CUE Lighting CREUS Bedienungsanleitung

CREUS

RGB DOME LED LIGHT

User's Manual

Read this manual before using. Do not attempt to open the housing

or repair this device by yourself without contact us!

General instructions

Unpacking:

Thank you for purchasing the CREUS. Please read user guide for safety and before using

the product. Keep this manual for future reference. This includes operation modes

programs and effects. The light has passed functionality tests before delivery. Please check

the contents after unpacking. Immediately upon receiving

a fixture, carefully unpack the box. Check the box contents to ensure that all parts are present

and that they are in good condition. If any part appears damaged from shipping, or if the

box shows signs of mishandling, notify the dealer immediately.

1. LED Light: 1PCS 2. Power Cable: 1PCS

3. User Guide: 1PCS

Safety Notice:

Please read the following safety information carefully.

Page 1

Troubleshooting

LCD Digital display function:

1. If the power supply indicator doesn't light up and the light doesn't work, please AOO1----------------A511

check the power supply, the input voltage and the fuse. AXXX A1 X Red LED ON

2. In Stand-Alone operation, if the power supply indicator is lit up and sound A2X Green LED ON

active indicator isn't lit up, but the laser is shut off it could be because: A3X Blue LED ON

A. Because sound is too small to make laser shut off in sound active, please A4X 3 color LED Jumping

increase the music volume or increase audio sensitivity with sensitivity knob, A5X 7 color LED Jumping

please check as below. A6X Fade

B. Please check if unit has been set up in slave mode, then set up in master mode. A7X Strobe

3. In Master-Slave operation, slave unit doesn't function, please check as below. S1X Sound Active

A. Make sure there's only one master in the chain, and the others are set in slave mode. S2X Sound Active Jumping

B. Make sure to control the unit without DMX console controlling.

C. Make sure to take a good quality power cable and connection.

Warranty Warnings:

1. Damages caused by the disregard of this user manual are not subject to Warranty.

The dealer will not accept liability for any resulting defects or problems.

2. Please do not modify the unit in any way for

safety reasons. Please note that damages caused by manual modifications on the

device or unauthorized operation by unqualified persons will invalidate warranty.

3. If this device will be operated in any way different to the one described in this

manual, it may suffer damages and the guarantee becomes void. Furthermore, any

other operation may lead to dangers like short-circuit, burns, electric shock, etc.

Should you have any problems please contact your local Cue Lighting dealer

Page 5 Page 2

Feature:

◆With the newest LED technology, this LED light can create an amazing and romantic

lighting effect.

◆It has over 200 beams of LED lighting from the transparent case. The beams on the wall look

like handreds of flowers drifting round and round.

◆Compact and lightweight, exquisite appearance, small size, streamline design, attractive

effects.

◆Clear and sharp lighting effects even without fog/smoke

◆Easy to use, plug and play

◆LCD digital display, manual function: color selection, jumping, dimmer, strobe, Sound

Active

◆Stable working, no hassle on warranty

◆Automatic rotation once power on

◆Built-in microphone can trigger external sound

Specification:

◆LED power output:3x1W (Red:1W*1,Green:1W*1,Blue:1W*1)

◆long life working hours:20000 H

◆Rotation angle: 180°

◆Cooling system: air cool

◆Working environment temperature: 0℃-40℃

◆Operation Modes: AUTO, Sound

◆Input Voltage: 90V-240V AC 50-60Hz

◆LED Light size: 185*185*150mm

◆Net weight: 0.5Kg

◆Gross Weight: 0.8Kg

◆Volume weight: 1.6kg(/5000) on inner gift box, 23.6kg(/5000) on outer carton box.

◆Gift box size: 188x188x157mm(0.006m³)

◆Outer carton box size: 565x380x480mm(0.11m³), 18pcs/CTN

Fixture Apperance Function & Setting

Sound Active

Front Panel Figure The light is controlled by the level of sound. Via an in-built mic

Control how sensitive the unit is from the sound sensitivity knob

clockwise direction to increase the fixture’s sensitivity to sound, the knob in the counter

clockwise direction to decrease.

AUTO

Auto cycles the built-in programs without the need for music

Rear Panel Figure The mode allows a single unit to react to the beat of the music in the master mode.

1. Install the units in a horzontal position

2. Set dipswitch to select Sound Active or AUTO mode.

3. Turn on the unit power, the unit begins, reset, then the unit begins working.

4. The unit will react to the low frequencies of music via the internal microphone.

Adjust the audio sensitivity knob on the back of the unit to make the unit more or less

sensitive in sound active.The panel has an LED indicating sound active.

1. working mode selection

2. UP (previous or speedy)

2. DOWN (next or slower)

4. Enter for confirmation 5. Built-in Michrophone 6.Digital LCD display

10. Power Cable

9. Fuse

Page 3 Page 4
