CyberData VoIP Ceiling Speaker Bedienungsanleitung

VoIP Ceiling Speaker

Operations Guide

Part #010844

CyberData Corporation

2555 Garden Road

Monterey, CA 93940

(831) 373-2601

930095H

CyberData Corporation 930095H Operations Guide

PoE VoIP Speaker Operations Guide 930095H

Part # 010844

This manual and related materials are the copyrighted property of CyberData Corporation. No part

of this manual or related materials may be reproduced or transmitted, in any form or by any means

(except for internal use by licensed customers), without prior express written permission of

CyberData Corporation. This manual, and the products, software, firmware, and/or hardware

described in this manual are the property of CyberData Corporation, provided under the terms of an

agreement between CyberData Corporation and recipient of this manual, and their use is subject to

that agreement and its terms.

DISCLAIMER: Except as expressly and specifically stated in a written agreement executed by

CyberData Corporation, CyberData Corporation makes no representation or warranty, express or

implied, including any warranty or merchantability or fitness for any purpose, with respect to this

manual or the products, software, firmware, and/or hardware described herein, and CyberData

Corporation assumes no liability for damages or claims resulting from any use of this manual or

such products, software, firmware, and/or hardware. CyberData Corporation reserves the right to

make changes, without notice, to this manual and to any such product, software, firmware, and/or

hardware.

OPEN SOURCE STATEMENT: Certain software components included in CyberData products are

subject to the GNU General Public License (GPL) and Lesser GNU General Public License (LGPL)

“open source” or “free software” licenses. Some of this Open Source Software may be owned by

third parties. Open Source Software is not subject to the terms and conditions of the CyberData

Source Software is determined by the terms of the GPL, LGPL, or third party, according to who

licenses that software.

Software or firmware developed by CyberData that is unrelated to Open Source Software is

copyrighted by CyberData, subject to the terms of CyberData licenses, and may not be copied,

modified, reverse-engineered, or otherwise altered without explicit written permission from

CyberData Corporation.

TRADEMARK NOTICE: CyberData Corporation and the CyberData Corporation logos are

trademarks of CyberData Corporation. Other product names, trademarks, and service marks may be

the trademarks or registered trademarks of their respective owners.

Phone: (831) 373-2601

Technical Support Ext. 333

[email protected]

Fax: (831) 373-4193

Company and product information at www.cyberdata.net

CyberData Corporation 930095H Operations Guide

Revision History

Revision Date Released Description of Changes

E 11/08/2006 Adds Section 2.4, "Set up the MGROUPS".

F 1/22/2007 Adds info about the RTFM Announcement feature in Table 2-6

G 4/12/2007 Changes the Authenticate ID and password character limit from

30 to 25 in Table 2-7.

H 6/29/2007 Adds Figure 2, "Public Address System—Multicast" .

Adds more information about MGROUPS in Section 2.4, "Set

up the MGROUPS".

Adds information about the Outbound Proxy in Table 2-7.

CyberData Corporation 930095H Operations Guide

Operations Guide 930095H CyberData Corporation

Contents

Chapter 1 Product Overview 1

1.1 Typical System Installation ...................................................................................................................1

1.2 Product Features .....................................................................................................................................2

1.3 Supported Protocols ..............................................................................................................................3

1.4 Supported SIP Servers ...........................................................................................................................3

1.5 Product Specifications ...........................................................................................................................3

Chapter 2 Installing the VoIP Ceiling Speaker 5

2.1 Parts List ..................................................................................................................................................5

2.2 Speaker Setup .........................................................................................................................................6

2.2.1 Connect Power to the Speaker .................................................................................................6

2.2.2 Confirm that the Speaker is Operational and Linked to the Network ...............................7

2.2.3 Confirm the IP Address, Test the Audio, and Check the Volume .......................................8

2.2.4 Adjust the Volume ......................................................................................................................9

2.3 Configure the Speaker Parameters .....................................................................................................9

2.3.1 Log in to the Configuration Home Page ................................................................................10

2.3.2 Configure the Network Parameters ......................................................................................12

2.3.3 Set up the Speaker .....................................................................................................................14

2.3.4 Configure the SIP Parameters .................................................................................................15

2.4 Set up the MGROUPS ..........................................................................................................................18

2.5 Upgrade the Firmware and Reboot the Speaker .............................................................................20

2.5.1 Reboot the Speaker ..................................................................................................................22

2.6 Restore the Factory Default Settings .................................................................................................23

Appendix A Mounting the Speaker 25

A.1 Mount the Speaker .............................................................................................................................25

Appendix B Setting up a TFTP Server 29

B.1 Set up a TFTP Server ...........................................................................................................................29

B.1.1 In a LINUX Environment ........................................................................................................29

B.1.2 In a Windows Environment ...................................................................................................29

B.1.3 In a Solarwinds Server Environment ....................................................................................29

Appendix C Troubleshooting/Technical Support 31

C.1 Frequently Asked Questions (FAQ) .................................................................................................31

C.2 Documentation ....................................................................................................................................31

C.3 Contact Information ............................................................................................................................31

C.4 Warranty ...............................................................................................................................................32

Index 33

CyberData Corporation 930095H Operations Guide

Operations Guide 930095H CyberData Corporation

1 Product Overview

The Voice-over-IP (VoIP) Ceiling Speaker uses a single cable to connect to existing LANs to

broadcast digital audio over your public address system. The small footprint and low height makes

this an ideal speaker to discreetly mount almost anywhere.

1.1 Typical System Installation

Figure 1 illustrates how the VoIP Ceiling Speakers are normally installed as part of a public address

system.

Figure 1. Public Address System

802.3af PoE compliant Hub

SIP Server

PoE VoIP Speakers VoIP Phone

CyberData Corporation 930095H Operations Guide

Product Overview

Product Features

Figure 2 illustrates how the VoIP Ceiling Speakers are can be installed as part of a multicast public

address system.

Figure 2. Public Address System—Multicast

1.2 Product Features

●

SIP compliant

●

Multicast support

●

Dual speeds of 10 Mbps and 100 Mbps

●

802.3af compliant

●

High efficiency speaker driver

●

Web-based configuration

●

External volume control

●

Small footprint

●

Web-based firmware upgrades

Product Overview

Supported Protocols

Operations Guide 930095H CyberData Corporation

1.3 Supported Protocols

The IP Speaker supports:

●SIP

●Multicast

●HTTP Web-based configuration

Provides an intuitive user interface for easy system configuration and verification of speaker

operations.

●DHCP Client

Dynamically assigns IP addresses in addition to the option to use static addressing.

●TFTP Client

Facilitates Web-based firmware upgrades of the latest speaker capabilities.

●RTP

●RTP/AVP - Audio Video Profile

●Audio Encodings

PCMU (G.711 mu-law)

PCMA (G.711 A-law)

Packet Time 20 ms

1.4 Supported SIP Servers

The following link contains information on how to configure the speaker for the supported SIP

servers:

http://www.cyberdata.net/support/voip/ceilingspeaker.html

1.5 Product Specifications

Category Specification

Sensitivity 96dB/1W/1M S.P. Level

Output 8 Watts Peak Power

Port Baud Rate 10/100 Mbps

Power Requirement 802.3af compliant

Protocol SIP

Part Number 010844

Dimensions 9" x 2.4"

Weight 1.6 lbs./shipping weight of 2.5 lbs.

CyberData Corporation 930095H Operations Guide

Product Overview

Product Specifications
