Current E-WAND Leitfaden
1
Installation Manual and
User Guide
2
Installation Manual & User Guide
Please carefully and fully read the following Installation
Manual and User Guide. Without proper installation and
programming, your E-Wand will not perform as designed.
Please save these instructions.
Please be aware that the E-Wand may behave dierently
based on blind manufacturer, slat size, and tilt mechanism
location.
For assistance:
CALL: 844-307-7435
EMAIL: [email protected]
WEBSITE: www.myewand.com/support
Instructional Videos can be viewed by going to
www.myewand.com/support
or by scanning the QR Code with your smart
phone.
To register your E-Wands, visit
www.currentproductscorp.com/products-registration.
3
TABLE OF CONTENTS
Mounting & Programming the E-Wand
Horizontal Blinds Installation & Programming Guide
Vertical Blinds Installation & Programming Guide
Batteries
5
6
7
7
8
9-10
11-14
15-18
19-21
22-25
27-29
30-31
32
33
34
35
35-36
37
37
38
38
39
40
4
Extension Handle
41
42-43
44
45-46
47
47
47
48
48
49
49
50-52
53-54
5
PACKAGE CONTENTS
AND PARTS IDENTIFIER
HORIZONTAL BLIND
MOUNT
VERTICAL BLIND
MOUNT
(6) AA 1.5V ALKALINE
BATTERIES
VERTICAL BLIND
REINFORCEMENT TAPE
EXTRA ADHESIVE STRIPS
OPTIONAL REMOTE
with wall plate
INSTALLATION MANUAL AND
USER GUIDE
Optional HORIZONTAL
TILT Converter
Optional EXTENSION
HANDLE
Wand Hook
SleevE
Installation Manual
&
User Guide
6
MEET YOUR E-Wand
Attachment Hook
Programming Button
Retaining Sleeve
Light Sensor Switch
Temperature Sensor switch
Control Housing
Twist Handle
Battery Cap
The E-Wand allows the user to motorize the slat movement for both horizontal
and vertical window blinds. Users can fully control the position of an individual
blind’s slats or a dened group of blind’s slats with manually with a slight twist of
the handle, with the remote, through the MyCurtains app, and using voice control.
Your E-Wand contains both light and temperature sensors for localized
automation of the opening and closing of the slats. This automatic movement
helps provide privacy at night and can be set to open and close the slats to assist
with maintaining a comfortable room temperature and help save energy.
For power, the E-Wand requires six (6) 1.5v Alkaline AA sized batteries (provided)
which are easy to replace and will provide, in most cases, approximately a year
between battery changes.
7
HORIZONTAL BLINDS DIAGRAM
HEADER
MANUAL TWIST
WAND
OR CORDED TILT
LIFTING CORD
SLATS
NOTE: Some blinds use a corded tilt mechanism to tilt the slats instead of a wand.
If your horizontal blinds have a corded tilt mechanism, you will need to convert it
to a wand tilt mechanism using the horizontal tilt gear. Instructions for converting
to a wand tilt mechanism can be found on page 9.
TILT GEAR
STEM VALANCE
Vertical BLINDS DIAGRAM
SLATS
HEADER
MANUAL TWIST WAND
NOTE: The E-Wand is not compatible with vertical blinds that use a rope or chain
to open and close the slats.
TILT GEAR
STEM
SLAT
ATTACHMENT
8
MOUNTING & programming
THE E-Wand
1. POWER UP
1.1 Unscrew Battery Cap
1.2 Insert Batteries
When batteries are properly installed, the E-Wand will play a
9
HORIZONTAL BLINDS
INstallation & Programming
2. Converting a horizontal cord tilt blind
Figure 2.1; Standard Assembly
Figure 2.2; Remove Tassels
Figure 2.3; Standard Assembly
10
Figure 2.4; Snap in Adapter
Figure 2.5; Slide Stem through Header
