Culver Mobility D12 Bedienungsanleitung
User’s Manual
D12
The company reserves the right to make any change and improvement without prior notice.
It reserves and also the property of models and forbids their reproduction, even partial.
BE FREE
BE EASY
BE YOUR LIFE
Thank you for choosing the D12 for your portable wheelchair transportation needs. It is
important to read through this manual before operating your D12 Power Wheelchair to
become familiar with its features as well as its limitations and safety information.
You will find the operation and care of your D12 Power Wheelchair simple and easy.
Disclaimer: Culver and partners cannot be held responsible forpersonal injury or
property damage resulting from the unsafe or improper operation or maintenance of
D12 wheel-chair.
As part of our ongoing product improvement initiative, we reserve the right to change
specifications and design without notice. As a result, there may be minor differences be-
tween your D12 and accessories and the photos, illustration and instruction in this manual.
INTRODUCTION
Dear Users,
www.culvermobility.com
Recommendation
Please play aattention to “Warning” shown in the content of this user’s manual to
protect you from any injury. Unable tofollow “Notification”in this manual may
result in damage the wheelchair.
Showroom & Office 1403 E Edinger Ave
Santa Ana, CA 92705
CULVER MOBILITY
CONTENTS
.........................................................................................
Specification Diagram
Specifications
..........................................................................
Precautions.......................................................................................................
Install Setup ......................................................................................................
Controller.............................................................................................................
Basic Operation ..............................................................................................
Charging Batteries........................................................................................
Free Wheel Mode ..........................................................................................
Transporting D12 ........................................................................................
Trouble Shooting............................................................................................
Diagnostics ........................................................................................................
Warranty ...............................................................................................................
Warranty Card...................................................................................................
1
2
Safe Operation ....................................................................................... 3-4
4-5
6-8
9
10
10-12
13
13-14
15
16
17
18
1
SPECIFICATIONS
Model D12
Aluminum alloy
1005 * 650 * 950 mm
650 * 350 * 750 mm
150 kgs
250W * 2 pcs brushless motors
24V 7AH * 2 pcs lithium battery
6 MPH
28 km
8” PU solid wheels
Max 12°
6-8 hours
600 mm
Front 490 mm / Back 470 mm
850 mm
23.5 kgs
28.0 kgs
Rear Drive
Electromagnetic Brake
470 mm
400 mm
12.5” PU solid wheels
Material
Unfold Size
Fold Size
Loading Capacity
Motor
Driving Range
Front Wheels
Rear Wheels
Climbing Slope
Charging Time
Width of Armrest
Seat Width
Seat Depth
Seat Height
Turning Radius
Net Weight without Battery
Net Weight with two Batteries
Drive Model
Braking System
Max Speed
Battery
Locate serial number
under push handle cushion
Seat back/
Push Handle
Backrest cushion
with storage bag
Shock absorption
springs
Rear wheel
Motors
Armrest
Controller
Controller knob
seat cushion
Foot rest
Front wheel
SPECIFICATION DIAGRAM
2
770 mm
470 mm
350mm
Seat width
Armrest width
600 mm
960 mm
10"8"
430 mm
1005 mm
630 mm
3
SAFE OPERATION
This is the most important section of manual; how to safely operate the D12 Wheelchair.
Please review this section thoroughly.
◎General safety
Adjust the D12 Wheelchair to your personal comfort level as much as possible.
Take your time to learn how the D12 Wheelchair works in a private space before you
begin operating around others.
Practice bending, reaching and transferring in and out of D12 Power Wheelchair.
Always be aware of your surroundings.
If you are not sure the D12 can surpass an obstacle, try to find another way around.
Make sure that electronic components such as the control panel, battery charge, and
other electronic controlled components avoid moisture. If these components encoun-
ter moisture, dry before use.
The D12 Wheelchair seat is designed for comfort, not specifically for pressure relief;
if you suffer from pressure sores, or if you are at risk that they will occur, please con-
sult your doctor.
Make sure the D12 Wheelchair is operating smoothly.
Check for any unusual noises, vibration, or a change in the ease of use; if you detect
a problem, get in touch with our service department.
Failing to maintain your D12 Wheelchair could increase the risk of injury.
◎Before using your D12 Power Wheelchair
A.
B.
C.
D.
E.
F.
G.
(1)
(2)
(3)
Before sitting, make sure the D12 is switched off, this will ensure the D10A will not
move upon touching the joystick.
Make sure the footrest is down.
Once on board, make sure your feet are safely on the footrest.
◎Getting into the D12 Power Wheelchair
(1)
(2)
(3)
Be alert to the danger of motor vehicles on roads or in parking spaces.
At night or when it is hard to see, use reflective clothing and equipment.
The D12 is designed for use on firm, even surface such as concrete, asphalt or
indoor floor.
Do not operate the D12 Power Wheelchair in sand, loose soil or over rough terrain,
which could damage wheels,bearings, axles or motors, or loose fasteners.
◎Driving the D12 Power Wheelchair
(1)
(2)
(3)
(4)
4
PRECAUTIONS
SAFE OPERATION
◎Getting out of the D12 Power Wheelchair
CAUTION: OPERATE SAFELY
Do not operate the Fold Power Wheelchair D12 in water of any kind.
Do not operate the Fold Power Wheelchair D12 up or down staircase or escalators.
Do turn off the Fold Power Wheelchair D12 when exiting the chair for safety.
Do practice driving the D12 Portable Electric Wheelchair in a private, enclosed area.
Do not operate the Fold Power Wheelchair D12 while on a moving vehicle such as a
bus.
Do not lean your body to reach out of the D12 , causing a balance issue.
Do not exceed the weight limited total of 120kg for rider plus any items.
Pleasedo not drive the wheelchair on public road and make sure have safety belt
buckled before operation.
Make sure to bring the D12 Power Wheelchair to a complete stop.
Turn off the D12 Power Wheelchair to avoid accidentally opening the joystick and
moving the wheelchair.
Raise the armrest so that you can conveniently exit the wheelchair.
Carefully and safely get out of the seat.
Never exceed a total weight of 150 kgs, total for the rider plus items carried.
Exceeding the weight limited is likely to damage the seat, frame or fasteners and
may cause severe injury to you or others.
◎Weight limited-Do not exceed or the warranty will be void
(1)
(2)
Never sit in the D12 Power Wheelchair while in a moving vehicle; an accident or
sudden stop may cause you to be thrown from the wheelchair.
Never transport the D12 Power Wheelchair in the front seat of a vehicle as it may
move and interfere with the driver.
Always secure the D12 Power Wheelchair so that it cannot roll or shift when being
transported in a vehicle.
The D12 Power Wheelchair is NOT approved to be used with any tie down system,
which is generally used to transport a seated user in a powered wheelchair in a
motor vehicle.
◎When transporting the Fold Power Wheelchair D12
(1)
(2)
(3)
(4)
(1)
(2)
(3)
(4)
5
PRECAUTIONS
It is important to perform regular maintenance of your D12 Power Wheelchair for longevi-
ty and warranty eligibility. Even a little cleaning now and again will go a long way to keep
your device looking and functioning like new.
Certified repair shops with trained professionals who specialize in electric wheelchairs
and scooters will be qualified to perform the service and maintenance on your D12 Power
Wheelchair.
We recommend you inspect your D12 Power Wheelchair two or three times per year in
the following areas:
Replacement parts and more major maintenance issues should be done by a professional.
Batteries are special lithium batteries designed specifically for use in the D12 Power
Wheelchair.
Read all battery instructions before attempting to change or charge batteries.
When you don’ t use the D12 wheelchair for long periods of time, please charge the
battery every month to avoid the battery being damaged.
Use fasteners that have been supplied by Culver .
Using the correct tools, tighten any fasteners that become loose as soon as possible.
◎Batteries
(1)
(2)
(3)
Many of the screws, bolts and nuts on the D12 are special high-strength fasteners. Re-
placing these fasteners with non-approved parts may cause your D12 Power Wheelchair
to result in faulty operation and may cause harm to you or other people, therefore:
◎Fasteners
Never use non-D12 Power Wheelchair parts or make changes unless authorized in writ-
ing by representative from our company. Doing so will void the warranty and may create
a safety hazard.
◎Change and Adjustments
(1)
(2)
(3)
Frame: Tighten loose screws as necessary D12 Power Wheelchair.
Wheels: Make sure they rotate easily. Significant resistance may require new bearings.
Armrest: Look for excessive wear or if they are loose.
A.
B.
6
INSTALL SETUP
Your D12 Power Wheelchair will arrive carefully packaged in a cardboard box.
Open the top of the box then turn the box on the side for easier pulling out the chair and
contents.
Total components as bellow:
1.
2.
To expand the D12 , grasp the push bar and pull up while holding down on the seat to
expand the chair and complete the assembly:
Hold down seat to expand
Grasp push bar
3.
Lithiun battery * 2 pcs
Chair, main assemblyCharger with power cables Seat cushion
Safe belt
Battery direct charge
tranfer cable
Battery serial
connection cable
Tools
