11M0247

INSTALLATION INSTRUCTIONS

CRL JACKSON 1275

SURFACE VERTICAL ROD

PANIC EXIT DEVICE

Phone: (800) 421-6144 • Fax: (866) 921-0531

crlaurence.com • usalum.com • crl-arch.com

crlaurence.com

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

TOOLS REQUIRED ...........................................................................................................................................02

PARTS IDENTIFICATION............................................................................................................................03 - 04

DOOR PREPARATION ...............................................................................................................................05 - 08

LAYOUT SELECTION ........................................................................................................................06 - 08

1275 EXIT DEVICE INSTALLATION ...........................................................................................06 - 07

1275 EXIT DEVICE WITH LOCK CYLINDER AND EXTERIOR TRIM .............................................. 08

DOOR HARDWARE INSTALLATION .........................................................................................................09 - 15

INSTALL MORTISE CYLINDER LOCK AND EXTERIOR TRIM (OPTIONAL).......................................... 09

INSTALL UPPER AND BOTTOM LATCH BRACKET ASSEMBLIES........................................................ 10

INSTALL 1275 EXIT DEVICE ....................................................................................................................11

ROD LINKAGE ADJUSTMENTS............................................................................................................... 12

CONNECTION OF LINKAGE RODS TO 1275 EXIT DEVICE................................................................... 13

OPERATIONS CHECK AND DOGGING INSTRUCTIONS....................................................................... 14

INSTALL END CAPS AND COVER ASSEMBLIES ................................................................................... 15

FRAME PREPARATION AND STRIKE INSTALLATION ............................................................................16 - 17

PACKAGED PARTS AVAILABLE....................................................................................................................... 18

ORDER OF ASSEMBLY AND INSTALLATION

NOTE: Any modications, other than those specied in this document, could result in this product's failure to

meet UL safety ratings and void the manufacturer's warranties.

TOOLS REQUIRED

Drill bits: 1/4", 9/32", 7/32", 3/8", 11/16", 7/8", 1-1/4"

Taps: 1/4-20, 10-32, 8-32

Tape measure

Saw horses

Drill

Phillips #2 screwdriver

Standard screwdriver

Framing square/straight edge

1" Masking tape

Center punch

Flat Metal File

Round Metal File

Jigsaw with metal cutting blade

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

PARTS IDENTIFICATION

FASTENERS AND PARTS LIST

CALL

OUT QTY. FASTENER FASTENER

DESCRIPTION PART USED WITH

PART NUMBER

A 4 10-32 x 7/8" FHMS

302652

Base End Cap

Assembly

B11/4"-20 x 1/2" PHMS

302652

Base End Cap

Assembly

C 11/4"-20 x 1-1/4" FHMS

Upper Latch

Bracket Assembly

Included in 302408

D 1 1/4"-20 x 1-1/4" FHMS

3028477

Upper Rod and Latch

Assembly

11/4"-20 x 1-1/4" FHMS

Bottom Latch

Bracket Assembly

Included in 302408

F11/4"-20 x 1-1/4" FHMS

302854

Bottom Rod and Latch

Assembly

10 8-32 x 1-1/4" FHMS

3028527 and 302856

Upper and Bottom

Rod Cover Base Assembly

4 6-32 x 1/4" FHMS

302841

Upper and Bottom

Latch Cover Assembly

210-16 x 3/4" FHDS

(302113 Set)

Upper Strike

Assembly

28-18 x 1/2" FHDS

(302113 Set)

Bottom Strike

Assembly

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

PARTS IDENTIFICATION

FASTENERS AND PARTS LIST

CALL

OUT QTY. FASTENER FASTENER

DESCRIPTION PART USED WITH

PART NUMBER

K48-32 x 3/8" FHMS

302652

Base End Cap

Assembly

L210-32 x 2-1/8" FHMS

Optional 7500LV02628 and

7500LVDT01628

Exterior Trim With

Lever Assembly

PARTS LIST

CALL

OUT PART PART NO. DESCRIPTION

3028527

and

302856

Upper and Bottom Rod Covers

302674

and

30267448

Base Cover Plates

ON/A

Rod Adjusters

Included in 302741ASM

Assembly Package

P302741

Cruciform Rod Activation

Included in 302741ASM

Assembly Package

QDL2170 Optional 1" Single

Mortise Cylinder

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

1. Place the door horizontally on the work stands, interior side up.

2. Mark the stile centerlines 1" from the outside edge of the stile. (Fig. 1)

3. Markthecorrespondinglayoutsontothestileusingtheverticalcenterlinesatthespeciedheight.(Fig. 2)

FIG. 2

REMOVE DOOR AND PREPARE PER ATTACHED LAYOUT DRAWING 10-1082-1

FIG. 1

Bottom Rail

INTERIOR VIEW

SEE DRAWING 10-1082-1

FOR HEIGHT DIMENSIONS

(25.4)

DOOR PREPARATION

NOT TO SCALE

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

DOOR PREPARATION – LAYOUT SELECTION

1275 EXIT DEVICE INSTALLATION - ACTIVE STILE

Edge of Door

40" (1016) to Bottom

of Door From This Line

FIG. 3

Drill and Tap

for a 10-24

Machine Screw

(4) Places

Glass Stop

INTERIOR VIEW

ACTIVE STILE

Templates from Box

NOT TO SCALE

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

FIG. 4

DOOR PREPARATION – LAYOUT SELECTION

1275 EXIT DEVICE INSTALLATION - INACTIVE STILE

Edge of Door

Drill and Tap

for a 1/4"-20

Machine Screw

40" (1016) to Bottom

of Door From This Line

Glass Stop

INTERIOR VIEW

ACTIVE STILE

Templates from Box

NOT TO SCALE

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

FIG. 6

DOOR PREPARATION – LAYOUT SELECTION

Edge of Door

FIG. 5

Drill and Tap for a

10-24 FHMS

(2) Places

Edge of Door

40" (1016) to Bottom

of Door From This Line

Glass Stop

Glass Stop Edge of Door

Drill and

Countersink

for a 10-24 FHMS

(2) Places

Edge of Door

Drill and Tap

for a 10-24

Machine Screw

(4) Places

40" (1016) to Bottom

of Door From This Line

Glass Stop

INTERIOR VIEW

ACTIVE STILE

Templates from Box

EXTERIOR VIEW

ACTIVE STILE

1275 EXIT DEVICE INSTALLATION WITH OPTIONAL

EXTERIOR TRIM AND MORTISE CYLINDER LOCK

NOT TO SCALE

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

INSTALL OPTIONAL MORTISE CYLINDER LOCK AND EXTERIOR TRIM

DOOR HARDWARE INSTALLATION

FIG. 7

1. Attach the exterior trim to the active stile with (2) #10 x 2-1/8" FHMS

NOTE: Exterior trim must be installed before attaching exit device.

#10 x 2-1/8" FHMS

NOT TO SCALE

crlaurence.com | usalum.com

CRL JACKSON PANIC EXIT DEVICE - 1275 SURFACE VERTICAL ROD

INSTALL UPPER AND BOTTOM LATCH BRACKET ASSEMBLIES

DOOR HARDWARE INSTALLATION (CONTINUED)

FIG. 8

1. Attach the upper and bottom latch bracket assemblies 302408 to the prepped active door stile using

(2) 1/4"-20 x 1-1/4" FHMS

2. Attach the upper and bottom rod cover base assemblies 3028527 and 302856 to the prepped active

door stile using (10) 8-32 x 1-1/4" FHMS

3. Attach the upper and bottom rod latch assemblies 3027854 and 3028477 to the latch brackets using

(2) 1/4"-20 x 1-1/4" FHMS and the bracket pins provided. It is normal for the Latch assemblies

to have some play. Secure the pins with the crescent clips provided.

4. Attach the upper and bottom rod adjusters 302741 onto the ends of the all-thread linkage rods

approximately 1/4".

302408

Upper Latch

Bracket Assembly

ACTIVE STILE

302408

Bottom Latch

Bracket Assembly

3028527

Upper Rod

Base Assemblies

3028477

Upper Rod and

Latch Assembly

302854

Bottom Rod and

Latch Assembly

302741

Rod Adjusters

Bracket Pin

Crescent Clip

1/4"-20 x 1-1/4"

FHMS

8-32 x 1-1/4"

FHMS

8-32 x 1-1/4"

FHMS

302856

Bottom Rod

Base Assemblies

1/4"-20 x 1-1/4"

FHMS

1/4"-20 x 1-1/4"

FHMS

1/4"-20 x 1-1/4"

FHMS

NOT TO SCALE
