Crystal Image Technologies RMP-161-17KA Bedienungsanleitung

User Manual

7U 17.3 inch Rack Mount Display Monitor

Options :

- DC 9~36V power input

- Touchscreen

Rack Mount Display Monitor - 4K

RMP-161-17KA

- AR hardness glass

< Part. 3 > Options

3.1 Touchscreen P.7

< Part. 2 > Speciﬁ cations / OSD

2.1 Product Speciﬁ cations

2.2 On-screen Display Operation ( OSD )

P.4 - 5

P.6

< Part. 1 >

1.1 Package Content

1.2 Structure Diagram & Dimension

1.3 Installation

Contents

P. 1

P.1 - 2

RMP-161-17KA

■ It is very important to mount the equipment in a suitable cabinet or on a stable surface.

■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive

dust, dirt, heat, water, moisture and vibration.

The equipment comes with the standard parts shown in package content. Check and make sure they are

included and in good condition. If anything is missing, or damaged, contact the supplier immediately.

Unpacking

Before Installation

How To Clean Your LCD Monitor

Caution :

■ To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or

plugging your monitor into an electrical outlet.

■ When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can

scratch or damage your display. Pressure damage is not covered under warranty.

■ Use only cleansers made speciﬁ cally for cleaning monitors and monitor screens. Cleansers not made to

clean monitors and monitor screens can scratch the LCD display or strip off the ﬁ nish.

■ Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly

onto the screen or case can cause damage which is not covered under warranty.

■ Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood based

paper product such as paper towels can scratch your LCD screen.

Cleaning Your Monitor

To clean your LCD safely, please follow these steps :

Disconnect the power cord.

Gently wipe the surface using a clean, dry microﬁ ber cloth. Use as little pressure as possible.

Cleaning Tough Marks and Smudges

To remove tough marks and smudges, please follow these steps :

Disconnect the power cord.

Spray a small amount of non-abrasive cleanser on a microﬁ ber cloth.

Gently wipe the surface. Use as little pressure as possible.

Wait until your monitor is completely dry before plugging it in and powering it up.

Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your

microﬁ ber cloth ﬁ rst, not directly on the parts you are cleaning.

< 1.1 > Package Content

P. 1

< Part 1 >

Rack mount monitor unit X 1

- 1.8 M Display port cable X 1

- Power cord X 1

< 1.2 > Structure Diagram

- 1.8 M HDMI cable X 1

Front view

Basic I/O : HDMI + Display port

Options : Touchscreen & DC power

1 LCD PANEL

2 LCD OSD

3 Handle

4Mounting bracket

I/O bracket

< 1.2 > Dimension

P. 2

Model Product Dimension

(W x D x H)

Packing Dimension

(W x D x H)

Net

Weight

Gross

Weight

482 x 62 x 310 mm 620 x 210 x 400 mm 7 kg 9 kg

RMP-161-17KA

P.3

< 1.3 > Rack Mounting Installation

Mount the RMP-161-4K17 display panel with M6 screw set

Step

M6 screw sets are not provided.

4 x M6 screw set are required

Step

90° tilt adjustment while mounted in rack: +45°~-45°

LCD

Panel

Manufacturer

Panel Size ( diagonal ) 17.3 inch widescreen

Display pixel ( dots x lines )

Brightness ( typ. ) 400

Contrast Ratio ( typ.)

Color

Viewing Angle ( H/V )

Response Time ( ms )

Dot pitch ( mm )

Backlight Type LED

Power Power Supply Range Auto-sensing 100 to 240VAC,

50 / 60Hz

< 2.1 > Product Speciﬁ cations

P.4

< Part 2 >

Regulatory Safety FCC & Certified

Environmental RoHS2 & REACH compliant

AUO

1000:1

3840 x 2160 / 1920 x 1200 / 1920 x 1080

16.7M

178/178

0.0995(H) x 0.0995(V)

Video Digital Display port DP 1.2 / HDCP 1.3

HDMI HDMI 2.0 / HDCP 2.2

Environmental

Conditions

Operating Temperature 0 to 50°C degree

Humidity 5~95%, non-condensing

Altitude 16,000 ft

Storage / Non-operating Temperature -20 to 60°C degree

Humidity 5~90%, non-condensing

Altitude 40,000 ft

Shock 15G acceleration (11ms duration)

Vibration 5~500Hz 1G RMS random

Physical

Speciﬁ cation

Product ( W x D x H )

Packing ( W x D x H )

Net Weight

Gross Weight

482 x 62 x 310 mm

620 x 210 x 400 mm

7 kg

9 kg

P.5

Applicable

Format Display Port Input PC Signal 3840 x 2160 x 60Hz

1920 x 1080 x 60Hz

1600 x 1200 x 60Hz

1360 x 768 x 60Hz

1280 x 1024 x 60 / 75Hz

1280 x 768 x 60Hz

1024 x 768 x 60 / 70 / 75Hz

800 x 600 x 60 / 72 / 75Hz

720 x 400 x 70Hz

640 x 480 x 60 / 72 / 75Hz

Audio Signal 2ch Linear PCM

HDMI Input HDMI 2.0 3840 x 2160 x 60Hz

HDMI 2.0 / 1.4 3840 x 2160 x 30Hz

1920 x 1080 x 50 / 60Hz ( 1080p )

1920 x 1080 x 25 / 30Hz ( 1080i )

1280 x 720 x 50 / 60Hz ( 720p )

720 x 480 x 50 / 60Hz ( 576p / 480p )

Audio Signal 2ch Linear PCM

P.6

< 2.2 > On-screen Display Operation ( OSD )

Source

Menu/Enter

Video input selection

■ USB touchscreen package includes 2 x 1.8 M USB cable, quick reference guideline and CD disc

■ For detailed information, please refer to the attached CD disc

■ As the touchscreen unit is not made of toughened glass, please handle it carefully

< 3.1 > Options : Touchscreen

Model TRB e-Resistive TCB e-Capacitive

Technology 5-Wire Resistive Capacitive

Touch Point Single Single

Method Stylus or Finger Finger

Activation Force ≤ 50g / Stylus=R0.8 ≤ 50g

Durability 10 million touches 300 million touches

Response Time 15 ms 20 ms

Optical Transmittance 80% ± 3% 87% ±2%

Surface Hardness 3H 9H

Haze 8% ± 3% 7%

Glass 3.2 ±0.2 mm 2.8 mm ±10%

Conn�ctor USB Type A

Compatibility Windows 7 / XP / Vista, Linux

P.7

F21" USB Touchscreen Speciﬁ cation

< Part 3 >
