Custom Audio Electronics P 150 Bedienungsanleitung
P 150
Panel printer
P 150
User’s Manual
www.custom.it
P 150
2
All rights reserved. The reproduction of this manual, either totally or partially, in any form
whatsoever, whether it be on paper or through computer processes, is strictly prohibited.
Custom Engineering s.r.l. and the resource teams employed in the making of this manual
will not be held responsible for any problems arising as a result of improper use of this
manual, as they guarantee that the information contained in it has been subjected to
careful inspection.
Any suggestions regarding errors in its contents or possible improvements will be
greatly appreciated. The products are continuously checked and improved. For this
reason Custom Engineering s.r.l. reserves the right to modify the information
contained in this manual without prior notice.
COD. DOME - P150 REV. 1.10
Copyright 1998 Custom Engineering s.r.l. – Italy
Custom Engineering
Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy
Tel. : +39 0521-680111 - Fax : +39 0521-610701
P 150
3
GENERAL INFORMATION REGARDING SAFETY
•Read and keep the following instructions.
•Observe all warnings and follow all instructions attached to the printer.
•Before cleaning the printer, disconnect the feed cable.
•Clean the printer with a damp cloth. Do not use liquid or spray products.
•Do not operate the printer near to water.
•Do not place the printer on unsteady surfaces. It could fall and get seriously
damaged.
•Use the type of electricity supply marked on the printer label. In the event of
uncertainty, contact the seller.
•Position the printer in such a way as to ensure that the cables connected to it will
not be damaged.
•Ensure that the maximum absorbed current of the printer does not exceed the
maximum acceptable current for the type of feed cable used.
•Do not put objects of any kind inside the printer as they could cause a short circuit
or damage parts which could affect its performance.
•Do not spill liquids on the printer.
•Do not carry out technical operations on the printer with the exception of the
scheduled maintenance operations specifically indicated in the user’s manual.
•Disconnect the printer from the electricity supply and have it repaired by a
specialized technician should any of the following conditions occur:
A. The feed connector has been damaged;
B. LIQUID has penetrated to the inside of the printer;
C. The printer has been exposed to rain or water;
D. The printer is not operating normally despite the instructions in the user’s
manual having been followed;
E. The printer has been dropped and its case damaged;
F. The performance of the printer is poor;
G. The printer does not work.
P 150
4
GENERAL CONTENTS
1. DESCRIPTION
1.1 General features
1.2 Product description
1.3 Technical specifications
2. INSTALLATION AND USE
2.1 Removing the printer from its packaging
2.2 Installation procedure
2.3 Connections
2.4 Self-test
2.5 Precautions
2.6 Maintenance
2.7 Configuration of the jumpers
3. INTERFACES
3.1 TTL serial
3.2 TTL parallel
3.3 Current loop RS232 serial (option)
3.4 CENTRONICS parallel (option)
3.5 Real Time Clock (option)
3.6 Installation of options
4. PRINTER FUNCTIONS
4.1 Printing modes
4.2 Graphics
4.3 Control characters
4.4 Characters set
CONTENTS
P 150
5
TABLE CONTENTS
Table 1, technical specifications
Table 2, serial output signals
Table 3, parallel output signals
Table4, controlcharacters
FIGURE CONTENTS
Figure 1, overall view
Figure 2, keyboard
Figure 3, installation
Figure 4, interface card
Figure 5, specimen self-test
Figure 6, paper changing
Figure 7, TTL serial communication
Figure 8, TTL parallel communication
Figure 9, RS232 interface board
Figure 10, printing modes
Figure 11, characters set
APPENDIX CONTENTS
A. POWER SUPPLY
A.1 PSM05power supply
A.2 ALI 9/40 powersupply
B. CONNECTION EXAMPLES
B.1 RS232 serial connection with PC (25-9 pin)
B.2 RS232 serial connection with PC (25-25 pin)
B.3 Centronics parallel connection with PC (25-36 pin)
B.4 Centronics parallel connection with PC (25-25 pin)
CONTENTS
P 150
6
1.1 General features
The P150 (figure 1) is an extremely simple and functional panel printer. It is the ideal solution for
applications which require the immediate printing of data on a ticket, whether they be of an industrial,
professionalorlaboratory nature.Itis suitable forPOS, weighing systems,receipts (not fortax purposes),
as well as for security, controlling and diagnostics purposes.
It has an 8-needle, rapid impact printing mechanism and uses 57.5 mm wide paper rolls.
The P 150 printer is so light-weight and compact that it can be easily fitted on any kind of machinery. It
can be personally programmed and is thus able to meet all possible requirements. It has a 150-byte
print buffer. It has TTL serial and parallel interfaces as standard or RS232 serial and CENTRONICS
parallel interfaces as options. It can, in addition, be equipped with a Real Time Clock . It comes in three
colours and two models, with 24 and 42 columns.
Figure 1
DESCRIPTION
P 150
7
1.2 Product description
The P 150 printer (figure1) has an ABS casing with a top covering the paper roll and print head.
The dimensions of the printer are shown in Figure 1.
The keyboard, located on the front of the printer, consists of the PRINT and FEED keys with their
respective LEDs.
Figure 2
PRINT key
When this key is pressed, if the printer is in parallel pin 2 of J7 comes out of logic state “0”, while in serial
it transmits control character “$0D”; this only happens if it has been enabled by DATA4 to logic “0” or if
switch 5 of the RS232 option is in the ON position. The PRINT key LED only lights up during printing.
FEED key
This enables the manual paper feed. If pressed briefly, when the RTCK option is installed, the time and
date are printed. When the FEED key LED lights up, it is to indicate that the logic card power supply is
correct, i.e. that it is over 3.7 V (minimum threshold below which the printer is reset and the LED goes
out).
DESCRIPTION
P 150
8
1.3 Technical specifications
Table 1 lists the main features of the two printer models: P 150 24 and 42 columns.
Table 1
Columns 24 40
Characters (L x H mm)
Normal 1,7 x 2,6 1,1 x 2,6
Double height 1,7 x 5,2 1,1 x 5,2
Double width 3,4 x 2,6 2,2 x 2,6
Expanded 3,4 x 5,2 2,2 x 5,2
Graphic point 0,33 x 0,38 0,19 x 0,38
Point for line 144 252
Printing speed
Lines/sec 2,5 1,5
Characters/sec 60 60
Feed (lines/sec) 6 3,6
Line buffer 24 byte 42 byte
Printing buffer 150 byte
Printing method Impact dot matrix
Character matrix 6 x 10 points
Printing mode Normal or Reverse
Character set Normal and extended
Standard interface Serial and parallel TTL
Optionally interface Current Loop RS232 serial, Centronics
Supply Double or single 5Vcc ±10%
Absorptions
Medium in stand by 38 mA
Medium in printing 880 mA
Impulsive in printing 3.0A (600 µSec.)
Environmental conditions
Operatingtemperature 0°C - +50°C
Operatinghumidity 35% - 85%
Storagetemperature/humidity -20°C - +70°C / 10%-90%
DESCRIPTION
P 150
9
2.1 Removing the printer from its packaging
Open the package and check that:
a) none of the parts have been damaged during transportation;
b) that the ink cartridge is fitted on the printing mechanism and the paper roll is in place;
c) the two brass screws and washers necessary for installing the printer are, in fact fitted on it
Figure 3
2.2 Installation procedure
1. Make a 112 mm x 112 mm square hole in the wall where the printer is to be installed (see Figure 3).
Unscrew the two brass washers “A”, leaving the screws “B” in their holes.
2. Insert the printer into the hole on the wall, open the front panel and, from the back, manually screw
in the two brass washers, until the printer is firmly in place.
3. Insert the interface and the power supply connectors, located on the logic card.
INSTALLATION and USE
P 150
10
1J5
1
1
J8 J1
1
JP1
JP2
JP3
J7
2.3 Connections
The Figure 4 shows the layout of the interface card of printer P150 and the position of the connectors
mentioned in this manual. The card can be accessed from the back of the printer, as shown in Figure 3.
The functions of the connectors are described follows.
Figure 4
INSTALLATION and USE
