CRX680
If your engine is not working properly or if there are parts missing or broken,
please DO NOT RETURN IT TO THE PLACE OF PURCHASE. Contact our
Customer Service Department at 1-877-362-4271 or [email protected]
7118266 Rev A JULY 2022
1-ENG
This engine is equipped with a
spark arresting muffler. If the
engine will be used around
flammable materials or on
land covered with materials
such as agricultural crops,
forest, brush, grass or other
similar items, then a USDA
Forest Service spark arrester
must be installed.
2-ENG
DO NOT touch hot surfaces
while operating or just after
stopping the engine. Avoid
contact with hot exhaust gases.
3-ENG
4-ENG
1
4
5
8
7
9
10
2
11
12 14
13
1Exhaust port / Spark Arrester
2
3
4
5
6
Spark plug
Oil cooler
Oil filter
Air filter cover
Choke lever
7Control box / Key start /
Choke lever
8
9
10
11
12
Static screen
Oil fill cap
Cylinder head cover
Dipstick
Starting motor
13
14
Muffler with spark arrester
Crankshaft
3
6
2
5-ENG
6-ENG
