Crosley CR224 Explorer I Bedienungsanleitung

CR-224

Explorer

Instruction Manual

External AM Antenna

Welcome

Thank you for purchasing the Crosley Radio CR224 Explorer I.

Before operating this unit, please read this manual thoroughly and retain it

for future reference.

Features

XM Ready

XM offers 160 digital radio channels of commercial-free music and

premier news, sports, talk, and traffic and weather in 21 metro markets.

XM's on-air hosts broadcast live from studios in Washington, D.C.,

New York City and Nashville. XM is broadcast via satellite to subscribers

from coast to coast. Subscribers listen to XM on a variety of award-win-

ning satellite radios for the vehicle, home, and portable use.

AroundSound™- Your Crosley Explorer Ifeatures our exclusive

AroundSoundtm design. Using a fully adjustable custom designed driver, the

Explorer Isimulates surround sound, via its three distinct channels, creating a

warm balanced tone, regardless of where you may be located with regards to

the radio.

Portable Audio Ready™- Your Explorer Ialso comes ready to play portable

audio products, including MP3 players, gaming devices, CD players,or

anything with a headphone or auxiliary output jack.

About This Manual

Instructions in this manual describe the controls and functions of the CR224

Explorer I.

Included in this package:

(1) Explorer IRadio

(1) External FM antenna

(1) External AM antenna

(1) Remote Control

(1) AC/DC adaptor

(1) Portable Audio Ready cable

Getting Started

Unpacking

1. Remove packing material from the unit.

Note: Save all packing materials.

2. Remove radio and all accessories.

4. Remove the protective plastic covering the radio and all accessories.

Set Up

1. Unwind the AC/DC power adaptor.

2. Plug AC end into appropriate outlet.

3. Plug the small end of the adaptor into the 12v Jack on the back of the unit.

4. Connect the FM antenna to the FM antenna jack on the back of the unit.

5. Connect the AM antenna to the External AM quick connectors.

6. Remove protective battery tab from remote control.

Getting Started

Unpacking . . . . . . . . . . . . . . . . . .3

Set Up . . . . . . . . . . . . . . . . . . . . . .3

Control Locators . . . . . . . . . . . .4-5

Display . . . . . . . . . . . . . . . . . . . . .6

Connector Locators . . . . . . . . . . .7

Basic Operation

Unit Controls . . . . . . . . . . . . . . .8-9

Clock Setup . . . . . . . . . . . . . . . . .9

Audio Setup . . . . . . . . . . . . . . . .10

Contrast . . . . . . . . . . . . . . . . . . .10

Factory Restore . . . . . . . . . . . . .10

Radio Operation

XM Radio

XM setup . . . . . . . . . . . . . . . . . .11

Listening to XM Radio . . . . . . . .11

AM/FM Radio

Listening to AM/FM Radio . . . . .11

Station Presets

Programming Stations into

Memory . . . . . . . . . . . . . . . . . . . .11

Alarm

Alarm Setup . . . . . . . . . . . . . . . .12

Sleep and Snooze Setup . . . . .13

Battery Back-Up . . . . . . . . . . . . .13

Portable Audio Ready

Auxiliary Input . . . . . . . . . . . . . . .14

Auxiliary Output . . . . . . . . . . . . .14

General

Troubleshooting Guide . . . . . . .15

Warranty Information . . . . . . . . .17

Table of Contents

Getting Started

Control Locators

1. Power

2. Tuning / Enter

3. Volume

4. Menu

5. Preset

6. Audio

7. Mode

8. Snooze / Mute

5687

Getting Started

16 19

Remote Locators

9. Mute

10. Volume Up

11. Volume Down

12. Memory

13. Tuning Down

14. Tuning Up

15. Numeric keys

16. Snooze

17. Sleep

18. Alarm 1

19. Alarm 2

Getting Started

Display Locators

1. Time

2. Mode

3. XM Antenna Signal

4. Station Information

5. Artist / Song TItle

Connector Locators

1. FM Antenna

2. External AM Antenna

3. XM Antenna Jack

4. Auxillary In

5. Headphone Jack

6. Line Out

7. 12v Jack

8. AroundSound™ Control

9. Remote Holder

10. Battery Back-up Cover

765431 2 8

910

Getting Started

Basic Operation

Unit Controls

1. Power Button – This button turns the main power on/off. When in the off

position, the time and date will be displayed.

2. Tuning Knob – The Tuning Knob is used to changeAM/FM/XM stations.

Pressing the Tuning Knob enters the selected station during tuning, and also

selected menu options.

3. Volume Knob – Rotate to adjust volume to desired listening level.

4. Menu – The Menu Button is used to access all menu items. After pressing

the menu button, rotate the Tuning Knob to browse through the menu selec-

tions. Push the Tuning Knob to select a menu function. The menu functions

are as follows: XM SETUP –AUDIO SETUP – CLOCK SETUP – ALARM

SETUP –SLEEPAND SNOOZE SETUP – CONTRAST SETUP – FACTORY

RESTORE – SOFTWARE VERSION.

5. Preset Button – Pressing the Preset Button takes you through stations

saved into memory.

6. Audio Button – This button takes you directly into theAudio Setup section

of the menu. Here, you can select and adjust Bass, Treble, and Balance. Use

the Tuning Button to select which to adjust.

7. Mode Button – Pressing the Mode Button toggles between the modes AM

– FM – XM – AUX.

8. Snooze Button – The Snooze Button has three different functions.

1. Pressing the Snooze Button once the Alarm has been activated

puts the unit into Snooze mode.

2. Pressing the Snooze Button during normal operation mutes the volume.

3. When the units power is turned off, pressing the Snooze Button will

temporarily light the display so the time and date can be seen.

Remote Control

9. Mute Button – Pressing this button mutes the volume.

10. MEM. Button – Memory Button, used to program presets.

11. Tune - – Changes stations in descending order.

12. Tune + – Changes stations in ascending order.

13. Volume Up – Increases volume level.

14. Volume Down – Decreases volume level.
