available from your local authorized dealer/distributor

DO NOT PLACE ANY

MEDIA ON SCREEN

5.Keep away from the unit for the first 20 minutes after igniting your unit for the first time,as lava rocks/pumice

stones/glass shards could pop out and cause injury. Should any rocks pop out,discard them.

6.Always ensure that pumice stones/Lava Glass are completely dry before use. Failure to do so will

cause them to crack or pop.

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

4. IMPORTANT: Do not exceed a height of 1" above the burner when placing glass media. Ensure no media covers

the igniter screen. Store any excess media in a safe location.

PARTS LIST

11Glass Beads x 1

Table Lid x 1

Table Top x 1

Table Leg A x 1

Side Panel A x 1

Handle x 1

Tank frame x 1

Tank Base x 1

Table Leg B x 1

Table Leg C x 2

Support Brace x 1

Side Panel B x 3

PVC Cover x 1

PACKAGE CONTENTS

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

Important: Handle fire table top

carefully during unpacking

and assembly.

www.CreativeOutdoorSolutionsCorp.com

14 Batteryx1

411

Bottom Bowl x 1

Burner x 1

Pilot Housing x 1

Regulator/Hose Asembly

x 1

Manual electric ignitor

x 1

Control Knob x 1

AA x 4

Assembly Instructions

1. Carefully place the top (3) upside down on a soft surface. Failure to do so could result

in damage or scratches to the tabletop. Attach the legs A (4), table leg B (9) and table

(11) to the top (3). Use bolt (AA).

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

ATTENTION: Assembly is

easiest when you partially

tighten bolts at first. Only

tighten by hand.

www.CreativeOutdoorSolutionsCorp.com

M6x20 Bolt and

washer

Qty: 26

M6x20 Bolt

Qty: 2

Bolt

Qty: 1

DD φ 15 Washer

Qty: 2

EE φ 17 Washer

Qty: 2

φ 24 Washer

Qty: 2

Washer

Qty: 2

Allen Wrench

Qty: 1

HARDWARE CONTENTS (not show actual size)

legs C

x 4

Assembly Instructions

3. Attach the side panel B (12) to table leg C (11). Use bolt (AA).

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

AA x 4

2. Attach the side panel B (12) to the table legs B (9) and table leg C (11). Use bolt (AA).

ATTENTION: Assembly is

easiest when you partially

tighten bolts at first. Only

tighten by hand.

ATTENTION: Assembly is

easiest when you partially

tighten bolts at first. Only

tighten by hand.

AA x 2

Assembly Instructions

5. Attach the tank frame (7) to side panel A (5). Use bolt (AA).

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

AA x 4

4. Attach the side panel B (12) to the table leg A (4) and table leg C (11). Use bolt (AA).

12 AA

ATTENTION: Assembly is

easiest when you partially

tighten bolts at first. Only

tighten by hand.

BB x 2

Assembly Instructions

7. Attach the handle (6) to side panel A (5). Use bolt (BB), washer (DD), washer (FF)

and washer (GG).

GG x 2

FF x 2

DD x 2

If you have any questions or concerns,

please contact Creative Outdoor Solutions

Corporation at CreativeOutdoorSolutionsCorp.com

or call 866-292-8800

www.CreativeOutdoorSolutionsCorp.com

AA x 4

AA AA

6. Attach the tank base (8) to side panel A (5). Use bolt AA.

Inhaltsverzeichnis

Andere Creative Outdoor Solutions Außenkamin Handbücher

Creative Outdoor Solutions

Creative Outdoor Solutions Stone Valley Bedienungsanleitung

Beliebte Außenkamin Handbücher anderer Marken

Outdoor Plus

Outdoor Plus PISMO OPT-2448 Bedienungsanleitung

Legacy

Legacy Fire Pit Bedienungsanleitung

Coleman

Coleman 5055-710 Bedienungsanleitung

Uniflame

Uniflame GAD1348HN Bedienungsanleitung

Jensen

Jensen 300NG Bedienungsanleitung

FEUERHAND

FEUERHAND PYRON Bedienungsanleitung

Firegear

Firegear KWB-NG1 Kurzanleitung

Classics

Classics FP35077 Bedienungsanleitung

Jensen

Jensen 1590LP Bedienungsanleitung

Mayer Barbecue

Mayer Barbecue HEIZA MFK-220 Bedienungsanleitung

Costway

Costway NP11018 Bedienungsanleitung

Target

Target Foxborough Bedienungsanleitung

Blumfeldt

Blumfeldt Merano Bedienungsanleitung

Blooma

Blooma Brasero Ulong Bedienungsanleitung

The Fireplace

The Fireplace JETMASTER 700 D Bedienungsanleitung

Superior

Superior VRE4543EN Bedienungsanleitung

Morsø

Morsø Forno Bedienungsanleitung

dobar

dobar CONICO 35439E Bedienungsanleitung
