Custom Audio Electronics P190 Bedienungsanleitung

P 190

User’s Manual

P190

Wall printer

www.custom.it

P 190

form whatsoever, whether it be on paper or through computer processes, is strictly

prohibited. Custom Engineering s.r.l. and the resource teams employed in the making

of this manual will not be held responsible for any problems arising as a result of

improper use of this manual, as they guarantee that the information contained in it has

been subjected to careful inspection.

Any suggestions regarding errors in its contents or possible improvements will,

nonetheless, be greatly appreciated. The products are continuously checked and

improved. For this reason Custom Engineering s.r.l. reserves the right to modify the

information contained in this manual without prior notice.

COD. DOME-P190-T Revision 1.10

Custom Engineering

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Tel. : +39 0521-680111 - Fax : +39 0521-610701

http: www.custom.it Email : [email protected]

P 190

GENERAL INFORMATION REGARDING SAFETY

•Read and keep the following instructions.

•Observe all warnings and follow all instructions attached to the printer.

•Before cleaning the printer, disconnect the feed cable.

•Clean the printer with a damp cloth. Do not use liquid or spray products.

•Do not operate the printer near to water.

•Do not place the printer on unsteady surfaces. It could fall and get seriously

damaged.

•Use the type of electricity supply marked on the printer label. In the event of

uncertainty, contact the seller.

•Position the printer in such a way as to ensure that the cables connected to it will

not be damaged.

•Ensure that the maximum absorbed current of the printer does not exceed the

maximum acceptable current for the type of feed cable used.

•Do not put objects of any kind inside the printer as they could cause a short circuit

or damage parts which could affect its performance.

•Do not spill liquids on the printer.

•Do not carry out technical operations on the printer with the exception of the

scheduled maintenance operations specifically indicated in the user’s manual.

•Disconnect the printer from the electricity supply and have it repaired by a

specialized technician should any of the following conditions occur:

A. The feed connector has been damaged.

B. Liquid has penetrated to the inside of the printer;

C. The printer has been exposed to rain or water;

D. The printer is not operating normally despite the instructions in the user’s

manual having been followed.

E. The printer has been dropped and its case damaged.

F. The performance of the printer is poor.

G. The printer does not work.

P 190

GENERAL CONTENTS

1. DESCRIPTION

1.1 General features

1.2 Product description

1.3 Technical specifications

2. INSTALLATION AND USE

2.1 Removing the printer from its packaging

2.2 Installation procedure

2.3 Connections

2.4 Configuration

2.5 Self-test

2.6 Precautions

2.7 Maintenance

3. INTERFACES

3.1 TTL serial

3.2 TTL parallel

3.3 RS232 serial (option)

3.4 CENTRONICS parallel (option)

3.5 Real Time Clock (option)

3.6 Installation of options

4. PRINTER FUNCTIONS

4.1 Printing modes

4.2 Graphics

4.3 Control characters

4.4 Character sets

CONTENTS

P 190

TABLE CONTENTS

Table 1,technicalspecifications

Table 2, serial output signals

Table 3, parallel output signals

Table 4, control characters

FIGURE CONTENTS

Figure 1, front view

Figure 2, overall view

Figure 3, installation

Figure 4, specimen self-test

Figure 5, paper changing

Figure 6, Current Loop selection

Figure 7, printing modes

Figure 8, character sets

APPENDIX CONTENTS

APPENDIX A

A.1 RS232 serial connection with PC

A.2 Centronics parallel connection with PC

APPENDIX B

B.1 PSM05 power supply

B.2 ALI 9/40

APPENDIX C

C.1 Enabling of keyboard configuration function

CONTENTS

P 190

1.1 GENERAL FEATURES

TheP190 (fig.1) is anextremely simpleand functionalwall printer. It isthe idealsolution forapplications

which require the immediate printing of data on a ticket, whether they be of an industrial, professional or

laboratory nature. It is suitable for POS, weighing systems, receipts (not for tax purposes), as well as

for security, controlling and diagnostics purposes.

It has an 8-needle, rapid impact printing mechanism and uses 57.5 mm wide paper rolls.

The P 190 printer is so light-weight and compact that it can be easily fitted on any kind of machinery.

It can be personally programmed and is thus able to meet all possible requirements. It has a 150 byte

print buffer and, as an option, can be equipped with a 2 Kbyte EEPROM. It has TTL serial and parallel

interfaces as standard or RS232 serial and CENTRONICS parallel interfaces as an option. It can, in

addition, be equipped with a Real Time Clock .

It comes in three colours and two models, with 24 and 40 columns.

FIGURE 1

DESCRIPTION

P 190

1.2 PRODUCT DESCRIPTION

The P 190 printer has an ABS casing with a top covering the paper roll and print head.

The dimensions of the printer are shown in Figure 2.

The keyboard, located on the front of the printer, consists of the PRINT and FEED keys with their

respective LEDs.

FIGURE 2

• PRINT key. When this key is pressed, if the printer is in parallel pin 2 of J7 comes out of logic state “0”,

while in serial it transmits control character “$0D”; this only happens if it has been enabled by DATA4 to

logic “0” or if switch 5 of the RS232 option is in the ON position. The PRINT key LED only lights up

during printing. If the printer has a 2 Kbyte EEPROM (option, see paragraph 2.4), the contents of the

memorized blocks are trasmitted.

• FEED key. This enables the manual paper feed. If pressed briefly, when the RTCK option is installed,

the time and date are printed. When the FEED key LED lights up, it is to indicate that the logic card

power supply is correct, i.e. that it is over 3.7 V (minimum threshold below which the printer is reset and

the LED goes out).

DESCRIPTION

P 190

1.3 TECHNICAL SPECIFICATIONS

Table 1 lists the main features of the two printer models: P 190 24 and 40 columns.

TABLE 1

COLUMNS 24 40

Characters (L x H mm):

Normal 1,7 x 2,6 1,1 x 2,6

Double height 1,7 x 5,2 1,1 x 5,2

Double width 3,4 x 2,6 2,2 x 2,6

Expanded 3,4 x 5,2 2,2 x 5,2

Graphic point (L x H mm) 0,33 x 0,38 0,19 x 0,38

Points per line 144 240

Printing speed:

Lines/sec. 2,5 1,5

Characters/sec. 60 60

Feed (lines/sec.) 6 3,6

Line buffer 24 byte 40 byte

Print buffer 150byte

Printing method Impactordot matrix

Character matrix 6 x 10 points

Printing mode Normalor reverse

Character set Normalandextended

Paper roll dimensions 57,5.0,5 mm xØ50 mmmax

Standard interfaces TTLserial andparallel

Optional interfaces Currentloop RS232serial

Centronicsparallel

Power supply double or single 5 Vcc ± 10%

Absorption

Mediumwhenonstandby 38 mA

Mediumwhenprinting 880 mA

Impulsewhenprinting 3,5 A (600 µSec)

Environmental conditions

Operatingtemperature 0°C - +50°C

Operatinghumidity 35% - 85%

Storagetemperature/humidity -20°C - +70°C / 10%-90%

Options Real time Clock, power pack 2 Kbyte EEPROM

DESCRIPTION

P 190

2.1 REMOVING THE PRINTER FROM ITS PACKAGING

Open the package and check that:

a) none of the parts have been damaged during transportation;

b) that the ink cartridge is fitted on the printing mechanism and the paper roll is in place;

c) the two brass screws and washers necessary for installing the printer are, in fact fitted on it

FIGURE 3

2.2 INSTALLATION PROCEDURE

Make a 112 mm x 112 mm square hole in the wall where the printer is to be installed (see Figure 3).

Unscrew the two brass washers “A”, leaving the screws “B” in their holes. Insert the printer into the hole

on the wall, open the front panel and, from the back, manually screw in the two brass washers, until the

printer is firmly in place.

Insert the interface and the power supply connectors, located on the logic card.

If possible, protect the machine from direct light sources.

INSTALLATION and USE

P 190

2.3 CONNECTIONS

Power supply

Withregardtopower supply,theP190 printerhasastandardAMPMODU1 4-pinmale(J3)typeconnector.

The power supply connector pins are marked as follows:

1 GND

2 GND

3 +VT: 5 Vcc ± 15% (printer needle power supply)

4 +VCC: 5 Vcc ± 7% (logic card power supply)

Connecting with the power supply connector (J5) can be avoided by using the flat 20-pin connector (J1)

of the logic or by replacing the latter, by special request at the order stage, with a similar 26-pin one,

thus connecting the power supply and the printer signals with a single cable. In this case, however, the

maximum length of the flat cable must not exceed 30 cm for the 20-pin version and 70 cm for the 26-pin

version. The reason for this is that current running along inside narrow wires can lead to power failures

which could interfere with the correct functioning of the printer.

Ifthe printerhas the RS232or CENTRONICSoptions, itmust besupplied by meansof theJ5 connector.

For the pin pattern required for supplying power through the logic flat cable, please refer to the following

paragraph.

LOGIC

Inthe J120-pin connector,the signalsarearrangedasfollows:

1+VT 2+VT

3 +VCC 4 +VCC

5 GND 6 GND

7 TD 8D6

9 D5 10 D4

11 D3 12 D2

13 D1 14 D0

15 D7 * 16 RESET

17 S-EN 18 READY/RTS

19 FEED 20 STB/RD

INSTALLATION and USE

TO PRINTING MECHANISM

POWER SUPPLY

CONNECTO

EXTERNAL REWINDER

CONNECTO

TO PRINT KEY

TO FEED KE

SELECTION JUMPER SETTING THROUGH

JUMPER FOR ENABLING

FRONT KEYS

CONNECTO

USER

EXTERNAL PRINT

KEY CONNECTOR
