CZone Switch Control Interface Installationsanleitung

Product description:

The Switch Control Interface (SCI) is a module which converts signals from traditional mechanical switches and converts them into a CAN

signal to control loads via channels on output interface modules

• 8 switch channels per module (sixteen switch points)

• Single switch position can control multiple OI channels

• Multiple SCI switches can control single OI channel

• Output for backlighting of switch labels (dimmable)

• Outputs systems on and function/fault codes to systems

on LED of switches (dimmable)

• Programmable switch types

Normally open

Normally closed

Momentary open or closed

Dimmer

Timer

Interlocking

Dimensions:

H 100mm (3”29/32) x W156mm (6”3/32) x D 42mm (1”5/8)

• IPX5 water ingress rated

Weight: 281g

SCI features:

Switch Control Interface (SCI)

For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

EMC ratings:

• IEC EN 60945

• IEC EN 61000

• FCC Class B

• ISO 7637 - 1 (12V Passenger cars and light commercial vehicles

with nominal 12V supply voltage - Electrical transient conduction

along supply lines only)

• ISO 7637 - 2 (24V Commercial vehicles with nominal 24 V supply

voltage - Electrical transient conduction along supply lines only)

• IEC Standards for indirect lighting strikes

For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

LED Flash Codes

Network Status indicator

Network Status Indicator

• Extinguished = Network power disconnected

• Green = Network power connected

• Red = Network trafﬁc

Channel Status Indicators

In the Case of the SCI module the LED channel status indicator ﬂashes are displayed on the Carling switches that are connected to the

SCI (Systems in operation window)



For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

Connections

SCI – 8 Way connector housing

Front View

Plugs into

carling Switch

Plugs to SCI 8

Way connector



For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

Connections

Internal SCI Conductor connections

RJ45 Conductor Colour Carling terminal Housing Conductor Designation

(in relation to SCI)

1 Green/White 8 Backlighting + 2V

2 NC

3 NC

4 Brown/White 3 Switch O/P Position 1

5 Green 1 Switch O/P Position 2

6 Blue 7 NEG

7 Orange Systems on + 2V

8 Brown 2 Switch I/P centre position

Internal SCI Conductor connections

SCI Cable Connections



For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

Labelling

Connections/LED ﬂash code label

This label is located on the inside of the front lid of the unit, it shows the LED codes and electrical connections to the unit

For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com



For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

Pictorial Overview

NMEA 2000

connector

Carling

8 way RJ45

connector bank

Proprietary

cable assembly

Waterproof

Cable grommet

For more information contact BEP | ph: +64 9 415 7261 | email: [email protected] | www.bepmarine.com

Dimensions


